Perspective Image Warp

Overview

Perspective Image Warp algorithm allows for correcting perspective distortion caused by camera misalignment with respect to the object plane being captured. This is the case when the camera is, for instance, pointing to a frame hanging on a wall, but looking from below. The resulting image won't have opposite sides that are parallel.

If the camera position, tilt and pan relative to the frame are known, a 3x3 pespective transform can be derived, which will warp the image in order to keep frame's opposite sides parallel to each other, as shown below.

Input	Transform	Corrected
	\begin{bmatrix} 0.5386 & 0.1419 & -74\\ -0.4399 & 0.8662 & 291.5\\ -0.0005 & 0.0003 & 1 \end{bmatrix}

Implementation

The perspective transform matrix maps the source image into the destination image. The transform can be described mathematically by the equation below:

\begin{align*} \mathsf{y} = \mathsf{H}_p \mathsf{x} = \begin{bmatrix} \mathsf{A} & \mathsf{t} \\ \mathsf{p}^\intercal & p \end{bmatrix} \mathsf{x} \end{align*}

or, expanding the matrices and vectors:

\begin{align*} \begin{bmatrix} y_u \\ y_v \\ y_w \end{bmatrix} &= \begin{bmatrix} a_{11} & a_{12} & t_u \\ a_{21} & a_{22} & t_v \\ p_0 & p_1 & p \end{bmatrix} \begin{bmatrix}x_u \\ x_v \\ 1 \end{bmatrix} \\ \end{align*}

In these equations,

• \(\mathsf{H}_p\) is the projection matrix
• \(\mathsf{x}\) is the homogeneous coordinates in the source image.
• \(\mathsf{y}\) is the homogeneous coordinates in the destination image.
• \(\mathsf{A}\) is a 2x2 non-singular matrix with the linear component.
• \(\mathsf{t}\) is the translation component.
• \(\mathsf{p},p\) are the projective components. \(p\) is usually 1.

The projection of \(\mathsf{y}\) onto the output image is then given by:

\begin{align*} \begin{bmatrix} y'_u \\ y'_v \end{bmatrix} &= \begin{bmatrix} y_u/y_w \\ y_v/y_w \end{bmatrix} \end{align*}

These equations are efficiently implemented by doing the reverse operation, i.e, applying the inverse transform on destination pixels and sample the corresponding values from source image. If flag VPI_WARP_INVERSE is passed, the operation will assume that user's matrix is already inverted and won't try to invert it again. Pass zero if matrix must be inverted by VPI.

\begin{align*} \mathsf{H}_p^{-1} &= \begin{bmatrix}h_{11} & h_{12} & h_{13} \\ h_{21} & h_{22} & h_{23} \\ h_{31} & h_{32} & h_{33}\end{bmatrix} \\ \mathrm{dst}(u,v) &= \mathrm{src}\left(\frac{h_{11}u+h_{12}v+h_{13}}{h_{31}u+h_{32}v+h_{33}},\frac{h_{21}u+h_{22}v+h_{23}}{h_{31}u+h_{32}v+h_{33}}\right), \forall (u,v) \in \mathrm{dst} \end{align*}

The source and destination images may have different dimensions. They must have the same type, though.

Interpolation is used when the source coordinate doesn't fall exactly on a pixel. Perspective Image Warp accepts the following interpolation modes:

• VPI_INTERP_NEAREST

• VPI_INTERP_LINEAR

• VPI_INTERP_CATMULL_ROM


The only boundary mode currently supported is:

• VPI_BOUNDARY_COND_ZERO - Sampling outside source image boundary will return a black value. This can be seen in the corrected image on top of this page, the black regions fall outside source image.

Usage

1. Initialization phase
   1. Include the header that defines the Perspective Image Warp function.

      #include <vpi/algo/PerspectiveImageWarp.h>

   2. Define the stream on which the algorithm will be executed and the input image.

          VPIStream stream = /*...*/;
          VPIImage input   = /*...*/;

   3. Create the output image. In this particular case both input and output have same dimensions, but this couldn't be the case.

          uint32_t w, h;
          vpiImageGetSize(input, &w, &h);

          VPIImageType type;
          vpiImageGetType(input, &type);

          VPIImage output;
          vpiImageCreate(w, h, type, 0, &output);

   4. Create the algorithm payload.

          VPIPayload warp;
          vpiCreatePerspectiveImageWarp(stream, &warp);

2. Processing phase
   1. Define the perspective transform to be applied. Note that the transform doesn't have to be the same in every call.

          VPIPerspectiveTransform xform =
          {
              { 0.5386, 0.1419, -74  },
              {-0.4399, 0.8662, 291.5},
              {-0.0005, 0.0003,   1  }
          };

   2. Submit the algorithm to the stream, along with all parameters.

          vpiSubmitPerspectiveImageWarp(warp, input, xform, output, VPI_INTERP_LINEAR, VPI_BOUNDARY_COND_ZERO, 0);

   3. Optionally, wait until the processing is done.

          vpiStreamSync(stream);

For more details, consult the API reference.

Limitations and Constraints

Constraints for specific backends supersede the ones specified for all backends.

PVA

• The following image types are accepted:
  • VPI_IMAGE_TYPE_NV12
• Only available on Jetson Xavier family.

CUDA

• Not implemented

CPU

• Not implemented

Performance

For further information on how performance was benchmarked, see Performance Measurement. Currently this algorithm is only available on Jetson Xavier family.

Jetson AGX Xavier

size	type	interp.	CPU	CUDA	PVA
1920x1080	nv12	nearest	n/a	n/a	2.290 ms
1920x1080	nv12	linear	n/a	n/a	2.283 ms
1920x1080	nv12	catmull	n/a	n/a	2.284 ms
