Gaussian Pyramid Generator

Overview

Gaussian pyramid generator takes one input image and fills the output image pyramid with downscaled versions of the input.

Input	Output

Implementation

The function is implemented by generating the Gaussian pyramid from the base (level 0) to coarser levels.

If the input image actually wraps the first level of the image pyramid, nothing is done for this level. If not, the input image contents will be copied to the first image pyramid level.

The coarser levels are generated by taking the previous level, convolving it using a clamp border extension with the following kernel:

\[ k = \begin{bmatrix} 1 \\ 4 \\ 6 \\ 4 \\ 1 \end{bmatrix} \cdot \begin{bmatrix} 1 & 4 & 6 & 4 & 1 \end{bmatrix} \]

Because only 2x downscaling is supported, the result is then downsampled by keeping all pixels with even coordinates.

The algorithm repeats until all levels are generated.

C API functions

For list of limitations, constraints and backends that implements the algorithm, consult reference documentation of the following functions:

Function	Description
vpiSubmitGaussianPyramidGenerator	Computes the Gaussian pyramid from the input image.

Usage

Language: C/C++ Python

1. Import VPI module

   import vpi

2. Returns the 4-level Gaussian pyramid created from the input image using the CUDA backend. Input is a VPI image, and output is a VPI pyramid.

   with vpi.Backend.CUDA:
       output = input.gaussian_pyramid(4)

1. Initialization phase
   1. Include the header that defines the Gaussian pyramid generator function.

      #include <vpi/algo/GaussianPyramid.h>

   2. Define the input image object.

          VPIImage input = /*...*/;

   3. Create the output pyramid with the desired number of levels (4) and scale factor (0.5). It gets its dimensions and format from the input image.

          int32_t w, h;
          vpiImageGetSize(input, &w, &h);

          VPIImageFormat type;
          vpiImageGetFormat(input, &type);

          VPIPyramid output;
          vpiPyramidCreate(w, h, type, 4, 0.5, 0, &output);

   4. Create the stream where the algorithm will be submitted for execution.

          VPIStream stream;
          vpiStreamCreate(0, &stream);

2. Processing phase
   1. Submit the algorithm to the stream, along with the input image and output pyramid. It'll be executed by the CPU backend.

          vpiSubmitGaussianPyramidGenerator(stream, VPI_BACKEND_CPU, input, output, VPI_BORDER_CLAMP);

   2. Optionally, wait until the processing is done.

          vpiStreamSync(stream);

3. Cleanup phase
   1. Free resources held by the stream, the input image and the output pyramid.

          vpiStreamDestroy(stream);
          vpiImageDestroy(input);
          vpiPyramidDestroy(output);

For more information, see Gaussian Pyramid Generator in the "C API Reference" section of VPI - Vision Programming Interface.

Performance

For information on how to use the performance table below, see Algorithm Performance Tables.
Before comparing measurements, consult Comparing Algorithm Elapsed Times.
For further information on how performance was benchmarked, see Performance Benchmark.

clear filters Device: Jetson AGX Xavier Jetson AGX Orin  -  Streams: 1 2 4 8
