TensorRT Operators

Boilerplate for All Operator Examples

This boilerplate code provides a framework to run all the operator examples. To make them runnable, copy and paste the specific example code between the designated ‘example begin’ and ‘example end’ comments.

import numpy as np
import math # example_plugin_v2.py
import ctypes

import tensorrt as trt
from cuda.bindings import driver as cuda, runtime as cudart
from common import cuda_call, CudaStreamContext, DeviceMem, PinnedHostMem, memcpy_host_to_device_async, memcpy_device_to_host_async




class OutputAllocator(trt.IOutputAllocator):
    def __init__(self, curr_size):
        trt.IOutputAllocator.__init__(self)
        self.curr_size = curr_size
        self.allocated_mem = None
        if curr_size > 0:
            self.allocated_mem = DeviceMem(curr_size)
        self.tensor_shape = None

    def reallocate_output(self, tensor_name, memory, size, alignment):
        assert size > 0
        if size > self.curr_size:
            self.allocated_mem = DeviceMem(size)
            self.curr_size = size
        return int(self.allocated_mem.device_ptr)

    def notify_shape(self, tensor_name, shape):
        self.tensor_shape = shape

class Runner:
    def __init__(self, logger=trt.Logger(min_severity=trt.ILogger.Severity.INFO)):
        self.builder = trt.Builder(logger)
        self.network = self.builder.create_network(flags=0)
        self.config = self.builder.create_builder_config()
        self.runtime = trt.Runtime(logger)
        self.inputs = {}
        self.outputs = {}
        self.expected = {}
        self.results = {}
        self.logger = logger
        self.atol = 0.1

def example(get_runner: Runner):
    network = get_runner.network
    inputs = get_runner.inputs
    outputs = get_runner.outputs
    expected = get_runner.expected

    # -------------------- Example Begin --------------------
    # Paste the code examples here
    # e.g. for Activation
    in1 = network.add_input("input1", dtype=trt.float32, shape=(2, 3))
    layer = network.add_activation(in1, type=trt.ActivationType.RELU)
    network.mark_output(layer.get_output(0))

    inputs[in1.name] = np.array([[-3.0, -2.0, -1.0], [0.0, 1.0, 2.0]])

    outputs[layer.get_output(0).name] = layer.get_output(0).shape

    expected[layer.get_output(0).name] = np.array([[0.0, 0.0, 0.0], [0.0, 1.0, 2.0]])
    # --------------------- Example End ---------------------

    return get_runner

def run_example():
    example_runner = Runner()
    inputs = example_runner.inputs
    outputs = example_runner.outputs
    expected = example_runner.expected
    builder = example_runner.builder
    config = example_runner.config
    runtime = example_runner.runtime
    results = example_runner.results

    def log_info(info):
        example_runner.logger.log(trt.ILogger.Severity.INFO, f"[Example] {info}")

    def log_error(info):
        example_runner.logger.log(trt.ILogger.Severity.ERROR, f"[Example] {info}")

    example_runner = example(example_runner)

    log_info("Building serialized network")
    serialized_engine = builder.build_serialized_network(example_runner.network, config)
    assert serialized_engine is not None

    log_info("Creating engine")
    engine = runtime.deserialize_cuda_engine(serialized_engine)
    context = engine.create_execution_context()

    # Allocate host and device buffers
    in_mem = []
    out_mem = dict()
    output_allocators = dict()
    tensor_names = [engine.get_tensor_name(i) for i in range(engine.num_io_tensors)]
    for tensor in tensor_names:
        dtype = np.dtype(trt.nptype(engine.get_tensor_dtype(tensor)))
        if engine.get_tensor_mode(tensor) == trt.TensorIOMode.INPUT:
            if engine.is_shape_inference_io(tensor):
                context.set_input_shape(tensor, inputs[tensor].shape)
                # Get input memory address from the numpy object.
                input_address = inputs[tensor].ctypes.data
                context.set_tensor_address(tensor, input_address)
            else:
                # Handle input tensors
                context.set_input_shape(tensor, inputs[tensor].shape)
                input_buffer = np.ascontiguousarray(inputs[tensor], dtype=dtype)
                input_memory = DeviceMem(input_buffer.nbytes)
                context.set_tensor_address(tensor, int(input_memory.device_ptr))
                in_mem.append((input_memory, input_buffer))
        else: # Handle output tensors
            # Check if output tensor contains unknown shape
            if trt.volume(context.get_tensor_shape(tensor)) < 0:
                # Set an output allocator for the output tensor with unknown shape.
                # Initialize output allocator with 0 memory size, so reallocate always allocate.
                output_allocator = OutputAllocator(0)
                context.set_output_allocator(tensor, output_allocator)
                output_allocators[tensor] = output_allocator
                # No need to initialize output buffer and output memory here.
                out_mem[tensor] = None
            else:
                size = trt.volume(context.get_tensor_shape(tensor))
                output_buffer = PinnedHostMem(size, dtype)
                output_memory = DeviceMem(output_buffer.nbytes)
                context.set_tensor_address(tensor, int(output_memory.device_ptr))
                out_mem[tensor] = (output_buffer.array, output_memory)

    # Run inference
    with CudaStreamContext() as stream:
        # Transfer input data to the GPU.
        for input in in_mem:
            memcpy_host_to_device_async(input[0].device_ptr, input[1], stream.stream)
        log_info("Running example")
        context.execute_async_v3(stream_handle=stream.stream)
        # Transfer prediction output from the GPU.
        for output in out_mem:
            output_mem = out_mem[output]
            if output_mem is None:
                # Must have been allocated using OutputAllocator.reallocate.
                assert output in output_allocators
                assert output_allocators[output].allocated_mem
                shape = output_allocators[output].tensor_shape
                assert shape is not None
                size = trt.volume(shape)
                dtype = np.dtype(trt.nptype(engine.get_tensor_dtype(output)))
                output_buffer = PinnedHostMem(size, dtype)
                output_memory = context.get_tensor_address(output)
                output_mem = (output_buffer.array, output_memory)
                # Store tensor to output buffer and output memory mappings.
                out_mem[output] = output_mem
            # Handle both DeviceMem objects and raw pointers
            device_ptr = output_mem[1].device_ptr if hasattr(output_mem[1], 'device_ptr') else output_mem[1]
            memcpy_device_to_host_async(output_mem[0], device_ptr, stream.stream)
        log_info("Synchronizing with cuda stream")
        stream.synchronize()
        log_info("Sync done")
    for output in out_mem:
        output_mem = out_mem[output][0]
        shape = outputs[output]
        if trt.volume(context.get_tensor_shape(tensor)) < 0:
            # Get real output tensor size
            shape = output_allocators[output].tensor_shape
            assert shape is not None
            size = trt.volume(shape)
            output_mem = output_mem[:size]
        output_mem = output_mem.reshape(shape)
        results[output] = output_mem

    log_info(f"Network inputs: {inputs}")
    log_info(f"Inference results: {results}")
    log_info(f"Expected results: {expected}")

    # Check result
    is_equal = {}
    all_are_equal = True
    for output in expected:
        is_equal[output] = np.allclose(results[output], expected[output], atol=example_runner.atol)
        all_are_equal &= is_equal[output]
    log_info(f"All results are expected: {all_are_equal}")
    if all_are_equal is False:
        for output in is_equal:
            if is_equal[output] is False:
                log_error(f"{output} mismatch:")
                log_error(f"expected - content:{expected[output]}")
                log_error(f"actual - content:{repr(results[output])}")

    log_info("Example complete")

if __name__ == "__main__":
    run_example()

TensorRT operators have stricter volume limits for input and output tensors on Turing GPUs, i.e. the product of the tensor dimensions cannot exceed \(2^{31}\). Volume limits for each operator on other GPUs can be found in the corresponding operator documentation page.
