cuBLAS

The API Reference guide for cuBLAS, the CUDA Basic Linear Algebra Subroutine library.

1. Introduction

The cuBLAS library is an implementation of BLAS (Basic Linear Algebra Subprograms) on top of the NVIDIA®CUDA™ runtime. It allows the user to access the computational resources of NVIDIA Graphics Processing Unit (GPU).

The cuBLAS Library exposes four sets of APIs:

  • The cuBLAS API, which is simply called cuBLAS API in this document (starting with CUDA 6.0),

  • The cuBLASXt API (starting with CUDA 6.0), and

  • The cuBLASLt API (starting with CUDA 10.1)

  • The cuBLASDx API (not shipped with the CUDA Toolkit)

To use the cuBLAS API, the application must allocate the required matrices and vectors in the GPU memory space, fill them with data, call the sequence of desired cuBLAS functions, and then upload the results from the GPU memory space back to the host. The cuBLAS API also provides helper functions for writing and retrieving data from the GPU.

To use the cuBLASXt API, the application may have the data on the Host or any of the devices involved in the computation, and the Library will take care of dispatching the operation to, and transferring the data to, one or multiple GPUs present in the system, depending on the user request.

The cuBLASLt is a lightweight library dedicated to GEneral Matrix-to-matrix Multiply (GEMM) operations with a new flexible API. This library adds flexibility in matrix data layouts, input types, compute types, and also in choosing the algorithmic implementations and heuristics through parameter programmability. After a set of options for the intended GEMM operation are identified by the user, these options can be used repeatedly for different inputs. This is analogous to how cuFFT and FFTW first create a plan and reuse for same size and type FFTs with different input data.

1.1. Data Layout

For maximum compatibility with existing Fortran environments, the cuBLAS library uses column-major storage, and 1-based indexing. Since C and C++ use row-major storage, applications written in these languages can not use the native array semantics for two-dimensional arrays. Instead, macros or inline functions should be defined to implement matrices on top of one-dimensional arrays. For Fortran code ported to C in mechanical fashion, one may chose to retain 1-based indexing to avoid the need to transform loops. In this case, the array index of a matrix element in row “i” and column “j” can be computed via the following macro

#define IDX2F(i,j,ld) ((((j)-1)*(ld))+((i)-1))

Here, ld refers to the leading dimension of the matrix, which in the case of column-major storage is the number of rows of the allocated matrix (even if only a submatrix of it is being used). For natively written C and C++ code, one would most likely choose 0-based indexing, in which case the array index of a matrix element in row “i” and column “j” can be computed via the following macro

#define IDX2C(i,j,ld) (((j)*(ld))+(i))

1.2. New and Legacy cuBLAS API

Starting with version 4.0, the cuBLAS Library provides a new API, in addition to the existing legacy API. This section discusses why a new API is provided, the advantages of using it, and the differences with the existing legacy API.

Warning

The legacy cuBLAS API is deprecated and will be removed in future release.

The new cuBLAS library API can be used by including the header file cublas_v2.h. It has the following features that the legacy cuBLAS API does not have:

  • The handle to the cuBLAS library context is initialized using the function and is explicitly passed to every subsequent library function call. This allows the user to have more control over the library setup when using multiple host threads and multiple GPUs. This also allows the cuBLAS APIs to be reentrant.

  • The scalars \(\alpha\) and \(\beta\) can be passed by reference on the host or the device, instead of only being allowed to be passed by value on the host. This change allows library functions to execute asynchronously using streams even when \(\alpha\) and \(\beta\) are generated by a previous kernel.

  • When a library routine returns a scalar result, it can be returned by reference on the host or the device, instead of only being allowed to be returned by value only on the host. This change allows library routines to be called asynchronously when the scalar result is generated and returned by reference on the device resulting in maximum parallelism.

  • The error status cublasStatus_t is returned by all cuBLAS library function calls. This change facilitates debugging and simplifies software development. Note that cublasStatus was renamed cublasStatus_t to be more consistent with other types in the cuBLAS library.

  • The cublasAlloc() and cublasFree() functions have been deprecated. This change removes these unnecessary wrappers around cudaMalloc() and cudaFree(), respectively.

  • The function cublasSetKernelStream() was renamed cublasSetStream() to be more consistent with the other CUDA libraries.

The legacy cuBLAS API, explained in more detail in Using the cuBLAS Legacy API, can be used by including the header file cublas.h. Since the legacy API is identical to the previously released cuBLAS library API, existing applications will work out of the box and automatically use this legacy API without any source code changes.

The current and the legacy cuBLAS APIs cannot be used simultaneously in a single translation unit: including both cublas.h and cublas_v2.h header files will lead to compilation errors due to incompatible symbol redeclarations.

In general, new applications should not use the legacy cuBLAS API, and existing applications should convert to using the new API if it requires sophisticated and optimal stream parallelism, or if it calls cuBLAS routines concurrently from multiple threads.

For the rest of the document, the new cuBLAS Library API will simply be referred to as the cuBLAS Library API.

As mentioned earlier the interfaces to the legacy and the cuBLAS library APIs are the header file cublas.h and cublas_v2.h, respectively. In addition, applications using the cuBLAS library need to link against:

  • The DSO cublas.so for Linux,

  • The DLL cublas.dll for Windows, or

  • The dynamic library cublas.dylib for Mac OS X.

Note

The same dynamic library implements both the new and legacy cuBLAS APIs.

1.3. Example Code

For sample code references please see the two examples below. They show an application written in C using the cuBLAS library API with two indexing styles (Example 1. “Application Using C and cuBLAS: 1-based indexing” and Example 2. “Application Using C and cuBLAS: 0-based Indexing”).

//Example 1. Application Using C and cuBLAS: 1-based indexing
//-----------------------------------------------------------
#include <stdio.h>
#include <stdlib.h>
#include <math.h>
#include <cuda_runtime.h>
#include "cublas_v2.h"
#define M 6
#define N 5
#define IDX2F(i,j,ld) ((((j)-1)*(ld))+((i)-1))

static __inline__ void modify (cublasHandle_t handle, float *m, int ldm, int n, int p, int q, float alpha, float beta){
    cublasSscal (handle, n-q+1, &alpha, &m[IDX2F(p,q,ldm)], ldm);
    cublasSscal (handle, ldm-p+1, &beta, &m[IDX2F(p,q,ldm)], 1);
}

int main (void){
    cudaError_t cudaStat;
    cublasStatus_t stat;
    cublasHandle_t handle;
    int i, j;
    float* devPtrA;
    float* a = 0;
    a = (float *)malloc (M * N * sizeof (*a));
    if (!a) {
        printf ("host memory allocation failed");
        return EXIT_FAILURE;
    }
    for (j = 1; j <= N; j++) {
        for (i = 1; i <= M; i++) {
            a[IDX2F(i,j,M)] = (float)((i-1) * N + j);
        }
    }
    cudaStat = cudaMalloc ((void**)&devPtrA, M*N*sizeof(*a));
    if (cudaStat != cudaSuccess) {
        printf ("device memory allocation failed");
        free (a);
        return EXIT_FAILURE;
    }
    stat = cublasCreate(&handle);
    if (stat != CUBLAS_STATUS_SUCCESS) {
        printf ("CUBLAS initialization failed\n");
        free (a);
        cudaFree (devPtrA);
        return EXIT_FAILURE;
    }
    stat = cublasSetMatrix (M, N, sizeof(*a), a, M, devPtrA, M);
    if (stat != CUBLAS_STATUS_SUCCESS) {
        printf ("data download failed");
        free (a);
        cudaFree (devPtrA);
        cublasDestroy(handle);
        return EXIT_FAILURE;
    }
    modify (handle, devPtrA, M, N, 2, 3, 16.0f, 12.0f);
    stat = cublasGetMatrix (M, N, sizeof(*a), devPtrA, M, a, M);
    if (stat != CUBLAS_STATUS_SUCCESS) {
        printf ("data upload failed");
        free (a);
        cudaFree (devPtrA);
        cublasDestroy(handle);
        return EXIT_FAILURE;
    }
    cudaFree (devPtrA);
    cublasDestroy(handle);
    for (j = 1; j <= N; j++) {
        for (i = 1; i <= M; i++) {
            printf ("%7.0f", a[IDX2F(i,j,M)]);
        }
        printf ("\n");
    }
    free(a);
    return EXIT_SUCCESS;
}

//Example 2. Application Using C and cuBLAS: 0-based indexing
//-----------------------------------------------------------
#include <stdio.h>
#include <stdlib.h>
#include <math.h>
#include <cuda_runtime.h>
#include "cublas_v2.h"
#define M 6
#define N 5
#define IDX2C(i,j,ld) (((j)*(ld))+(i))

static __inline__ void modify (cublasHandle_t handle, float *m, int ldm, int n, int p, int q, float alpha, float beta){
    cublasSscal (handle, n-q, &alpha, &m[IDX2C(p,q,ldm)], ldm);
    cublasSscal (handle, ldm-p, &beta, &m[IDX2C(p,q,ldm)], 1);
}

int main (void){
    cudaError_t cudaStat;
    cublasStatus_t stat;
    cublasHandle_t handle;
    int i, j;
    float* devPtrA;
    float* a = 0;
    a = (float *)malloc (M * N * sizeof (*a));
    if (!a) {
        printf ("host memory allocation failed");
        return EXIT_FAILURE;
    }
    for (j = 0; j < N; j++) {
        for (i = 0; i < M; i++) {
            a[IDX2C(i,j,M)] = (float)(i * N + j + 1);
        }
    }
    cudaStat = cudaMalloc ((void**)&devPtrA, M*N*sizeof(*a));
    if (cudaStat != cudaSuccess) {
        printf ("device memory allocation failed");
        free (a);
        return EXIT_FAILURE;
    }
    stat = cublasCreate(&handle);
    if (stat != CUBLAS_STATUS_SUCCESS) {
        printf ("CUBLAS initialization failed\n");
        free (a);
        cudaFree (devPtrA);
        return EXIT_FAILURE;
    }
    stat = cublasSetMatrix (M, N, sizeof(*a), a, M, devPtrA, M);
    if (stat != CUBLAS_STATUS_SUCCESS) {
        printf ("data download failed");
        free (a);
        cudaFree (devPtrA);
        cublasDestroy(handle);
        return EXIT_FAILURE;
    }
    modify (handle, devPtrA, M, N, 1, 2, 16.0f, 12.0f);
    stat = cublasGetMatrix (M, N, sizeof(*a), devPtrA, M, a, M);
    if (stat != CUBLAS_STATUS_SUCCESS) {
        printf ("data upload failed");
        free (a);
        cudaFree (devPtrA);
        cublasDestroy(handle);
        return EXIT_FAILURE;
    }
    cudaFree (devPtrA);
    cublasDestroy(handle);
    for (j = 0; j < N; j++) {
        for (i = 0; i < M; i++) {
            printf ("%7.0f", a[IDX2C(i,j,M)]);
        }
        printf ("\n");
    }
    free(a);
    return EXIT_SUCCESS;
}

2. Using the cuBLAS API

2.1. General Description

This section describes how to use the cuBLAS library API.

2.1.1. Error Status

All cuBLAS library function calls return the error status cublasStatus_t.

2.1.2. cuBLAS Context

The application must initialize a handle to the cuBLAS library context by calling the cublasCreate() function. Then, the handle is explicitly passed to every subsequent library function call. Once the application finishes using the library, it must call the function cublasDestroy() to release the resources associated with the cuBLAS library context.

This approach allows the user to explicitly control the library setup when using multiple host threads and multiple GPUs. For example, the application can use cudaSetDevice() to associate different devices with different host threads and in each of those host threads it can initialize a unique handle to the cuBLAS library context, which will use the particular device associated with that host thread. Then, the cuBLAS library function calls made with different handles will automatically dispatch the computation to different devices.

The device associated with a particular cuBLAS context is assumed to remain unchanged between the corresponding cublasCreate() and cublasDestroy() calls. In order for the cuBLAS library to use a different device in the same host thread, the application must set the new device to be used by calling cudaSetDevice() and then create another cuBLAS context, which will be associated with the new device, by calling cublasCreate().

A cuBLAS library context is tightly coupled with the CUDA context that is current at the time of the cublasCreate() call. An application that uses multiple CUDA contexts is required to create a cuBLAS context per CUDA context and make sure the former never outlives the latter.

2.1.3. Thread Safety

The library is thread safe and its functions can be called from multiple host threads, even with the same handle. When multiple threads share the same handle, extreme care needs to be taken when the handle configuration is changed because that change will affect potentially subsequent cuBLAS calls in all threads. It is even more true for the destruction of the handle. So it is not recommended that multiple thread share the same cuBLAS handle.

2.1.4. Results Reproducibility

By design, all cuBLAS API routines from a given toolkit version, generate the same bit-wise results at every run when executed on GPUs with the same architecture and the same number of SMs. However, bit-wise reproducibility is not guaranteed across toolkit versions because the implementation might differ due to some implementation changes.

This guarantee holds when a single CUDA stream is active only. If multiple concurrent streams are active, the library may optimize total performance by picking different internal implementations.

Note

The non-deterministic behavior of multi-stream execution is due to library optimizations in selecting internal workspace for the routines running in parallel streams. To avoid this effect user can either:

  • provide a separate workspace for each used stream using the cublasSetWorkspace() function, or

  • have one cuBLAS handle per stream, or

  • use cublasLtMatmul() instead of GEMM-family of functions and provide user owned workspace, or

  • set a debug environment variable CUBLAS_WORKSPACE_CONFIG to :16:8 (may limit overall performance) or :4096:8 (will increase library footprint in GPU memory by approximately 24MiB).

Any of those settings will allow for deterministic behavior even with multiple concurrent streams sharing a single cuBLAS handle.

This behavior is expected to change in a future release.

For some routines such as cublas<t>symv and cublas<t>hemv, an alternate significantly faster routine can be chosen using the routine cublasSetAtomicsMode(). In that case, the results are not guaranteed to be bit-wise reproducible because atomics are used for the computation.

2.1.5. Scalar Parameters

There are two categories of the functions that use scalar parameters :

  • Functions that take alpha and/or beta parameters by reference on the host or the device as scaling factors, such as gemm.

  • Functions that return a scalar result on the host or the device such as amax(), amin, asum(), rotg(), rotmg(), dot() and nrm2().

For the functions of the first category, when the pointer mode is set to CUBLAS_POINTER_MODE_HOST, the scalar parameters alpha and/or beta can be on the stack or allocated on the heap, shouldn’t be placed in managed memory. Underneath, the CUDA kernels related to those functions will be launched with the value of alpha and/or beta. Therefore if they were allocated on the heap, they can be freed just after the return of the call even though the kernel launch is asynchronous. When the pointer mode is set to CUBLAS_POINTER_MODE_DEVICE, alpha and/or beta must be accessible on the device and their values should not be modified until the kernel is done. Note that since cudaFree() does an implicit cudaDeviceSynchronize(), cudaFree() can still be called on alpha and/or beta just after the call but it would defeat the purpose of using this pointer mode in that case.

For the functions of the second category, when the pointer mode is set to CUBLAS_POINTER_MODE_HOST, these functions block the CPU, until the GPU has completed its computation and the results have been copied back to the Host. When the pointer mode is set to CUBLAS_POINTER_MODE_DEVICE, these functions return immediately. In this case, similar to matrix and vector results, the scalar result is ready only when execution of the routine on the GPU has completed. This requires proper synchronization in order to read the result from the host.

In either case, the pointer mode CUBLAS_POINTER_MODE_DEVICE allows the library functions to execute completely asynchronously from the Host even when alpha and/or beta are generated by a previous kernel. For example, this situation can arise when iterative methods for solution of linear systems and eigenvalue problems are implemented using the cuBLAS library.

2.1.6. Parallelism with Streams

If the application uses the results computed by multiple independent tasks, CUDA™ streams can be used to overlap the computation performed in these tasks.

The application can conceptually associate each stream with each task. In order to achieve the overlap of computation between the tasks, the user should create CUDA™ streams using the function cudaStreamCreate() and set the stream to be used by each individual cuBLAS library routine by calling cublasSetStream() just before calling the actual cuBLAS routine. Note that cublasSetStream() resets the user-provided workspace to the default workspace pool; see cublasSetWorkspace(). Then, the computation performed in separate streams would be overlapped automatically when possible on the GPU. This approach is especially useful when the computation performed by a single task is relatively small and is not enough to fill the GPU with work.

We recommend using the new cuBLAS API with scalar parameters and results passed by reference in the device memory to achieve maximum overlap of the computation when using streams.

A particular application of streams, batching of multiple small kernels, is described in the following section.

2.1.7. Batching Kernels

In this section, we explain how to use streams to batch the execution of small kernels. For instance, suppose that we have an application where we need to make many small independent matrix-matrix multiplications with dense matrices.

It is clear that even with millions of small independent matrices we will not be able to achieve the same GFLOPS rate as with a one large matrix. For example, a single \(n \times n\) large matrix-matrix multiplication performs \(n^{3}\) operations for \(n^{2}\) input size, while 1024 \(\frac{n}{32} \times \frac{n}{32}\) small matrix-matrix multiplications perform \(1024\left( \frac{n}{32} \right)^{3} = \frac{n^{3}}{32}\) operations for the same input size. However, it is also clear that we can achieve a significantly better performance with many small independent matrices compared with a single small matrix.

The architecture family of GPUs allows us to execute multiple kernels simultaneously. Hence, in order to batch the execution of independent kernels, we can run each of them in a separate stream. In particular, in the above example we could create 1024 CUDA™ streams using the function cudaStreamCreate(), then preface each call to cublas<t>gemm() with a call to cublasSetStream() with a different stream for each of the matrix-matrix multiplications (note that cublasSetStream() resets user-provided workspace to the default workspace pool, see cublasSetWorkspace()). This will ensure that when possible the different computations will be executed concurrently. Although the user can create many streams, in practice it is not possible to have more than 32 concurrent kernels executing at the same time.

2.1.8. Cache Configuration

On some devices, L1 cache and shared memory use the same hardware resources. The cache configuration can be set directly with the CUDA Runtime function cudaDeviceSetCacheConfig. The cache configuration can also be set specifically for some functions using the routine cudaFuncSetCacheConfig. Please refer to the CUDA Runtime API documentation for details about the cache configuration settings.

Because switching from one configuration to another can affect kernels concurrency, the cuBLAS Library does not set any cache configuration preference and relies on the current setting. However, some cuBLAS routines, especially Level-3 routines, rely heavily on shared memory. Thus the cache preference setting might affect adversely their performance.

2.1.9. Static Library Support

The cuBLAS Library is also delivered in a static form as libcublas_static.a on Linux. The static cuBLAS library and all other static math libraries depend on a common thread abstraction layer library called libculibos.a.

For example, on Linux, to compile a small application using cuBLAS, against the dynamic library, the following command can be used:

nvcc myCublasApp.c  -lcublas  -o myCublasApp

Whereas to compile against the static cuBLAS library, the following command must be used:

nvcc myCublasApp.c  -lcublas_static   -lculibos -o myCublasApp

It is also possible to use the native Host C++ compiler. Depending on the Host operating system, some additional libraries like pthread or dl might be needed on the linking line. The following command on Linux is suggested :

g++ myCublasApp.c  -lcublas_static   -lculibos -lcudart_static -lpthread -ldl -I <cuda-toolkit-path>/include -L <cuda-toolkit-path>/lib64 -o myCublasApp

Note that in the latter case, the library cuda is not needed. The CUDA Runtime will try to open explicitly the cuda library if needed. In the case of a system which does not have the CUDA driver installed, this allows the application to gracefully manage this issue and potentially run if a CPU-only path is available.

Starting with release 11.2, using the typed functions instead of the extension functions (cublas**Ex()) helps in reducing the binary size when linking to static cuBLAS Library.

2.1.10. GEMM Algorithms Numerical Behavior

Some GEMM algorithms split the computation along the dimension K to increase the GPU occupancy, especially when the dimension K is large compared to dimensions M and N. When this type of algorithm is chosen by the cuBLAS heuristics or explicitly by the user, the results of each split is summed deterministically into the resulting matrix to get the final result.

For the routines cublas<t>gemmEx and cublasGemmEx(), when the compute type is greater than the output type, the sum of the split chunks can potentially lead to some intermediate overflows thus producing a final resulting matrix with some overflows. Those overflows might not have occurred if all the dot products had been accumulated in the compute type before being converted at the end in the output type. This computation side-effect can be easily exposed when the computeType is CUDA_R_32F and Atype, Btype and Ctype are in CUDA_R_16F. This behavior can be controlled using the compute precision mode CUBLAS_MATH_DISALLOW_REDUCED_PRECISION_REDUCTION with cublasSetMathMode()

2.1.11. Tensor Core Usage

Tensor cores were first introduced with Volta GPUs (compute capability 7.0 and above) and significantly accelerate matrix multiplications. Starting with cuBLAS version 11.0.0, the library will automatically make use of Tensor Core capabilities wherever possible, unless they are explicitly disabled by selecting pedantic compute modes in cuBLAS (see cublasSetMathMode(), cublasMath_t).

It should be noted that the library will pick a Tensor Core enabled implementation wherever it determines that it would provide the best performance.

Starting with cuBLAS version 11.0.0 there are no longer any restriction on matrix dimensions and memory alignments to use Tensor Cores. However, the best performance when using Tensor Cores can be achieved when the matrix dimensions and pointers meet certain memory alignment requirements. Specifically, all of the following conditions must be satisfied to get the most performance out of Tensor Cores:

  • m % 8 == 0

  • k % 8 == 0

  • op_B == CUBLAS_OP_N || n%8 == 0

  • intptr_t(A) % 16 == 0

  • intptr_t(B) % 16 == 0

  • intptr_t(C) % 16 == 0

  • intptr_t(A+lda) % 16 == 0

  • intptr_t(B+ldb) % 16 == 0

  • intptr_t(C+ldc) % 16 == 0

2.1.12. CUDA Graphs Support

cuBLAS routines can be captured in CUDA Graph stream capture without restrictions in most situations.

The exception are routines that output results into host buffers (e.g. cublas<t>dot while pointer mode CUBLAS_POINTER_MODE_HOST is configured), as it enforces synchronization.

For input coefficients (such as alpha, beta) behavior depends on the pointer mode setting:

  • In the case of CUBLAS(LT)_POINTER_MODE_HOST, coefficient values are captured in the graph.

  • In the case of pointer modes with device pointers, coefficient value is accessed using the device pointer at the time of graph execution.

Note

When captured in CUDA Graph stream capture, cuBLAS routines can create memory nodes through the use of stream-ordered allocation APIs, cudaMallocAsync and cudaFreeAsync. However, as there is currently no support for memory nodes in child graphs or graphs launched from the device, attempts to capture cuBLAS routines in such scenarios may fail. To avoid this issue, use the cublasSetWorkspace() function to provide user-owned workspace memory.

2.1.13. 64-bit Integer Interface

cuBLAS version 12 introduced 64-bit integer capable functions. Each 64-bit integer function is equivalent to a 32-bit integer function with the following changes:

  • The function name has _64 suffix.

  • The dimension (problem size) data type changed from int to int64_t. Examples of dimension: m, n, and k.

  • The leading dimension data type changed from int to int64_t. Examples of leading dimension: lda, ldb, and ldc.

  • The vector increment data type changed from int to int64_t. Examples of vector increment: incx and incy.

For example, consider the following 32-bit integer functions:

cublasStatus_t cublasSetMatrix(int rows, int cols, int elemSize, const void *A, int lda, void *B, int ldb);
cublasStatus_t cublasIsamax(cublasHandle_t handle, int n, const float *x, int incx, int *result);
cublasStatus_t cublasSsyr(cublasHandle_t handle, cublasFillMode_t uplo, int n, const float *alpha, const float *x, int incx, float *A, int lda);

The equivalent 64-bit integer functions are:

cublasStatus_t cublasSetMatrix_64(int64_t rows, int64_t cols, int64_t elemSize, const void *A, int64_t lda, void *B, int64_t ldb);
cublasStatus_t cublasIsamax_64(cublasHandle_t handle, int64_t n, const float *x, int64_t incx, int64_t *result);
cublasStatus_t cublasSsyr_64(cublasHandle_t handle, cublasFillMode_t uplo, int64_t n, const float *alpha, const float *x, int64_t incx, float *A, int64_t lda);

Not every function has a 64-bit integer equivalent. For instance, cublasSetMathMode() doesn’t have any arguments that could meaningfully be int64_t. For documentation brevity, the 64-bit integer APIs are not explicitly listed, but only mentioned that they exist for the relevant functions.

2.2. cuBLAS Datatypes Reference

2.2.1. cublasHandle_t

The cublasHandle_t type is a pointer type to an opaque structure holding the cuBLAS library context. The cuBLAS library context must be initialized using cublasCreate() and the returned handle must be passed to all subsequent library function calls. The context should be destroyed at the end using cublasDestroy().

2.2.2. cublasStatus_t

The type is used for function status returns. All cuBLAS library functions return their status, which can have the following values.

Value

Meaning

CUBLAS_STATUS_SUCCESS

The operation completed successfully.

CUBLAS_STATUS_NOT_INITIALIZED

The cuBLAS library was not initialized. This is usually caused by the lack of a prior cublasCreate() call, an error in the CUDA Runtime API called by the cuBLAS routine, or an error in the hardware setup.

To correct: call cublasCreate() before the function call; and check that the hardware, an appropriate version of the driver, and the cuBLAS library are correctly installed.

CUBLAS_STATUS_ALLOC_FAILED

Resource allocation failed inside the cuBLAS library. This is usually caused by a cudaMalloc() failure.

To correct: prior to the function call, deallocate previously allocated memory as much as possible.

CUBLAS_STATUS_INVALID_VALUE

An unsupported value or parameter was passed to the function (a negative vector size, for example).

To correct: ensure that all the parameters being passed have valid values.

CUBLAS_STATUS_ARCH_MISMATCH

The function requires a feature absent from the device architecture; usually caused by compute capability lower than 5.0.

To correct: compile and run the application on a device with appropriate compute capability.

CUBLAS_STATUS_MAPPING_ERROR

An access to GPU memory space failed, which is usually caused by a failure to bind a texture.

To correct: before the function call, unbind any previously bound textures.

CUBLAS_STATUS_EXECUTION_FAILED

The GPU program failed to execute. This is often caused by a launch failure of the kernel on the GPU, which can be caused by multiple reasons.

To correct: check that the hardware, an appropriate version of the driver, and the cuBLAS library are correctly installed.

CUBLAS_STATUS_INTERNAL_ERROR

An internal cuBLAS operation failed. This error is usually caused by a cudaMemcpyAsync() failure.

To correct: check that the hardware, an appropriate version of the driver, and the cuBLAS library are correctly installed. Also, check that the memory passed as a parameter to the routine is not being deallocated prior to the routine’s completion.

CUBLAS_STATUS_NOT_SUPPORTED

The functionality requested is not supported.

CUBLAS_STATUS_LICENSE_ERROR

The functionality requested requires some license and an error was detected when trying to check the current licensing. This error can happen if the license is not present or is expired or if the environment variable NVIDIA_LICENSE_FILE is not set properly.

2.2.3. cublasOperation_t

The cublasOperation_t type indicates which operation needs to be performed with the dense matrix. Its values correspond to Fortran characters ‘N’ or ‘n’ (non-transpose), ‘T’ or ‘t’ (transpose) and ‘C’ or ‘c’ (conjugate transpose) that are often used as parameters to legacy BLAS implementations.

Value

Meaning

CUBLAS_OP_N

The non-transpose operation is selected.

CUBLAS_OP_T

The transpose operation is selected.

CUBLAS_OP_C

The conjugate transpose operation is selected.

2.2.4. cublasFillMode_t

The type indicates which part (lower or upper) of the dense matrix was filled and consequently should be used by the function. Its values correspond to Fortran characters L or l (lower) and U or u (upper) that are often used as parameters to legacy BLAS implementations.

Value

Meaning

CUBLAS_FILL_MODE_LOWER

The lower part of the matrix is filled.

CUBLAS_FILL_MODE_UPPER

The upper part of the matrix is filled.

CUBLAS_FILL_MODE_FULL

The full matrix is filled.

2.2.5. cublasDiagType_t

The type indicates whether the main diagonal of the dense matrix is unity and consequently should not be touched or modified by the function. Its values correspond to Fortran characters ‘N’ or ‘n’ (non-unit) and ‘U’ or ‘u’ (unit) that are often used as parameters to legacy BLAS implementations.

Value

Meaning

CUBLAS_DIAG_NON_UNIT

The matrix diagonal has non-unit elements.

CUBLAS_DIAG_UNIT

The matrix diagonal has unit elements.

2.2.6. cublasSideMode_t

The type indicates whether the dense matrix is on the left or right side in the matrix equation solved by a particular function. Its values correspond to Fortran characters ‘L’ or ‘l’ (left) and ‘R’ or ‘r’ (right) that are often used as parameters to legacy BLAS implementations.

Value

Meaning

CUBLAS_SIDE_LEFT

The matrix is on the left side in the equation.

CUBLAS_SIDE_RIGHT

The matrix is on the right side in the equation.

2.2.7. cublasPointerMode_t

The cublasPointerMode_t type indicates whether the scalar values are passed by reference on the host or device. It is important to point out that if several scalar values are present in the function call, all of them must conform to the same single pointer mode. The pointer mode can be set and retrieved using cublasSetPointerMode() and cublasGetPointerMode() routines, respectively.

Value

Meaning

CUBLAS_POINTER_MODE_HOST

The scalars are passed by reference on the host.

CUBLAS_POINTER_MODE_DEVICE

The scalars are passed by reference on the device.

2.2.8. cublasAtomicsMode_t

The type indicates whether cuBLAS routines which has an alternate implementation using atomics can be used. The atomics mode can be set and queried using cublasSetAtomicsMode() and cublasGetAtomicsMode() and routines, respectively.

Value

Meaning

CUBLAS_ATOMICS_NOT_ALLOWED

The usage of atomics is not allowed.

CUBLAS_ATOMICS_ALLOWED

The usage of atomics is allowed.

2.2.9. cublasGemmAlgo_t

cublasGemmAlgo_t type is an enumerant to specify the algorithm for matrix-matrix multiplication on GPU architectures up to sm_75. On sm_80 and newer GPU architectures, this enumarant has no effect. cuBLAS has the following algorithm options:

Value

Meaning

CUBLAS_GEMM_DEFAULT

Apply Heuristics to select the GEMM algorithm

CUBLAS_GEMM_ALGO0 to CUBLAS_GEMM_ALGO23

Explicitly choose an Algorithm [0,23]. Note: Doesn’t have effect on NVIDIA Ampere architecture GPUs and newer.

CUBLAS_GEMM_DEFAULT_TENSOR_OP[DEPRECATED]

This mode is deprecated and will be removed in a future release. Apply Heuristics to select the GEMM algorithm, while allowing use of reduced precision CUBLAS_COMPUTE_32F_FAST_16F kernels (for backward compatibility).

CUBLAS_GEMM_ALGO0_TENSOR_OP to CUBLAS_GEMM_ALGO15_TENSOR_OP[DEPRECATED]

Those values are deprecated and will be removed in a future release. Explicitly choose a Tensor core GEMM Algorithm [0,15]. Allows use of reduced precision CUBLAS_COMPUTE_32F_FAST_16F kernels (for backward compatibility). Note: Doesn’t have effect on NVIDIA Ampere architecture GPUs and newer.

2.2.10. cublasMath_t

cublasMath_t enumerate type is used in cublasSetMathMode() to choose compute precision modes as defined in the following table. Since this setting does not directly control the use of Tensor Cores, the mode CUBLAS_TENSOR_OP_MATH is being deprecated, and will be removed in a future release.

Value

Meaning

CUBLAS_DEFAULT_MATH

This is the default and highest-performance mode that uses compute and intermediate storage precisions with at least the same number of mantissa and exponent bits as requested. Tensor Cores will be used whenever possible.

CUBLAS_PEDANTIC_MATH

This mode uses the prescribed precision and standardized arithmetic for all phases of calculations and is primarily intended for numerical robustness studies, testing, and debugging. This mode might not be as performant as the other modes.

CUBLAS_TF32_TENSOR_OP_MATH

Enable acceleration of single-precision routines using TF32 tensor cores.

CUBLAS_MATH_DISALLOW_REDUCED_PRECISION_REDUCTION

Forces any reductions during matrix multiplications to use the accumulator type (that is, compute type) and not the output type in case of mixed precision routines where output type precision is less than the compute type precision. This is a flag that can be set (using a bitwise or operation) alongside any of the other values.

CUBLAS_TENSOR_OP_MATH [DEPRECATED]

This mode is deprecated and will be removed in a future release. Allows the library to use Tensor Core operations whenever possible. For single precision GEMM routines cuBLAS will use the CUBLAS_COMPUTE_32F_FAST_16F compute type.

2.2.11. cublasComputeType_t

cublasComputeType_t enumerate type is used in cublasGemmEx() and cublasLtMatmul() (including all batched and strided batched variants) to choose compute precision modes as defined below.

Value

Meaning

CUBLAS_COMPUTE_16F

This is the default and highest-performance mode for 16-bit half precision floating point and all compute and intermediate storage precisions with at least 16-bit half precision. Tensor Cores will be used whenever possible.

CUBLAS_COMPUTE_16F_PEDANTIC

This mode uses 16-bit half precision floating point standardized arithmetic for all phases of calculations and is primarily intended for numerical robustness studies, testing, and debugging. This mode might not be as performant as the other modes since it disables use of tensor cores.

CUBLAS_COMPUTE_32F

This is the default 32-bit single precision floating point and uses compute and intermediate storage precisions of at least 32-bits.

CUBLAS_COMPUTE_32F_PEDANTIC

Uses 32-bit single precision floatin point arithmetic for all phases of calculations and also disables algorithmic optimizations such as Gaussian complexity reduction (3M).

CUBLAS_COMPUTE_32F_FAST_16F

Allows the library to use Tensor Cores with automatic down-conversion and 16-bit half-precision compute for 32-bit input and output matrices.

CUBLAS_COMPUTE_32F_FAST_16BF

Allows the library to use Tensor Cores with automatic down-convesion and bfloat16 compute for 32-bit input and output matrices. See Alternate Floating Point section for more details on bfloat16.

CUBLAS_COMPUTE_32F_FAST_TF32

Allows the library to use Tensor Cores with TF32 compute for 32-bit input and output matrices. See Alternate Floating Point section for more details on TF32 compute.

CUBLAS_COMPUTE_64F

This is the default 64-bit double precision floating point and uses compute and intermediate storage precisions of at least 64-bits.

CUBLAS_COMPUTE_64F_PEDANTIC

Uses 64-bit double precision floatin point arithmetic for all phases of calculations and also disables algorithmic optimizations such as Gaussian complexity reduction (3M).

CUBLAS_COMPUTE_32I

This is the default 32-bit integer mode and uses compute and intermediate storage precisions of at least 32-bits.

CUBLAS_COMPUTE_32I_PEDANTIC

Uses 32-bit integer arithmetic for all phases of calculations.

Note

Setting the environment variable NVIDIA_TF32_OVERRIDE = 0 will override any defaults or programmatic configuration of NVIDIA libraries, and consequently, cuBLAS will not accelerate FP32 computations with TF32 tensor cores.

2.3. CUDA Datatypes Reference

The chapter describes types shared by multiple CUDA Libraries and defined in the header file library_types.h.

2.3.1. cudaDataType_t

The cudaDataType_t type is an enumerant to specify the data precision. It is used when the data reference does not carry the type itself (e.g void *)

For example, it is used in the routine cublasSgemmEx().

Value

Meaning

CUDA_R_16F

the data type is a 16-bit real half precision floating-point

CUDA_C_16F

the data type is a 32-bit structure comprised of two half precision floating-points representing a complex number.

CUDA_R_16BF

the data type is a 16-bit real bfloat16 floating-point

CUDA_C_16BF

the data type is a 32-bit structure comprised of two bfloat16 floating-points representing a complex number.

CUDA_R_32F

the data type is a 32-bit real single precision floating-point

CUDA_C_32F

the data type is a 64-bit structure comprised of two single precision floating-points representing a complex number.

CUDA_R_64F

the data type is a 64-bit real double precision floating-point

CUDA_C_64F

the data type is a 128-bit structure comprised of two double precision floating-points representing a complex number.

CUDA_R_8I

the data type is a 8-bit real signed integer

CUDA_C_8I

the data type is a 16-bit structure comprised of two 8-bit signed integers representing a complex number.

CUDA_R_8U

the data type is a 8-bit real unsigned integer

CUDA_C_8U

the data type is a 16-bit structure comprised of two 8-bit unsigned integers representing a complex number.

CUDA_R_32I

the data type is a 32-bit real signed integer

CUDA_C_32I

the data type is a 64-bit structure comprised of two 32-bit signed integers representing a complex number.

CUDA_R_8F_E4M3

the data type is an 8-bit real floating point in E4M3 format

CUDA_R_8F_E5M2

the data type is an 8-bit real floating point in E5M2 format

2.3.2. libraryPropertyType_t

The libraryPropertyType_t is used as a parameter to specify which property is requested when using the routine cublasGetProperty()

Value

Meaning

MAJOR_VERSION

enumerant to query the major version

MINOR_VERSION

enumerant to query the minor version

PATCH_LEVEL

number to identify the patch level

2.4. cuBLAS Helper Function Reference

2.4.1. cublasCreate()

cublasStatus_t
cublasCreate(cublasHandle_t *handle)

This function initializes the cuBLAS library and creates a handle to an opaque structure holding the cuBLAS library context. It allocates hardware resources on the host and device and must be called prior to making any other cuBLAS library calls. The cuBLAS library context is tied to the current CUDA device. To use the library on multiple devices, one cuBLAS handle needs to be created for each device. Furthermore, for a given device, multiple cuBLAS handles with different configurations can be created. Because cublasCreate() allocates some internal resources and the release of those resources by calling cublasDestroy() will implicitly call cudaDeviceSynchronize(), it is recommended to minimize the number of times these functions are called. For multi-threaded applications that use the same device from different threads, the recommended programming model is to create one cuBLAS handle per thread and use that cuBLAS handle for the entire life of the thread.

Return Value

Meaning

CUBLAS_STATUS_SUCCESS

the initialization succeeded

CUBLAS_STATUS_NOT_INITIALIZED

the CUDA™ Runtime initialization failed

CUBLAS_STATUS_ALLOC_FAILED

the resources could not be allocated

CUBLAS_STATUS_INVALID_VALUE

handle == NULL

2.4.2. cublasDestroy()

cublasStatus_t
cublasDestroy(cublasHandle_t handle)

This function releases hardware resources used by the cuBLAS library. This function is usually the last call with a particular handle to the cuBLAS library. Because cublasCreate() allocates some internal resources and the release of those resources by calling cublasDestroy() will implicitly call cudaDeviceSynchronize(), it is recommended to minimize the number of times these functions are called.

Return Value

Meaning

CUBLAS_STATUS_SUCCESS

the shut down succeeded

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

2.4.3. cublasGetVersion()

cublasStatus_t
cublasGetVersion(cublasHandle_t handle, int *version)

This function returns the version number of the cuBLAS library.

Return Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_INVALID_VALUE

the provided storage for library version number is not initialized (NULL)

Note

This function can be safely called with the handle set to NULL. This allows users to get the version of the library without a handle. Another way to do this is with cublasGetProperty().

2.4.4. cublasGetProperty()

cublasStatus_t
cublasGetProperty(libraryPropertyType type, int *value)

This function returns the value of the requested property in memory pointed to by value. Refer to libraryPropertyType for supported types.

Return Value

Meaning

CUBLAS_STATUS_SUCCESS

The operation completed successfully

CUBLAS_STATUS_INVALID_VALUE

Invalid type value

  • If invalid type value or

  • value == NULL

2.4.5. cublasGetStatusName()

const char* cublasGetStatusName(cublasStatus_t status)

This function returns the string representation of a given status.

Return Value

Meaning

NULL-terminated string

The string representation of the status

2.4.6. cublasGetStatusString()

const char* cublasGetStatusString(cublasStatus_t status)

This function returns the description string for a given status.

Return Value

Meaning

NULL-terminated string

The description of the status

2.4.7. cublasSetStream()

cublasStatus_t
cublasSetStream(cublasHandle_t handle, cudaStream_t streamId)

This function sets the cuBLAS library stream, which will be used to execute all subsequent calls to the cuBLAS library functions. If the cuBLAS library stream is not set, all kernels use the default NULL stream. In particular, this routine can be used to change the stream between kernel launches and then to reset the cuBLAS library stream back to NULL. Additionally this function unconditionally resets the cuBLAS library workspace back to the default workspace pool (see cublasSetWorkspace()).

Return Value

Meaning

CUBLAS_STATUS_SUCCESS

the stream was set successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

2.4.8. cublasSetWorkspace()

cublasStatus_t
cublasSetWorkspace(cublasHandle_t handle, void *workspace, size_t workspaceSizeInBytes)

This function sets the cuBLAS library workspace to a user-owned device buffer, which will be used to execute all subsequent calls to the cuBLAS library functions (on the currently set stream). If the cuBLAS library workspace is not set, all kernels will use the default workspace pool allocated during the cuBLAS context creation. In particular, this routine can be used to change the workspace between kernel launches. The workspace pointer has to be aligned to at least 256 bytes, otherwise CUBLAS_STATUS_INVALID_VALUE error is returned. The cublasSetStream() function unconditionally resets the cuBLAS library workspace back to the default workspace pool. Calling this function, including with workspaceSizeInBytes equal to 0, will prevent the cuBLAS library from utilizing the default workspace. Too small workspaceSizeInBytes may cause some routines to fail with CUBLAS_STATUS_ALLOC_FAILED error returned or cause large regressions in performance. Workspace size equal to or larger than 16KiB is enough to prevent CUBLAS_STATUS_ALLOC_FAILED error, while a larger workspace can provide performance benefits for some routines.

The table below shows the recommended size of user-provided workspace. This is based on the cuBLAS default workspace pool size which is GPU architecture dependent.

GPU Architecture

Recommended workspace size

NVIDIA Hopper Architecture

32 MiB

Other

4 MiB

The possible error values returned by this function and their meanings are listed below.

Return Value

Meaning

CUBLAS_STATUS_SUCCESS

the stream was set successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

the workspace pointer wasn’t aligned to at least 256 bytes

2.4.9. cublasGetStream()

cublasStatus_t
cublasGetStream(cublasHandle_t handle, cudaStream_t *streamId)

This function gets the cuBLAS library stream, which is being used to execute all calls to the cuBLAS library functions. If the cuBLAS library stream is not set, all kernels use the default NULL stream.

Return Value

Meaning

CUBLAS_STATUS_SUCCESS

the stream was returned successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

streamId == NULL

2.4.10. cublasGetPointerMode()

cublasStatus_t
cublasGetPointerMode(cublasHandle_t handle, cublasPointerMode_t *mode)

This function obtains the pointer mode used by the cuBLAS library. Please see the section on the cublasPointerMode_t type for more details.

Return Value

Meaning

CUBLAS_STATUS_SUCCESS

the pointer mode was obtained successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

mode == NULL

2.4.11. cublasSetPointerMode()

cublasStatus_t
cublasSetPointerMode(cublasHandle_t handle, cublasPointerMode_t mode)

This function sets the pointer mode used by the cuBLAS library. The default is for the values to be passed by reference on the host. Please see the section on the cublasPointerMode_t type for more details.

Return Value

Meaning

CUBLAS_STATUS_SUCCESS

the pointer mode was set successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

mode is not CUBLAS_POINTER_MODE_HOST or CUBLAS_POINTER_MODE_DEVICE

2.4.12. cublasSetVector()

cublasStatus_t
cublasSetVector(int n, int elemSize,
                const void *x, int incx, void *y, int incy)

This function supports the 64-bit Integer Interface.

This function copies n elements from a vector x in host memory space to a vector y in GPU memory space. Elements in both vectors are assumed to have a size of elemSize bytes. The storage spacing between consecutive elements is given by incx for the source vector x and by incy for the destination vector y.

Since column-major format for two-dimensional matrices is assumed, if a vector is part of a matrix, a vector increment equal to 1 accesses a (partial) column of that matrix. Similarly, using an increment equal to the leading dimension of the matrix results in accesses to a (partial) row of that matrix.

Return Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_INVALID_VALUE

the parameters incx, incy, elemSize<=0

CUBLAS_STATUS_MAPPING_ERROR

there was an error accessing GPU memory

2.4.13. cublasGetVector()

cublasStatus_t
cublasGetVector(int n, int elemSize,
                const void *x, int incx, void *y, int incy)

This function supports the 64-bit Integer Interface.

This function copies n elements from a vector x in GPU memory space to a vector y in host memory space. Elements in both vectors are assumed to have a size of elemSize bytes. The storage spacing between consecutive elements is given by incx for the source vector and incy for the destination vector y.

Since column-major format for two-dimensional matrices is assumed, if a vector is part of a matrix, a vector increment equal to 1 accesses a (partial) column of that matrix. Similarly, using an increment equal to the leading dimension of the matrix results in accesses to a (partial) row of that matrix.

Return Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_INVALID_VALUE

the parameters incx, incy, elemSize<=0

CUBLAS_STATUS_MAPPING_ERROR

there was an error accessing GPU memory

2.4.14. cublasSetMatrix()

cublasStatus_t
cublasSetMatrix(int rows, int cols, int elemSize,
                const void *A, int lda, void *B, int ldb)

This function supports the 64-bit Integer Interface.

This function copies a tile of rows x cols elements from a matrix A in host memory space to a matrix B in GPU memory space. It is assumed that each element requires storage of elemSize bytes and that both matrices are stored in column-major format, with the leading dimension of the source matrix A and destination matrix B given in lda and ldb, respectively. The leading dimension indicates the number of rows of the allocated matrix, even if only a submatrix of it is being used.

Return Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_INVALID_VALUE

the parameters rows, cols<0 or elemSize, lda, ldb<=0

CUBLAS_STATUS_MAPPING_ERROR

there was an error accessing GPU memory

2.4.15. cublasGetMatrix()

cublasStatus_t
cublasGetMatrix(int rows, int cols, int elemSize,
                const void *A, int lda, void *B, int ldb)

This function supports the 64-bit Integer Interface.

This function copies a tile of rows x cols elements from a matrix A in GPU memory space to a matrix B in host memory space. It is assumed that each element requires storage of elemSize bytes and that both matrices are stored in column-major format, with the leading dimension of the source matrix A and destination matrix B given in lda and ldb, respectively. The leading dimension indicates the number of rows of the allocated matrix, even if only a submatrix of it is being used.

Return Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_INVALID_VALUE

the parameters rows, cols<0 or elemSize, lda, ldb<=0

CUBLAS_STATUS_MAPPING_ERROR

there was an error accessing GPU memory

2.4.16. cublasSetVectorAsync()

cublasStatus_t
cublasSetVectorAsync(int n, int elemSize, const void *hostPtr, int incx,
                     void *devicePtr, int incy, cudaStream_t stream)

This function supports the 64-bit Integer Interface.

This function has the same functionality as cublasSetVector(), with the exception that the data transfer is done asynchronously (with respect to the host) using the given CUDA™ stream parameter.

Return Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_INVALID_VALUE

the parameters incx, incy, elemSize<=0

CUBLAS_STATUS_MAPPING_ERROR

there was an error accessing GPU memory

2.4.17. cublasGetVectorAsync()

cublasStatus_t
cublasGetVectorAsync(int n, int elemSize, const void *devicePtr, int incx,
                     void *hostPtr, int incy, cudaStream_t stream)

This function supports the 64-bit Integer Interface.

This function has the same functionality as cublasGetVector(), with the exception that the data transfer is done asynchronously (with respect to the host) using the given CUDA™ stream parameter.

Return Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_INVALID_VALUE

the parameters incx, incy, elemSize<=0

CUBLAS_STATUS_MAPPING_ERROR

there was an error accessing GPU memory

2.4.18. cublasSetMatrixAsync()

cublasStatus_t
cublasSetMatrixAsync(int rows, int cols, int elemSize, const void *A,
                     int lda, void *B, int ldb, cudaStream_t stream)

This function supports the 64-bit Integer Interface.

This function has the same functionality as cublasSetMatrix(), with the exception that the data transfer is done asynchronously (with respect to the host) using the given CUDA™ stream parameter.

Return Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_INVALID_VALUE

the parameters rows, cols<0 or elemSize, lda, ldb<=0

CUBLAS_STATUS_MAPPING_ERROR

there was an error accessing GPU memory

2.4.19. cublasGetMatrixAsync()

cublasStatus_t
cublasGetMatrixAsync(int rows, int cols, int elemSize, const void *A,
                     int lda, void *B, int ldb, cudaStream_t stream)

This function supports the 64-bit Integer Interface.

This function has the same functionality as cublasGetMatrix(), with the exception that the data transfer is done asynchronously (with respect to the host) using the given CUDA™ stream parameter.

Return Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_INVALID_VALUE

the parameters rows, cols<0 or elemSize, lda, ldb<=0

CUBLAS_STATUS_MAPPING_ERROR

there was an error accessing GPU memory

2.4.20. cublasSetAtomicsMode()

cublasStatus_t cublasSetAtomicsMode(cublasHandlet handle, cublasAtomicsMode_t mode)

Some routines like cublas<t>symv and cublas<t>hemv have an alternate implementation that use atomics to cumulate results. This implementation is generally significantly faster but can generate results that are not strictly identical from one run to the others. Mathematically, those different results are not significant but when debugging those differences can be prejudicial.

This function allows or disallows the usage of atomics in the cuBLAS library for all routines which have an alternate implementation. When not explicitly specified in the documentation of any cuBLAS routine, it means that this routine does not have an alternate implementation that use atomics. When atomics mode is disabled, each cuBLAS routine should produce the same results from one run to the other when called with identical parameters on the same Hardware.

The default atomics mode of default initialized cublasHandle_t object is CUBLAS_ATOMICS_NOT_ALLOWED. Please see the section on the type for more details.

Return Value

Meaning

CUBLAS_STATUS_SUCCESS

the atomics mode was set successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

2.4.21. cublasGetAtomicsMode()

cublasStatus_t cublasGetAtomicsMode(cublasHandle_t handle, cublasAtomicsMode_t *mode)

This function queries the atomic mode of a specific cuBLAS context.

The default atomics mode of default initialized cublasHandle_t object is CUBLAS_ATOMICS_NOT_ALLOWED. Please see the section on the type for more details.

Return Value

Meaning

CUBLAS_STATUS_SUCCESS

the atomics mode was queried successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

the argument mode is a NULL pointer

2.4.22. cublasSetMathMode()

cublasStatus_t cublasSetMathMode(cublasHandle_t handle, cublasMath_t mode)

The cublasSetMathMode() function enables you to choose the compute precision modes as defined by cublasMath_t. Users are allowed to set the compute precision mode as a logical combination of them (except the deprecated CUBLAS_TENSOR_OP_MATH). For example, cublasSetMathMode(handle, CUBLAS_DEFAULT_MATH | CUBLAS_MATH_DISALLOW_REDUCED_PRECISION_REDUCTION). Please note that the default math mode is CUBLAS_DEFAULT_MATH.

For matrix and compute precisions allowed for cublasGemmEx() and cublasLtMatmul() APIs and their strided variants please refer to: cublasGemmEx() , cublasGemmBatchedEx(), cublasGemmStridedBatchedEx(), and cublasLtMatmul().

Return Value

Meaning

CUBLAS_STATUS_SUCCESS

the math mode was set successfully.

CUBLAS_STATUS_INVALID_VALUE

an invalid value for mode was specified.

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized.

2.4.23. cublasGetMathMode()

cublasStatus_t cublasGetMathMode(cublasHandle_t handle, cublasMath_t *mode)

This function returns the math mode used by the library routines.

Return Value

Meaning

CUBLAS_STATUS_SUCCESS

the math type was returned successfully.

CUBLAS_STATUS_INVALID_VALUE

if mode is NULL.

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized.

2.4.24. cublasSetSmCountTarget()

cublasStatus_t cublasSetSmCountTarget(cublasHandle_t handle, int smCountTarget)

The cublasSetSmCountTarget() function allows overriding the number of multiprocessors available to the library during kernels execution.

This option can be used to improve the library performance when cuBLAS routines are known to run concurrently with other work on different CUDA streams. E.g. a NVIDIA A100 GPU has 108 SM and there is a concurrent kenrel running with grid size of 8, one can use cublasSetSmCountTarget() with value 100 to override the library heuristics to optimize for running on 100 multiprocessors.

When set to 0 the library returns to its default behavior. The input value should not exceed the device’s multiprocessor count, which can be obtained using cudaDeviceGetAttribute. Negative values are not accepted.

The user must ensure thread safety when modifying the library handle with this routine similar to when using cublasSetStream(), etc.

Return Value

Meaning

CUBLAS_STATUS_SUCCESS

SM count target was set successfully.

CUBLAS_STATUS_INVALID_VALUE

the value of smCountTarget outside of the allowed range.

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized.

2.4.25. cublasGetSmCountTarget()

cublasStatus_t cublasGetSmCountTarget(cublasHandle_t handle, int *smCountTarget)

This function obtains the value previously programmed to the library handle.

Return Value

Meaning

CUBLAS_STATUS_SUCCESS

SM count target was set successfully.

CUBLAS_STATUS_INVALID_VALUE

smCountTarget is NULL.

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized.

2.4.26. cublasLoggerConfigure()

cublasStatus_t cublasLoggerConfigure(
    int             logIsOn,
    int             logToStdOut,
    int             logToStdErr,
    const char*     logFileName)

This function configures logging during runtime. Besides this type of configuration, it is possible to configure logging with special environment variables which will be checked by libcublas:

  • CUBLAS_LOGINFO_DBG - Setup env. variable to “1” means turn on logging (by default logging is off).

  • CUBLAS_LOGDEST_DBG - Setup env. variable encodes how to log. “stdout”, “stderr” means to output log messages to stdout or stderr, respectively. In the other case, its specifies “filename” of file.

Parameters

logIsOn

Input. Turn on/off logging completely. By default is off, but is turned on by calling cublasSetLoggerCallback() to user defined callback function.

logToStdOut

Input. Turn on/off logging to standard output I/O stream. By default is off.

logToStdErr

Input. Turn on/off logging to standard error I/O stream. By default is off.

logFileName

Input. Turn on/off logging to file in filesystem specified by it’s name. cublasLoggerConfigure() copies the content of logFileName. You should provide null pointer if you are not interested in this type of logging.

Returns

CUBLAS_STATUS_SUCCESS

Success.

2.4.27. cublasGetLoggerCallback()

cublasStatus_t cublasGetLoggerCallback(
    cublasLogCallback* userCallback)

This function retrieves function pointer to previously installed custom user defined callback function via cublasSetLoggerCallback() or zero otherwise.

Parameters

userCallback

Output. Pointer to user defined callback function.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_INVALID_VALUE

userCallback is NULL

2.4.28. cublasSetLoggerCallback()

cublasStatus_t cublasSetLoggerCallback(
    cublasLogCallback   userCallback)

This function installs a custom user defined callback function via cublas C public API.

Parameters

userCallback

Input. Pointer to user defined callback function.

Returns

CUBLAS_STATUS_SUCCESS

Success.

2.5. cuBLAS Level-1 Function Reference

In this chapter we describe the Level-1 Basic Linear Algebra Subprograms (BLAS1) functions that perform scalar and vector based operations. We will use abbreviations <type> for type and <t> for the corresponding short type to make a more concise and clear presentation of the implemented functions. Unless otherwise specified <type> and <t> have the following meanings:

<type>

<t>

Meaning

float

‘s’ or ‘S’

real single-precision

double

‘d’ or ‘D’

real double-precision

cuComplex

‘c’ or ‘C’

complex single-precision

cuDoubleComplex

‘z’ or ‘Z’

complex double-precision

When the parameters and returned values of the function differ, which sometimes happens for complex input, the <t> can also have the following meanings Sc, Cs, Dz and Zd.

The abbreviation \(\mathbf{Re}(\cdot)\) and \(\mathbf{Im}(\cdot)\) will stand for the real and imaginary part of a number, respectively. Since imaginary part of a real number does not exist, we will consider it to be zero and can usually simply discard it from the equation where it is being used. Also, the \(\bar{\alpha}\) will denote the complex conjugate of \(\alpha\) .

In general throughout the documentation, the lower case Greek symbols \(\alpha\) and \(\beta\) will denote scalars, lower case English letters in bold type \(\mathbf{x}\) and \(\mathbf{y}\) will denote vectors and capital English letters \(A\) , \(B\) and \(C\) will denote matrices.

2.5.1. cublasI<t>amax()

cublasStatus_t cublasIsamax(cublasHandle_t handle, int n,
                            const float *x, int incx, int *result)
cublasStatus_t cublasIdamax(cublasHandle_t handle, int n,
                            const double *x, int incx, int *result)
cublasStatus_t cublasIcamax(cublasHandle_t handle, int n,
                            const cuComplex *x, int incx, int *result)
cublasStatus_t cublasIzamax(cublasHandle_t handle, int n,
                            const cuDoubleComplex *x, int incx, int *result)

This function supports the 64-bit Integer Interface.

This function finds the (smallest) index of the element of the maximum magnitude. Hence, the result is the first \(i\) such that \(\left| \mathbf{Im}\left( {x\lbrack j\rbrack} \right) \middle| + \middle| \mathbf{Re}\left( {x\lbrack j\rbrack} \right) \right|\) is maximum for \(i = 1,\ldots,n\) and \(j = 1 + \left( {i - 1} \right)*\text{ incx}\) . Notice that the last equation reflects 1-based indexing used for compatibility with Fortran.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

n

input

number of elements in the vector x.

x

device

input

<type> vector with elements.

incx

input

stride between consecutive elements of x.

result

host or device

output

the resulting index, which is 0 if n,incx<=0.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_ALLOC_FAILED

the reduction buffer could not be allocated

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

CUBLAS_STATUS_INVALID_VALUE

result is NULL

For references please refer to:

isamax, idamax, icamax, izamax

2.5.2. cublasI<t>amin()

cublasStatus_t cublasIsamin(cublasHandle_t handle, int n,
                            const float *x, int incx, int *result)
cublasStatus_t cublasIdamin(cublasHandle_t handle, int n,
                            const double *x, int incx, int *result)
cublasStatus_t cublasIcamin(cublasHandle_t handle, int n,
                            const cuComplex *x, int incx, int *result)
cublasStatus_t cublasIzamin(cublasHandle_t handle, int n,
                            const cuDoubleComplex *x, int incx, int *result)

This function supports the 64-bit Integer Interface.

This function finds the (smallest) index of the element of the minimum magnitude. Hence, the result is the first \(i\) such that \(\left| \mathbf{Im}\left( {x\lbrack j\rbrack} \right) \middle| + \middle| \mathbf{Re}\left( {x\lbrack j\rbrack} \right) \right|\) is minimum for \(i = 1,\ldots,n\) and \(j = 1 + \left( {i - 1} \right)*\text{incx}\) Notice that the last equation reflects 1-based indexing used for compatibility with Fortran.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

n

input

number of elements in the vector x.

x

device

input

<type> vector with elements.

incx

input

stride between consecutive elements of x.

result

host or device

output

the resulting index, which is 0 if n,incx<=0.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_ALLOC_FAILED

the reduction buffer could not be allocated

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

CUBLAS_STATUS_INVALID_VALUE

result is NULL

For references please refer to:

isamin

2.5.3. cublas<t>asum()

cublasStatus_t  cublasSasum(cublasHandle_t handle, int n,
                            const float           *x, int incx, float  *result)
cublasStatus_t  cublasDasum(cublasHandle_t handle, int n,
                            const double          *x, int incx, double *result)
cublasStatus_t cublasScasum(cublasHandle_t handle, int n,
                            const cuComplex       *x, int incx, float  *result)
cublasStatus_t cublasDzasum(cublasHandle_t handle, int n,
                            const cuDoubleComplex *x, int incx, double *result)

This function supports the 64-bit Integer Interface.

This function computes the sum of the absolute values of the elements of vector x. Hence, the result is \(\left. \sum_{i = 1}^{n} \middle| \mathbf{Im}\left( {x\lbrack j\rbrack} \right) \middle| + \middle| \mathbf{Re}\left( {x\lbrack j\rbrack} \right) \right|\) where \(j = 1 + \left( {i - 1} \right)*\text{incx}\) . Notice that the last equation reflects 1-based indexing used for compatibility with Fortran.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

n

input

number of elements in the vector x.

x

device

input

<type> vector with elements.

incx

input

stride between consecutive elements of x.

result

host or device

output

the resulting index, which is 0.0 if n,incx<=0.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_ALLOC_FAILED

the reduction buffer could not be allocated

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

CUBLAS_STATUS_INVALID_VALUE

result is NULL

For references please refer to:

sasum, dasum, scasum, dzasum

2.5.4. cublas<t>axpy()

cublasStatus_t cublasSaxpy(cublasHandle_t handle, int n,
                           const float           *alpha,
                           const float           *x, int incx,
                           float                 *y, int incy)
cublasStatus_t cublasDaxpy(cublasHandle_t handle, int n,
                           const double          *alpha,
                           const double          *x, int incx,
                           double                *y, int incy)
cublasStatus_t cublasCaxpy(cublasHandle_t handle, int n,
                           const cuComplex       *alpha,
                           const cuComplex       *x, int incx,
                           cuComplex             *y, int incy)
cublasStatus_t cublasZaxpy(cublasHandle_t handle, int n,
                           const cuDoubleComplex *alpha,
                           const cuDoubleComplex *x, int incx,
                           cuDoubleComplex       *y, int incy)

This function supports the 64-bit Integer Interface.

This function multiplies the vector x by the scalar \(\alpha\) and adds it to the vector y overwriting the latest vector with the result. Hence, the performed operation is \(\mathbf{y}\lbrack j\rbrack = \alpha \times \mathbf{x}\lbrack k\rbrack + \mathbf{y}\lbrack j\rbrack\) for \(i = 1,\ldots,n\) , \(k = 1 + \left( {i - 1} \right)*\text{incx}\) and \(j = 1 + \left( {i - 1} \right)*\text{incy}\) . Notice that the last two equations reflect 1-based indexing used for compatibility with Fortran.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

alpha

host or device

input

<type> scalar used for multiplication.

n

input

number of elements in the vector x and y.

x

device

input

<type> vector with n elements.

incx

input

stride between consecutive elements of x.

y

device

in/out

<type> vector with n elements.

incy

input

stride between consecutive elements of y.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

saxpy, daxpy, caxpy, zaxpy

2.5.5. cublas<t>copy()

cublasStatus_t cublasScopy(cublasHandle_t handle, int n,
                           const float           *x, int incx,
                           float                 *y, int incy)
cublasStatus_t cublasDcopy(cublasHandle_t handle, int n,
                           const double          *x, int incx,
                           double                *y, int incy)
cublasStatus_t cublasCcopy(cublasHandle_t handle, int n,
                           const cuComplex       *x, int incx,
                           cuComplex             *y, int incy)
cublasStatus_t cublasZcopy(cublasHandle_t handle, int n,
                           const cuDoubleComplex *x, int incx,
                           cuDoubleComplex       *y, int incy)

This function supports the 64-bit Integer Interface.

This function copies the vector x into the vector y. Hence, the performed operation is \(\mathbf{y}\lbrack j\rbrack = \mathbf{x}\lbrack k\rbrack\) for \(i = 1,\ldots,n\) , \(k = 1 + \left( {i - 1} \right)*\text{incx}\) and \(j = 1 + \left( {i - 1} \right)*\text{incy}\) . Notice that the last two equations reflect 1-based indexing used for compatibility with Fortran.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

n

input

number of elements in the vector x and y.

x

device

input

<type> vector with n elements.

incx

input

stride between consecutive elements of x.

y

device

output

<type> vector with n elements.

incy

input

stride between consecutive elements of y.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

scopy, dcopy, ccopy, zcopy

2.5.6. cublas<t>dot()

cublasStatus_t cublasSdot (cublasHandle_t handle, int n,
                           const float           *x, int incx,
                           const float           *y, int incy,
                           float           *result)
cublasStatus_t cublasDdot (cublasHandle_t handle, int n,
                           const double          *x, int incx,
                           const double          *y, int incy,
                           double          *result)
cublasStatus_t cublasCdotu(cublasHandle_t handle, int n,
                           const cuComplex       *x, int incx,
                           const cuComplex       *y, int incy,
                           cuComplex       *result)
cublasStatus_t cublasCdotc(cublasHandle_t handle, int n,
                           const cuComplex       *x, int incx,
                           const cuComplex       *y, int incy,
                           cuComplex       *result)
cublasStatus_t cublasZdotu(cublasHandle_t handle, int n,
                           const cuDoubleComplex *x, int incx,
                           const cuDoubleComplex *y, int incy,
                           cuDoubleComplex *result)
cublasStatus_t cublasZdotc(cublasHandle_t handle, int n,
                           const cuDoubleComplex *x, int incx,
                           const cuDoubleComplex *y, int incy,
                           cuDoubleComplex       *result)

This function supports the 64-bit Integer Interface.

This function computes the dot product of vectors x and y. Hence, the result is \(\sum_{i = 1}^{n}\left( {\mathbf{x}\lbrack k\rbrack \times \mathbf{y}\lbrack j\rbrack} \right)\) where \(k = 1 + \left( {i - 1} \right)*\text{incx}\) and \(j = 1 + \left( {i - 1} \right)*\text{incy}\) . Notice that in the first equation the conjugate of the element of vector x should be used if the function name ends in character ‘c’ and that the last two equations reflect 1-based indexing used for compatibility with Fortran.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

n

input

number of elements in the vectors x and y.

x

device

input

<type> vector with n elements.

incx

input

stride between consecutive elements of x.

y

device

input

<type> vector with n elements.

incy

input

stride between consecutive elements of y.

result

host or device

output

the resulting dot product, which is 0.0 if n<=0.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_ALLOC_FAILED

the reduction buffer could not be allocated

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

sdot, ddot, cdotu, cdotc, zdotu, zdotc

2.5.7. cublas<t>nrm2()

cublasStatus_t  cublasSnrm2(cublasHandle_t handle, int n,
                            const float           *x, int incx, float  *result)
cublasStatus_t  cublasDnrm2(cublasHandle_t handle, int n,
                            const double          *x, int incx, double *result)
cublasStatus_t cublasScnrm2(cublasHandle_t handle, int n,
                            const cuComplex       *x, int incx, float  *result)
cublasStatus_t cublasDznrm2(cublasHandle_t handle, int n,
                            const cuDoubleComplex *x, int incx, double *result)

This function supports the 64-bit Integer Interface.

This function computes the Euclidean norm of the vector x. The code uses a multiphase model of accumulation to avoid intermediate underflow and overflow, with the result being equivalent to \(\sqrt{\sum_{i = 1}^{n}\left( {\mathbf{x}\lbrack j\rbrack \times \mathbf{x}\lbrack j\rbrack} \right)}\) where \(j = 1 + \left( {i - 1} \right)*\text{incx}\) in exact arithmetic. Notice that the last equation reflects 1-based indexing used for compatibility with Fortran.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

n

input

number of elements in the vector x.

x

device

input

<type> vector with n elements.

incx

input

stride between consecutive elements of x.

result

host or device

output

the resulting norm, which is 0.0 if n,incx<=0.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_ALLOC_FAILED

the reduction buffer could not be allocated

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

CUBLAS_STATUS_INVALID_VALUE

result is NULL

For references please refer to:

snrm2, dnrm2, scnrm2, dznrm2

2.5.8. cublas<t>rot()

cublasStatus_t  cublasSrot(cublasHandle_t handle, int n,
                           float           *x, int incx,
                           float           *y, int incy,
                           const float  *c, const float           *s)
cublasStatus_t  cublasDrot(cublasHandle_t handle, int n,
                           double          *x, int incx,
                           double          *y, int incy,
                           const double *c, const double          *s)
cublasStatus_t  cublasCrot(cublasHandle_t handle, int n,
                           cuComplex       *x, int incx,
                           cuComplex       *y, int incy,
                           const float  *c, const cuComplex       *s)
cublasStatus_t cublasCsrot(cublasHandle_t handle, int n,
                           cuComplex       *x, int incx,
                           cuComplex       *y, int incy,
                           const float  *c, const float           *s)
cublasStatus_t  cublasZrot(cublasHandle_t handle, int n,
                           cuDoubleComplex *x, int incx,
                           cuDoubleComplex *y, int incy,
                           const double *c, const cuDoubleComplex *s)
cublasStatus_t cublasZdrot(cublasHandle_t handle, int n,
                           cuDoubleComplex *x, int incx,
                           cuDoubleComplex *y, int incy,
                           const double *c, const double          *s)

This function supports the 64-bit Integer Interface.

This function applies Givens rotation matrix (i.e., rotation in the x,y plane counter-clockwise by angle defined by cos(alpha)=c, sin(alpha)=s):

\(G = \begin{pmatrix} c & s \\ {- s} & c \\ \end{pmatrix}\)

to vectors x and y.

Hence, the result is \(\mathbf{x}\lbrack k\rbrack = c \times \mathbf{x}\lbrack k\rbrack + s \times \mathbf{y}\lbrack j\rbrack\) and \(\mathbf{y}\lbrack j\rbrack = - s \times \mathbf{x}\lbrack k\rbrack + c \times \mathbf{y}\lbrack j\rbrack\) where \(k = 1 + \left( {i - 1} \right)*\text{incx}\) and \(j = 1 + \left( {i - 1} \right)*\text{incy}\) . Notice that the last two equations reflect 1-based indexing used for compatibility with Fortran.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

n

input

number of elements in the vectors x and y.

x

device

in/out

<type> vector with n elements.

incx

input

stride between consecutive elements of x.

y

device

in/out

<type> vector with n elements.

incy

input

stride between consecutive elements of y.

c

host or device

input

cosine element of the rotation matrix.

s

host or device

input

sine element of the rotation matrix.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

srot, drot, crot, csrot, zrot, zdrot

2.5.9. cublas<t>rotg()

cublasStatus_t cublasSrotg(cublasHandle_t handle,
                           float           *a, float           *b,
                           float  *c, float           *s)
cublasStatus_t cublasDrotg(cublasHandle_t handle,
                           double          *a, double          *b,
                           double *c, double          *s)
cublasStatus_t cublasCrotg(cublasHandle_t handle,
                           cuComplex       *a, cuComplex       *b,
                           float  *c, cuComplex       *s)
cublasStatus_t cublasZrotg(cublasHandle_t handle,
                           cuDoubleComplex *a, cuDoubleComplex *b,
                           double *c, cuDoubleComplex *s)

This function supports the 64-bit Integer Interface.

This function constructs the Givens rotation matrix

\(G = \begin{pmatrix} c & s \\ {- s} & c \\ \end{pmatrix}\)

that zeros out the second entry of a \(2 \times 1\) vector \(\left( {a,b} \right)^{T}\) .

Then, for real numbers we can write

\(\begin{pmatrix} c & s \\ {- s} & c \\ \end{pmatrix}\begin{pmatrix} a \\ b \\ \end{pmatrix} = \begin{pmatrix} r \\ 0 \\ \end{pmatrix}\)

where \(c^{2} + s^{2} = 1\) and \(r = a^{2} + b^{2}\) . The parameters \(a\) and \(b\) are overwritten with \(r\) and \(z\) , respectively. The value of \(z\) is such that \(c\) and \(s\) may be recovered using the following rules:

\(\left( {c,s} \right) = \begin{cases} \left( {\sqrt{1 - z^{2}},z} \right) & {\text{ if }\left| z \middle| < 1 \right.} \\ \left( {0.0,1.0} \right) & {\text{ if }\left| z \middle| = 1 \right.} \\ \left( 1/z,\sqrt{1 - z^{2}} \right) & {\text{ if }\left| z \middle| > 1 \right.} \\ \end{cases}\)

For complex numbers we can write

\(\begin{pmatrix} c & s \\ {- \bar{s}} & c \\ \end{pmatrix}\begin{pmatrix} a \\ b \\ \end{pmatrix} = \begin{pmatrix} r \\ 0 \\ \end{pmatrix}\)

where \(c^{2} + \left( {\bar{s} \times s} \right) = 1\) and \(r = \frac{a}{|a|} \times \parallel \left( {a,b} \right)^{T} \parallel_{2}\) with \(\parallel \left( {a,b} \right)^{T} \parallel_{2} = \sqrt{\left| a|^{2} + \middle| b|^{2} \right.}\) for \(a \neq 0\) and \(r = b\) for \(a = 0\) . Finally, the parameter \(a\) is overwritten with \(r\) on exit.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

a

host or device

in/out

<type> scalar that is overwritten with \(r\) .

b

host or device

in/out

<type> scalar that is overwritten with \(z\) .

c

host or device

output

cosine element of the rotation matrix.

s

host or device

output

sine element of the rotation matrix.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

srotg, drotg, crotg, zrotg

2.5.10. cublas<t>rotm()

cublasStatus_t cublasSrotm(cublasHandle_t handle, int n, float  *x, int incx,
                           float  *y, int incy, const float*  param)
cublasStatus_t cublasDrotm(cublasHandle_t handle, int n, double *x, int incx,
                           double *y, int incy, const double* param)

This function supports the 64-bit Integer Interface.

This function applies the modified Givens transformation

\(H = \begin{pmatrix} h_{11} & h_{12} \\ h_{21} & h_{22} \\ \end{pmatrix}\)

to vectors x and y.

Hence, the result is \(\mathbf{x}\lbrack k\rbrack = h_{11} \times \mathbf{x}\lbrack k\rbrack + h_{12} \times \mathbf{y}\lbrack j\rbrack\) and \(\mathbf{y}\lbrack j\rbrack = h_{21} \times \mathbf{x}\lbrack k\rbrack + h_{22} \times \mathbf{y}\lbrack j\rbrack\) where \(k = 1 + \left( {i - 1} \right)*\text{incx}\) and \(j = 1 + \left( {i - 1} \right)*\text{incy}\) . Notice that the last two equations reflect 1-based indexing used for compatibility with Fortran.

The elements , , and of matrix \(H\) are stored in param[1], param[2], param[3] and param[4], respectively. The flag=param[0] defines the following predefined values for the matrix \(H\) entries

flag=-1.0

flag= 0.0

flag= 1.0

flag=-2.0

\(\begin{pmatrix} h_{11} & h_{12} \\ h_{21} & h_{22} \\ \end{pmatrix}\)

\(\begin{pmatrix} {1.0} & h_{12} \\ h_{21} & {1.0} \\ \end{pmatrix}\)

\(\begin{pmatrix} h_{11} & {1.0} \\ {- 1.0} & h_{22} \\ \end{pmatrix}\)

\(\begin{pmatrix} {1.0} & {0.0} \\ {0.0} & {1.0} \\ \end{pmatrix}\)

Notice that the values -1.0, 0.0 and 1.0 implied by the flag are not stored in param.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

n

input

number of elements in the vectors x and y.

x

device

in/out

<type> vector with n elements.

incx

input

stride between consecutive elements of x.

y

device

in/out

<type> vector with n elements.

incy

input

stride between consecutive elements of y.

param

host or device

input

<type> vector of 5 elements, where param[0] and param[1-4] contain the flag and matrix \(H\) .

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

srotm, drotm

2.5.11. cublas<t>rotmg()

cublasStatus_t cublasSrotmg(cublasHandle_t handle, float  *d1, float  *d2,
                            float  *x1, const float  *y1, float  *param)
cublasStatus_t cublasDrotmg(cublasHandle_t handle, double *d1, double *d2,
                            double *x1, const double *y1, double *param)

This function supports the 64-bit Integer Interface.

This function constructs the modified Givens transformation

\(H = \begin{pmatrix} h_{11} & h_{12} \\ h_{21} & h_{22} \\ \end{pmatrix}\)

that zeros out the second entry of a \(2 \times 1\) vector \(\left( {\sqrt{d1}*x1,\sqrt{d2}*y1} \right)^{T}\) .

The flag=param[0] defines the following predefined values for the matrix \(H\) entries

flag=-1.0

flag= 0.0

flag= 1.0

flag=-2.0

\(\begin{pmatrix} h_{11} & h_{12} \\ h_{21} & h_{22} \\ \end{pmatrix}\)

\(\begin{pmatrix} {1.0} & h_{12} \\ h_{21} & {1.0} \\ \end{pmatrix}\)

\(\begin{pmatrix} h_{11} & {1.0} \\ {- 1.0} & h_{22} \\ \end{pmatrix}\)

\(\begin{pmatrix} {1.0} & {0.0} \\ {0.0} & {1.0} \\ \end{pmatrix}\)

Notice that the values -1.0, 0.0 and 1.0 implied by the flag are not stored in param.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

d1

host or device

in/out

<type> scalar that is overwritten on exit.

d2

host or device

in/out

<type> scalar that is overwritten on exit.

x1

host or device

in/out

<type> scalar that is overwritten on exit.

y1

host or device

input

<type> scalar.

param

host or device

output

<type> vector of 5 elements, where param[0] and param[1-4] contain the flag and matrix \(H\) .

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

srotmg, drotmg

2.5.12. cublas<t>scal()

cublasStatus_t  cublasSscal(cublasHandle_t handle, int n,
                            const float           *alpha,
                            float           *x, int incx)
cublasStatus_t  cublasDscal(cublasHandle_t handle, int n,
                            const double          *alpha,
                            double          *x, int incx)
cublasStatus_t  cublasCscal(cublasHandle_t handle, int n,
                            const cuComplex       *alpha,
                            cuComplex       *x, int incx)
cublasStatus_t cublasCsscal(cublasHandle_t handle, int n,
                            const float           *alpha,
                            cuComplex       *x, int incx)
cublasStatus_t  cublasZscal(cublasHandle_t handle, int n,
                            const cuDoubleComplex *alpha,
                            cuDoubleComplex *x, int incx)
cublasStatus_t cublasZdscal(cublasHandle_t handle, int n,
                            const double          *alpha,
                            cuDoubleComplex *x, int incx)

This function supports the 64-bit Integer Interface.

This function scales the vector x by the scalar \(\alpha\) and overwrites it with the result. Hence, the performed operation is \(\mathbf{x}\lbrack j\rbrack = \alpha \times \mathbf{x}\lbrack j\rbrack\) for \(i = 1,\ldots,n\) and \(j = 1 + \left( {i - 1} \right)*\text{incx}\) . Notice that the last two equations reflect 1-based indexing used for compatibility with Fortran.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

alpha

host or device

input

<type> scalar used for multiplication.

n

input

number of elements in the vector x.

x

device

in/out

<type> vector with n elements.

incx

input

stride between consecutive elements of x.

The possible error values returned by this function and their meanings are listed below.

:class: table-no-stripes

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

sscal, dscal, csscal, cscal, zdscal, zscal

2.5.13. cublas<t>swap()

cublasStatus_t cublasSswap(cublasHandle_t handle, int n, float           *x,
                           int incx, float           *y, int incy)
cublasStatus_t cublasDswap(cublasHandle_t handle, int n, double          *x,
                           int incx, double          *y, int incy)
cublasStatus_t cublasCswap(cublasHandle_t handle, int n, cuComplex       *x,
                           int incx, cuComplex       *y, int incy)
cublasStatus_t cublasZswap(cublasHandle_t handle, int n, cuDoubleComplex *x,
                           int incx, cuDoubleComplex *y, int incy)

This function supports the 64-bit Integer Interface.

This function interchanges the elements of vector x and y. Hence, the performed operation is \(\left. \mathbf{y}\lbrack j\rbrack\Leftrightarrow\mathbf{x}\lbrack k\rbrack \right.\) for \(i = 1,\ldots,n\) , \(k = 1 + \left( {i - 1} \right)*\text{incx}\) and \(j = 1 + \left( {i - 1} \right)*\text{incy}\) . Notice that the last two equations reflect 1-based indexing used for compatibility with Fortran.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

n

input

number of elements in the vector x and y.

x

device

in/out

<type> vector with n elements.

incx

input

stride between consecutive elements of x.

y

device

in/out

<type> vector with n elements.

incy

input

stride between consecutive elements of y.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

sswap, dswap, cswap, zswap

2.6. cuBLAS Level-2 Function Reference

In this chapter we describe the Level-2 Basic Linear Algebra Subprograms (BLAS2) functions that perform matrix-vector operations.

2.6.1. cublas<t>gbmv()

cublasStatus_t cublasSgbmv(cublasHandle_t handle, cublasOperation_t trans,
                           int m, int n, int kl, int ku,
                           const float           *alpha,
                           const float           *A, int lda,
                           const float           *x, int incx,
                           const float           *beta,
                           float           *y, int incy)
cublasStatus_t cublasDgbmv(cublasHandle_t handle, cublasOperation_t trans,
                           int m, int n, int kl, int ku,
                           const double          *alpha,
                           const double          *A, int lda,
                           const double          *x, int incx,
                           const double          *beta,
                           double          *y, int incy)
cublasStatus_t cublasCgbmv(cublasHandle_t handle, cublasOperation_t trans,
                           int m, int n, int kl, int ku,
                           const cuComplex       *alpha,
                           const cuComplex       *A, int lda,
                           const cuComplex       *x, int incx,
                           const cuComplex       *beta,
                           cuComplex       *y, int incy)
cublasStatus_t cublasZgbmv(cublasHandle_t handle, cublasOperation_t trans,
                           int m, int n, int kl, int ku,
                           const cuDoubleComplex *alpha,
                           const cuDoubleComplex *A, int lda,
                           const cuDoubleComplex *x, int incx,
                           const cuDoubleComplex *beta,
                           cuDoubleComplex *y, int incy)

This function supports the 64-bit Integer Interface.

This function performs the banded matrix-vector multiplication

\(\mathbf{y} = \alpha\text{ op}(A)\mathbf{x} + \beta\mathbf{y}\)

where \(A\) is a banded matrix with \(kl\) subdiagonals and \(ku\) superdiagonals, \(\mathbf{x}\) and \(\mathbf{y}\) are vectors, and \(\alpha\) and \(\beta\) are scalars. Also, for matrix \(A\)

\(\text{ op}(A) = \begin{cases} A & \text{ if transa == $\mathrm{CUBLAS\_OP\_N}$} \\ A^{T} & \text{ if transa == $\mathrm{CUBLAS\_OP\_T}$} \\ A^{H} & \text{ if transa == $\mathrm{CUBLAS\_OP\_C}$} \\ \end{cases}\)

The banded matrix \(A\) is stored column by column, with the main diagonal stored in row \(ku + 1\) (starting in first position), the first superdiagonal stored in row \(ku\) (starting in second position), the first subdiagonal stored in row \(ku + 2\) (starting in first position), etc. So that in general, the element \(A\left( {i,j} \right)\) is stored in the memory location A(ku+1+i-j,j) for \(j = 1,\ldots,n\) and \(i \in \left\lbrack {\max\left( {1,j - ku} \right),\min\left( {m,j + kl} \right)} \right\rbrack\) . Also, the elements in the array \(A\) that do not conceptually correspond to the elements in the banded matrix (the top left \(ku \times ku\) and bottom right \(kl \times kl\) triangles) are not referenced.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

trans

input

operation op(A) that is non- or (conj.) transpose.

m

input

number of rows of matrix A.

n

input

number of columns of matrix A.

kl

input

number of subdiagonals of matrix A.

ku

input

number of superdiagonals of matrix A.

alpha

host or device

input

<type> scalar used for multiplication.

A

device

input

<type> array of dimension lda x n with lda>=kl+ku+1.

lda

input

leading dimension of two-dimensional array used to store matrix A.

x

device

input

<type> vector with n elements if transa == CUBLAS_OP_N and m elements otherwise.

incx

input

stride between consecutive elements of x.

beta

host or device

input

<type> scalar used for multiplication, if beta == 0 then y does not have to be a valid input.

y

device

in/out

<type> vector with m elements if transa == CUBLAS_OP_N and n elements otherwise.

incy

input

stride between consecutive elements of y.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If m, n, kl, ku < 0 or

  • if lda < (kl+ku+1) or

  • if incx, incy == 0 or

  • if trans != CUBLAS_OP_N, CUBLAS_OP_T, CUBLAS_OP_C or

  • alpha, beta == NULL

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

sgbmv, dgbmv, cgbmv, zgbmv

2.6.2. cublas<t>gemv()

cublasStatus_t cublasSgemv(cublasHandle_t handle, cublasOperation_t trans,
                           int m, int n,
                           const float           *alpha,
                           const float           *A, int lda,
                           const float           *x, int incx,
                           const float           *beta,
                           float           *y, int incy)
cublasStatus_t cublasDgemv(cublasHandle_t handle, cublasOperation_t trans,
                           int m, int n,
                           const double          *alpha,
                           const double          *A, int lda,
                           const double          *x, int incx,
                           const double          *beta,
                           double          *y, int incy)
cublasStatus_t cublasCgemv(cublasHandle_t handle, cublasOperation_t trans,
                           int m, int n,
                           const cuComplex       *alpha,
                           const cuComplex       *A, int lda,
                           const cuComplex       *x, int incx,
                           const cuComplex       *beta,
                           cuComplex       *y, int incy)
cublasStatus_t cublasZgemv(cublasHandle_t handle, cublasOperation_t trans,
                           int m, int n,
                           const cuDoubleComplex *alpha,
                           const cuDoubleComplex *A, int lda,
                           const cuDoubleComplex *x, int incx,
                           const cuDoubleComplex *beta,
                           cuDoubleComplex *y, int incy)

This function supports the 64-bit Integer Interface.

This function performs the matrix-vector multiplication

\(\textbf{y} = \alpha\text{ op}(A)\textbf{x} + \beta\textbf{y}\)

where \(A\) is a \(m \times n\) matrix stored in column-major format, \(\mathbf{x}\) and \(\mathbf{y}\) are vectors, and \(\alpha\) and \(\beta\) are scalars. Also, for matrix \(A\)

\(\text{ op}(A) = \begin{cases} A & \text{ if transa == $\mathrm{CUBLAS\_OP\_N}$} \\ A^{T} & \text{ if transa == $\mathrm{CUBLAS\_OP\_T}$} \\ A^{H} & \text{ if transa == $\mathrm{CUBLAS\_OP\_C}$} \\ \end{cases}\)

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

trans

input

operation op(A) that is non- or (conj.) transpose.

m

input

number of rows of matrix A.

n

input

number of columns of matrix A.

alpha

host or device

input

<type> scalar used for multiplication.

A

device

input

<type> array of dimension lda x n with lda >= max(1,m). Before entry, the leading m by n part of the array A must contain the matrix of coefficients. Unchanged on exit.

lda

input

leading dimension of two-dimensional array used to store matrix A. lda must be at least max(1,m).

x

device

input

<type> vector at least (1+(n-1)*abs(incx)) elements if transa==CUBLAS_OP_N and at least (1+(m-1)*abs(incx)) elements otherwise.

incx

input

stride between consecutive elements of x.

beta

host or device

input

<type> scalar used for multiplication, if beta==0 then y does not have to be a valid input.

y

device

in/out

<type> vector at least (1+(m-1)*abs(incy)) elements if transa==CUBLAS_OP_N and at least (1+(n-1)*abs(incy)) elements otherwise.

incy

input

stride between consecutive elements of y

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

the parameters m,n<0 or incx,incy=0

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

sgemv, dgemv, cgemv, zgemv

2.6.3. cublas<t>ger()

cublasStatus_t  cublasSger(cublasHandle_t handle, int m, int n,
                           const float           *alpha,
                           const float           *x, int incx,
                           const float           *y, int incy,
                           float           *A, int lda)
cublasStatus_t  cublasDger(cublasHandle_t handle, int m, int n,
                           const double          *alpha,
                           const double          *x, int incx,
                           const double          *y, int incy,
                           double          *A, int lda)
cublasStatus_t cublasCgeru(cublasHandle_t handle, int m, int n,
                           const cuComplex       *alpha,
                           const cuComplex       *x, int incx,
                           const cuComplex       *y, int incy,
                           cuComplex       *A, int lda)
cublasStatus_t cublasCgerc(cublasHandle_t handle, int m, int n,
                           const cuComplex       *alpha,
                           const cuComplex       *x, int incx,
                           const cuComplex       *y, int incy,
                           cuComplex       *A, int lda)
cublasStatus_t cublasZgeru(cublasHandle_t handle, int m, int n,
                           const cuDoubleComplex *alpha,
                           const cuDoubleComplex *x, int incx,
                           const cuDoubleComplex *y, int incy,
                           cuDoubleComplex *A, int lda)
cublasStatus_t cublasZgerc(cublasHandle_t handle, int m, int n,
                           const cuDoubleComplex *alpha,
                           const cuDoubleComplex *x, int incx,
                           const cuDoubleComplex *y, int incy,
                           cuDoubleComplex *A, int lda)

This function supports the 64-bit Integer Interface.

This function performs the rank-1 update

\(A = \begin{cases} {\alpha\mathbf{xy}^{T} + A} & \text{if ger(),geru() is called} \\ {\alpha\mathbf{xy}^{H} + A} & \text{if gerc() is called} \\ \end{cases}\)

where \(A\) is a \(m \times n\) matrix stored in column-major format, \(\mathbf{x}\) and \(\mathbf{y}\) are vectors, and \(\alpha\) is a scalar.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

m

input

number of rows of matrix A.

n

input

number of columns of matrix A.

alpha

host or device

input

<type> scalar used for multiplication.

x

device

input

<type> vector with m elements.

incx

input

stride between consecutive elements of x.

y

device

input

<type> vector with n elements.

incy

input

stride between consecutive elements of y.

A

device

in/out

<type> array of dimension lda x n with lda >= max(1,m).

lda

input

leading dimension of two-dimensional array used to store matrix A.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If m < 0 or n < 0

  • if incx = 0 or incy = 0 or

  • if alpha == NULL or

  • lda < max(1, m)

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

sger, dger, cgeru, cgerc, zgeru, zgerc

2.6.4. cublas<t>sbmv()

cublasStatus_t cublasSsbmv(cublasHandle_t handle, cublasFillMode_t uplo,
                           int n, int k, const float  *alpha,
                           const float  *A, int lda,
                           const float  *x, int incx,
                           const float  *beta, float *y, int incy)
cublasStatus_t cublasDsbmv(cublasHandle_t handle, cublasFillMode_t uplo,
                           int n, int k, const double *alpha,
                           const double *A, int lda,
                           const double *x, int incx,
                           const double *beta, double *y, int incy)

This function supports the 64-bit Integer Interface.

This function performs the symmetric banded matrix-vector multiplication

\(\textbf{y} = \alpha A\textbf{x} + \beta\textbf{y}\)

where \(A\) is a \(n \times n\) symmetric banded matrix with \(k\) subdiagonals and superdiagonals, \(\mathbf{x}\) and \(\mathbf{y}\) are vectors, and \(\alpha\) and \(\beta\) are scalars.

If uplo == CUBLAS_FILL_MODE_LOWER then the symmetric banded matrix \(A\) is stored column by column, with the main diagonal of the matrix stored in row 1, the first subdiagonal in row 2 (starting at first position), the second subdiagonal in row 3 (starting at first position), etc. So that in general, the element \(A(i,j)\) is stored in the memory location A(1+i-j,j) for \(j = 1,\ldots,n\) and \(i \in \lbrack j,\min(m,j + k)\rbrack\) . Also, the elements in the array A that do not conceptually correspond to the elements in the banded matrix (the bottom right \(k \times k\) triangle) are not referenced.

If uplo == CUBLAS_FILL_MODE_UPPER then the symmetric banded matrix \(A\) is stored column by column, with the main diagonal of the matrix stored in row k+1, the first superdiagonal in row k (starting at second position), the second superdiagonal in row k-1 (starting at third position), etc. So that in general, the element \(A(i,j)\) is stored in the memory location A(1+k+i-j,j) for \(j = 1,\ldots,n\) and \(i \in \lbrack\max(1,j - k),j\rbrack\) . Also, the elements in the array A that do not conceptually correspond to the elements in the banded matrix (the top left \(k \times k\) triangle) are not referenced.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

uplo

input

indicates if matrix A lower or upper part is stored, the other symmetric part is not referenced and is inferred from the stored elements.

n

input

number of rows and columns of matrix A.

k

input

number of sub- and super-diagonals of matrix A.

alpha

host or device

input

<type> scalar used for multiplication.

A

device

input

<type> array of dimension lda x n with lda >= k+1.

lda

input

leading dimension of two-dimensional array used to store matrix A.

x

device

input

<type> vector with n elements.

incx

input

stride between consecutive elements of x.

beta

host or device

input

<type> scalar used for multiplication, if beta==0 then y does not have to be a valid input.

y

device

in/out

<type> vector with n elements.

incy

input

stride between consecutive elements of y.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If n < 0 or k < 0 or

  • if incx = 0 or incy = 0 or

  • if uplo != CUBLAS_FILL_MODE_LOWER, CUBLAS_FILL_MODE_UPPER or

  • if alpha == NULL or beta == NULL or

  • lda < (1 + k)

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

ssbmv, dsbmv

2.6.5. cublas<t>spmv()

cublasStatus_t cublasSspmv(cublasHandle_t handle, cublasFillMode_t uplo,
                           int n, const float  *alpha, const float  *AP,
                           const float  *x, int incx, const float  *beta,
                           float  *y, int incy)
cublasStatus_t cublasDspmv(cublasHandle_t handle, cublasFillMode_t uplo,
                           int n, const double *alpha, const double *AP,
                           const double *x, int incx, const double *beta,
                           double *y, int incy)

This function supports the 64-bit Integer Interface.

This function performs the symmetric packed matrix-vector multiplication

\(\textbf{y} = \alpha A\textbf{x} + \beta\textbf{y}\)

where \(A\) is a \(n \times n\) symmetric matrix stored in packed format, \(\mathbf{x}\) and \(\mathbf{y}\) are vectors, and \(\alpha\) and \(\beta\) are scalars.

If uplo == CUBLAS_FILL_MODE_LOWER then the elements in the lower triangular part of the symmetric matrix \(A\) are packed together column by column without gaps, so that the element \(A(i,j)\) is stored in the memory location AP[i+((2*n-j+1)*j)/2] for \(j = 1,\ldots,n\) and \(i \geq j\) . Consequently, the packed format requires only \(\frac{n(n + 1)}{2}\) elements for storage.

If uplo == CUBLAS_FILL_MODE_UPPER then the elements in the upper triangular part of the symmetric matrix \(A\) are packed together column by column without gaps, so that the element \(A(i,j)\) is stored in the memory location AP[i+(j*(j+1))/2] for \(j = 1,\ldots,n\) and \(i \leq j\) . Consequently, the packed format requires only \(\frac{n(n + 1)}{2}\) elements for storage.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

uplo

input

indicates if matrix \(A\) lower or upper part is stored, the other symmetric part is not referenced and is inferred from the stored elements.

n

input

number of rows and columns of matrix \(A\) .

alpha

host or device

input

<type> scalar used for multiplication.

AP

device

input

<type> array with \(A\) stored in packed format.

x

device

input

<type> vector with n elements.

incx

input

stride between consecutive elements of x.

beta

host or device

input

<type> scalar used for multiplication, if beta==0 then y does not have to be a valid input.

y

device

input

<type> vector with n elements.

incy

input

stride between consecutive elements of y.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If n < 0 or

  • if incx = 0 or incy = 0 or

  • if uplo != CUBLAS_FILL_MODE_LOWER, CUBLAS_FILL_MODE_UPPER or

  • alpha == NULL or beta == NULL

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

sspmv, dspmv

2.6.6. cublas<t>spr()

cublasStatus_t cublasSspr(cublasHandle_t handle, cublasFillMode_t uplo,
                          int n, const float  *alpha,
                          const float  *x, int incx, float  *AP)
cublasStatus_t cublasDspr(cublasHandle_t handle, cublasFillMode_t uplo,
                          int n, const double *alpha,
                          const double *x, int incx, double *AP)

This function supports the 64-bit Integer Interface.

This function performs the packed symmetric rank-1 update

\(A = \alpha\textbf{x}\textbf{x}^{T} + A\)

where \(A\) is a \(n \times n\) symmetric matrix stored in packed format, \(\mathbf{x}\) is a vector, and \(\alpha\) is a scalar.

If uplo == CUBLAS_FILL_MODE_LOWER then the elements in the lower triangular part of the symmetric matrix \(A\) are packed together column by column without gaps, so that the element \(A(i,j)\) is stored in the memory location AP[i+((2*n-j+1)*j)/2] for \(j = 1,\ldots,n\) and \(i \geq j\) . Consequently, the packed format requires only \(\frac{n(n + 1)}{2}\) elements for storage.

If uplo == CUBLAS_FILL_MODE_UPPER then the elements in the upper triangular part of the symmetric matrix \(A\) are packed together column by column without gaps, so that the element \(A(i,j)\) is stored in the memory location AP[i+(j*(j+1))/2] for \(j = 1,\ldots,n\) and \(i \leq j\) . Consequently, the packed format requires only \(\frac{n(n + 1)}{2}\) elements for storage.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

uplo

input

indicates if matrix \(A\) lower or upper part is stored, the other symmetric part is not referenced and is inferred from the stored elements.

n

input

number of rows and columns of matrix \(A\) .

alpha

host or device

input

<type> scalar used for multiplication.

x

device

input

<type> vector with n elements.

incx

input

stride between consecutive elements of x.

AP

device

in/out

<type> array with \(A\) stored in packed format.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If n < 0 or

  • if incx = 0 or

  • if uplo != CUBLAS_FILL_MODE_LOWER, CUBLAS_FILL_MODE_UPPER or

  • alpha == NULL

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

sspr, dspr

2.6.7. cublas<t>spr2()

cublasStatus_t cublasSspr2(cublasHandle_t handle, cublasFillMode_t uplo,
                           int n, const float  *alpha,
                           const float  *x, int incx,
                           const float  *y, int incy, float  *AP)
cublasStatus_t cublasDspr2(cublasHandle_t handle, cublasFillMode_t uplo,
                           int n, const double *alpha,
                           const double *x, int incx,
                           const double *y, int incy, double *AP)

This function supports the 64-bit Integer Interface.

This function performs the packed symmetric rank-2 update

\(A = \alpha\left( {\textbf{x}\textbf{y}^{T} + \textbf{y}\textbf{x}^{T}} \right) + A\)

where \(A\) is a \(n \times n\) symmetric matrix stored in packed format, \(\mathbf{x}\) is a vector, and \(\alpha\) is a scalar.

If uplo == CUBLAS_FILL_MODE_LOWER then the elements in the lower triangular part of the symmetric matrix \(A\) are packed together column by column without gaps, so that the element \(A(i,j)\) is stored in the memory location AP[i+((2*n-j+1)*j)/2] for \(j = 1,\ldots,n\) and \(i \geq j\) . Consequently, the packed format requires only \(\frac{n(n + 1)}{2}\) elements for storage.

If uplo == CUBLAS_FILL_MODE_UPPER then the elements in the upper triangular part of the symmetric matrix \(A\) are packed together column by column without gaps, so that the element \(A(i,j)\) is stored in the memory location AP[i+(j*(j+1))/2] for \(j = 1,\ldots,n\) and \(i \leq j\) . Consequently, the packed format requires only \(\frac{n(n + 1)}{2}\) elements for storage.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

uplo

input

indicates if matrix \(A\) lower or upper part is stored, the other symmetric part is not referenced and is inferred from the stored elements.

n

input

number of rows and columns of matrix \(A\) .

alpha

host or device

input

<type> scalar used for multiplication.

x

device

input

<type> vector with n elements.

incx

input

stride between consecutive elements of x.

y

device

input

<type> vector with n elements.

incy

input

stride between consecutive elements of y.

AP

device

in/out

<type> array with \(A\) stored in packed format.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If n < 0 or

  • if incx = 0 or incy = 0 or

  • if uplo != CUBLAS_FILL_MODE_LOWER, CUBLAS_FILL_MODE_UPPER or

  • alpha == NULL

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

sspr2, dspr2

2.6.8. cublas<t>symv()

cublasStatus_t cublasSsymv(cublasHandle_t handle, cublasFillMode_t uplo,
                           int n, const float           *alpha,
                           const float           *A, int lda,
                           const float           *x, int incx, const float           *beta,
                           float           *y, int incy)
cublasStatus_t cublasDsymv(cublasHandle_t handle, cublasFillMode_t uplo,
                           int n, const double          *alpha,
                           const double          *A, int lda,
                           const double          *x, int incx, const double          *beta,
                           double          *y, int incy)
cublasStatus_t cublasCsymv(cublasHandle_t handle, cublasFillMode_t uplo,
                           int n, const cuComplex       *alpha, /* host or device pointer */
                           const cuComplex       *A, int lda,
                           const cuComplex       *x, int incx, const cuComplex       *beta,
                           cuComplex       *y, int incy)
cublasStatus_t cublasZsymv(cublasHandle_t handle, cublasFillMode_t uplo,
                           int n, const cuDoubleComplex *alpha,
                           const cuDoubleComplex *A, int lda,
                           const cuDoubleComplex *x, int incx, const cuDoubleComplex *beta,
                           cuDoubleComplex *y, int incy)

This function supports the 64-bit Integer Interface.

This function performs the symmetric matrix-vector multiplication.

\(\textbf{y} = \alpha A\textbf{x} + \beta\textbf{y}\) where \(A\) is a \(n \times n\) symmetric matrix stored in lower or upper mode, \(\mathbf{x}\) and \(\mathbf{y}\) are vectors, and \(\alpha\) and \(\beta\) are scalars.

This function has an alternate faster implementation using atomics that can be enabled with cublasSetAtomicsMode().

Please see the section on the function cublasSetAtomicsMode() for more details about the usage of atomics.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

uplo

input

indicates if matrix lower or upper part is stored, the other symmetric part is not referenced and is inferred from the stored elements.

n

input

number of rows and columns of matrix A.

alpha

host or device

input

<type> scalar used for multiplication.

A

device

input

<type> array of dimension lda x n with lda>=max(1,n).

lda

input

leading dimension of two-dimensional array used to store matrix A.

x

device

input

<type> vector with n elements.

incx

input

stride between consecutive elements of x.

beta

host or device

input

<type> scalar used for multiplication, if beta==0 then y does not have to be a valid input.

y

device

in/out

<type> vector with n elements.

incy

input

stride between consecutive elements of y.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If n < 0 or

  • if incx = 0 or incy = 0 or

  • if uplo != CUBLAS_FILL_MODE_LOWER, CUBLAS_FILL_MODE_UPPER or

  • lda < n

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

ssymv, dsymv

2.6.9. cublas<t>syr()

cublasStatus_t cublasSsyr(cublasHandle_t handle, cublasFillMode_t uplo,
                          int n, const float           *alpha,
                          const float           *x, int incx, float           *A, int lda)
cublasStatus_t cublasDsyr(cublasHandle_t handle, cublasFillMode_t uplo,
                          int n, const double          *alpha,
                          const double          *x, int incx, double          *A, int lda)
cublasStatus_t cublasCsyr(cublasHandle_t handle, cublasFillMode_t uplo,
                          int n, const cuComplex       *alpha,
                          const cuComplex       *x, int incx, cuComplex       *A, int lda)
cublasStatus_t cublasZsyr(cublasHandle_t handle, cublasFillMode_t uplo,
                          int n, const cuDoubleComplex *alpha,
                          const cuDoubleComplex *x, int incx, cuDoubleComplex *A, int lda)

This function supports the 64-bit Integer Interface.

This function performs the symmetric rank-1 update

\(A = \alpha\textbf{x}\textbf{x}^{T} + A\)

where \(A\) is a \(n \times n\) symmetric matrix stored in column-major format, \(\mathbf{x}\) is a vector, and \(\alpha\) is a scalar.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

uplo

input

indicates if matrix A lower or upper part is stored, the other symmetric part is not referenced and is inferred from the stored elements.

n

input

number of rows and columns of matrix A.

alpha

host or device

input

<type> scalar used for multiplication.

x

device

input

<type> vector with n elements.

incx

input

stride between consecutive elements of x.

A

device

in/out

<type> array of dimensions lda x n, with lda>=max(1,n).

lda

input

leading dimension of two-dimensional array used to store matrix A.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If n < 0 or

  • if incx = 0 or

  • if uplo != CUBLAS_FILL_MODE_LOWER, CUBLAS_FILL_MODE_UPPER or

  • if lda < max(1, n) or

  • alpha == NULL

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

ssyr, dsyr

2.6.10. cublas<t>syr2()

cublasStatus_t cublasSsyr2(cublasHandle_t handle, cublasFillMode_t uplo, int n,
                           const float           *alpha, const float           *x, int incx,
                           const float           *y, int incy, float           *A, int lda
cublasStatus_t cublasDsyr2(cublasHandle_t handle, cublasFillMode_t uplo, int n,
                           const double          *alpha, const double          *x, int incx,
                           const double          *y, int incy, double          *A, int lda
cublasStatus_t cublasCsyr2(cublasHandle_t handle, cublasFillMode_t uplo, int n,
                           const cuComplex       *alpha, const cuComplex       *x, int incx,
                           const cuComplex       *y, int incy, cuComplex       *A, int lda
cublasStatus_t cublasZsyr2(cublasHandle_t handle, cublasFillMode_t uplo, int n,
                           const cuDoubleComplex *alpha, const cuDoubleComplex *x, int incx,
                           const cuDoubleComplex *y, int incy, cuDoubleComplex *A, int lda

This function supports the 64-bit Integer Interface.

This function performs the symmetric rank-2 update

\(A = \alpha\left( {\textbf{x}\textbf{y}^{T} + \textbf{y}\textbf{x}^{T}} \right) + A\)

where \(A\) is a \(n \times n\) symmetric matrix stored in column-major format, \(\mathbf{x}\) and \(\mathbf{y}\) are vectors, and \(\alpha\) is a scalar.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

uplo

input

indicates if matrix A lower or upper part is stored, the other symmetric part is not referenced and is inferred from the stored elements.

n

input

number of rows and columns of matrix A.

alpha

host or device

input

<type> scalar used for multiplication.

x

device

input

<type> vector with n elements.

incx

input

stride between consecutive elements of x.

y

device

input

<type> vector with n elements.

incy

input

stride between consecutive elements of y.

A

device

in/out

<type> array of dimensions lda x n, with lda>=max(1,n).

lda

input

leading dimension of two-dimensional array used to store matrix A.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If n < 0 or

  • if incx = 0 or incy = 0 or

  • if uplo != CUBLAS_FILL_MODE_LOWER, CUBLAS_FILL_MODE_UPPER or

  • if alpha == NULL or

  • lda < max(1, n)

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

ssyr2, dsyr2

2.6.11. cublas<t>tbmv()

cublasStatus_t cublasStbmv(cublasHandle_t handle, cublasFillMode_t uplo,
                           cublasOperation_t trans, cublasDiagType_t diag,
                           int n, int k, const float           *A, int lda,
                           float           *x, int incx)
cublasStatus_t cublasDtbmv(cublasHandle_t handle, cublasFillMode_t uplo,
                           cublasOperation_t trans, cublasDiagType_t diag,
                           int n, int k, const double          *A, int lda,
                           double          *x, int incx)
cublasStatus_t cublasCtbmv(cublasHandle_t handle, cublasFillMode_t uplo,
                           cublasOperation_t trans, cublasDiagType_t diag,
                           int n, int k, const cuComplex       *A, int lda,
                           cuComplex       *x, int incx)
cublasStatus_t cublasZtbmv(cublasHandle_t handle, cublasFillMode_t uplo,
                           cublasOperation_t trans, cublasDiagType_t diag,
                           int n, int k, const cuDoubleComplex *A, int lda,
                           cuDoubleComplex *x, int incx)

This function supports the 64-bit Integer Interface.

This function performs the triangular banded matrix-vector multiplication

\(\textbf{x} = \text{op}(A)\textbf{x}\)

where \(A\) is a triangular banded matrix, and \(\mathbf{x}\) is a vector. Also, for matrix \(A\)

\(\text{op}(A) = \left\{ \begin{matrix} A & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_N}$}} \\ A^{T} & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_T}$}} \\ A^{H} & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_C}$}} \\ \end{matrix} \right.\)

If uplo == CUBLAS_FILL_MODE_LOWER then the triangular banded matrix \(A\) is stored column by column, with the main diagonal of the matrix stored in row 1, the first subdiagonal in row 2 (starting at first position), the second subdiagonal in row 3 (starting at first position), etc. So that in general, the element \(A(i,j)\) is stored in the memory location A(1+i-j,j) for \(j = 1,\ldots,n\) and \(i \in \lbrack j,\min(m,j + k)\rbrack\) . Also, the elements in the array A that do not conceptually correspond to the elements in the banded matrix (the bottom right \(k \times k\) triangle) are not referenced.

If uplo == CUBLAS_FILL_MODE_UPPER then the triangular banded matrix \(A\) is stored column by column, with the main diagonal of the matrix stored in row k+1, the first superdiagonal in row k (starting at second position), the second superdiagonal in row k-1 (starting at third position), etc. So that in general, the element \(A(i,j)\) is stored in the memory location A(1+k+i-j,j) for \(j = 1,\ldots,n\) and \(i \in \lbrack\max(1,j - k,j)\rbrack\) . Also, the elements in the array A that do not conceptually correspond to the elements in the banded matrix (the top left \(k \times k\) triangle) are not referenced.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

uplo

input

indicates if matrix A lower or upper part is stored, the other part is not referenced and is inferred from the stored elements.

trans

input

operation op(A) that is non- or (conj.) transpose.

diag

input

indicates if the elements on the main diagonal of matrix A are unity and should not be accessed.

n

input

number of rows and columns of matrix A.

k

input

number of sub- and super-diagonals of matrix .

A

device

input

<type> array of dimension lda x n, with lda>=k+1.

lda

input

leading dimension of two-dimensional array used to store matrix A.

x

device

in/out

<type> vector with n elements.

incx

input

stride between consecutive elements of x.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If n < 0 or k < 0 or

  • if incx = 0 or

  • if trans != CUBLAS_OP_N, CUBLAS_OP_C, CUBLAS_OP_T or

  • if uplo != CUBLAS_FILL_MODE_LOWER, CUBLAS_FILL_MODE_UPPER or

  • if diag != CUBLAS_DIAG_UNIT, CUBLAS_DIAG_NON_UNIT or

  • lda < (1 + k)

CUBLAS_STATUS_ALLOC_FAILED

the allocation of internal scratch memory failed

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

stbmv, dtbmv, ctbmv, ztbmv

2.6.12. cublas<t>tbsv()

cublasStatus_t cublasStbsv(cublasHandle_t handle, cublasFillMode_t uplo,
                           cublasOperation_t trans, cublasDiagType_t diag,
                           int n, int k, const float           *A, int lda,
                           float           *x, int incx)
cublasStatus_t cublasDtbsv(cublasHandle_t handle, cublasFillMode_t uplo,
                           cublasOperation_t trans, cublasDiagType_t diag,
                           int n, int k, const double          *A, int lda,
                           double          *x, int incx)
cublasStatus_t cublasCtbsv(cublasHandle_t handle, cublasFillMode_t uplo,
                           cublasOperation_t trans, cublasDiagType_t diag,
                           int n, int k, const cuComplex       *A, int lda,
                           cuComplex       *x, int incx)
cublasStatus_t cublasZtbsv(cublasHandle_t handle, cublasFillMode_t uplo,
                           cublasOperation_t trans, cublasDiagType_t diag,
                           int n, int k, const cuDoubleComplex *A, int lda,
                           cuDoubleComplex *x, int incx)

This function supports the 64-bit Integer Interface.

This function solves the triangular banded linear system with a single right-hand-side

\(\text{op}(A)\textbf{x} = \textbf{b}\)

where \(A\) is a triangular banded matrix, and \(\mathbf{x}\) and \(\mathbf{b}\) are vectors. Also, for matrix \(A\)

\(\text{op}(A) = \left\{ \begin{matrix} A & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_N}$}} \\ A^{T} & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_T}$}} \\ A^{H} & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_C}$}} \\ \end{matrix} \right.\)

The solution \(\mathbf{x}\) overwrites the right-hand-sides \(\mathbf{b}\) on exit.

No test for singularity or near-singularity is included in this function.

If uplo == CUBLAS_FILL_MODE_LOWER then the triangular banded matrix \(A\) is stored column by column, with the main diagonal of the matrix stored in row 1, the first subdiagonal in row 2 (starting at first position), the second subdiagonal in row 3 (starting at first position), etc. So that in general, the element \(A(i,j)\) is stored in the memory location A(1+i-j,j) for \(j = 1,\ldots,n\) and \(i \in \lbrack j,\min(m,j + k)\rbrack\) . Also, the elements in the array A that do not conceptually correspond to the elements in the banded matrix (the bottom right \(k \times k\) triangle) are not referenced.

If uplo == CUBLAS_FILL_MODE_UPPER then the triangular banded matrix \(A\) is stored column by column, with the main diagonal of the matrix stored in row k+1, the first superdiagonal in row k (starting at second position), the second superdiagonal in row k-1 (starting at third position), etc. So that in general, the element \(A(i,j)\) is stored in the memory location A(1+k+i-j,j) for \(j = 1,\ldots,n\) and \(i \in \lbrack\max(1,j - k,j)\rbrack\) . Also, the elements in the array A that do not conceptually correspond to the elements in the banded matrix (the top left \(k \times k\) triangle) are not referenced.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

uplo

input

indicates if matrix A lower or upper part is stored, the other part is not referenced and is inferred from the stored elements.

trans

input

operation op(A) that is non- or (conj.) transpose.

diag

input

indicates if the elements on the main diagonal of matrix A are unity and should not be accessed.

n

input

number of rows and columns of matrix A.

k

input

number of sub- and super-diagonals of matrix A.

A

device

input

<type> array of dimension lda x n, with lda >= k+1.

lda

input

leading dimension of two-dimensional array used to store matrix A.

x

device

in/out

<type> vector with n elements.

incx

input

stride between consecutive elements of x.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If n < 0 or k < 0 or

  • if incx = 0 or

  • if trans != CUBLAS_OP_N, CUBLAS_OP_C, CUBLAS_OP_T or

  • if uplo != CUBLAS_FILL_MODE_LOWER, CUBLAS_FILL_MODE_UPPER or

  • if diag != CUBLAS_DIAG_UNIT, CUBLAS_DIAG_NON_UNIT or

  • lda < (1 + k)

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

stbsv, dtbsv, ctbsv, ztbsv

2.6.13. cublas<t>tpmv()

cublasStatus_t cublasStpmv(cublasHandle_t handle, cublasFillMode_t uplo,
                           cublasOperation_t trans, cublasDiagType_t diag,
                           int n, const float           *AP,
                           float           *x, int incx)
cublasStatus_t cublasDtpmv(cublasHandle_t handle, cublasFillMode_t uplo,
                           cublasOperation_t trans, cublasDiagType_t diag,
                           int n, const double          *AP,
                           double          *x, int incx)
cublasStatus_t cublasCtpmv(cublasHandle_t handle, cublasFillMode_t uplo,
                           cublasOperation_t trans, cublasDiagType_t diag,
                           int n, const cuComplex       *AP,
                           cuComplex       *x, int incx)
cublasStatus_t cublasZtpmv(cublasHandle_t handle, cublasFillMode_t uplo,
                           cublasOperation_t trans, cublasDiagType_t diag,
                           int n, const cuDoubleComplex *AP,
                           cuDoubleComplex *x, int incx)

This function supports the 64-bit Integer Interface.

This function performs the triangular packed matrix-vector multiplication

\(\textbf{x} = \text{op}(A)\textbf{x}\)

where \(A\) is a triangular matrix stored in packed format, and \(\mathbf{x}\) is a vector. Also, for matrix \(A\)

\(\text{op}(A) = \left\{ \begin{matrix} A & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_N}$}} \\ A^{T} & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_T}$}} \\ A^{H} & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_C}$}} \\ \end{matrix} \right.\)

If uplo == CUBLAS_FILL_MODE_LOWER then the elements in the lower triangular part of the triangular matrix \(A\) are packed together column by column without gaps, so that the element \(A(i,j)\) is stored in the memory location AP[i+((2*n-j+1)*j)/2] for \(j = 1,\ldots,n\) and \(i \geq j\) . Consequently, the packed format requires only \(\frac{n(n + 1)}{2}\) elements for storage.

If uplo == CUBLAS_FILL_MODE_UPPER then the elements in the upper triangular part of the triangular matrix \(A\) are packed together column by column without gaps, so that the element \(A(i,j)\) is stored in the memory location AP[i+(j*(j+1))/2] for \(A(i,j)\) and \(i \leq j\) . Consequently, the packed format requires only \(\frac{n(n + 1)}{2}\) elements for storage.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

uplo

input

indicates if matrix A lower or upper part is stored, the other part is not referenced and is inferred from the stored elements.

trans

input

operation op(A) that is non- or (conj.) transpose.

diag

input

indicates if the elements on the main diagonal of matrix A are unity and should not be accessed.

n

input

number of rows and columns of matrix A.

AP

device

input

<type> array with \(A\) stored in packed format.

x

device

in/out

<type> vector with n elements.

incx

input

stride between consecutive elements of x.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If n < 0 or

  • if incx == 0 or

  • if uplo != CUBLAS_FILL_MODE_UPPER, CUBLAS_FILL_MODE_LOWER or

  • if trans != CUBLAS_OP_N, CUBLAS_OP_T, CUBLAS_OP_C or

  • diag != CUBLAS_DIAG_UNIT, CUBLAS_DIAG_NON_UNIT

CUBLAS_STATUS_ALLOC_FAILED

the allocation of internal scratch memory failed

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

stpmv, dtpmv, ctpmv, ztpmv

2.6.14. cublas<t>tpsv()

cublasStatus_t cublasStpsv(cublasHandle_t handle, cublasFillMode_t uplo,
                           cublasOperation_t trans, cublasDiagType_t diag,
                           int n, const float           *AP,
                           float           *x, int incx)
cublasStatus_t cublasDtpsv(cublasHandle_t handle, cublasFillMode_t uplo,
                           cublasOperation_t trans, cublasDiagType_t diag,
                           int n, const double          *AP,
                           double          *x, int incx)
cublasStatus_t cublasCtpsv(cublasHandle_t handle, cublasFillMode_t uplo,
                           cublasOperation_t trans, cublasDiagType_t diag,
                           int n, const cuComplex       *AP,
                           cuComplex       *x, int incx)
cublasStatus_t cublasZtpsv(cublasHandle_t handle, cublasFillMode_t uplo,
                           cublasOperation_t trans, cublasDiagType_t diag,
                           int n, const cuDoubleComplex *AP,
                           cuDoubleComplex *x, int incx)

This function supports the 64-bit Integer Interface.

This function solves the packed triangular linear system with a single right-hand-side

\(\text{op}(A)\textbf{x} = \textbf{b}\)

where \(A\) is a triangular matrix stored in packed format, and \(\mathbf{x}\) and \(\mathbf{b}\) are vectors. Also, for matrix \(A\)

\(\text{op}(A) = \left\{ \begin{matrix} A & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_N}$}} \\ A^{T} & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_T}$}} \\ A^{H} & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_C}$}} \\ \end{matrix} \right.\)

The solution \(\mathbf{x}\) overwrites the right-hand-sides \(\mathbf{b}\) on exit.

No test for singularity or near-singularity is included in this function.

If uplo == CUBLAS_FILL_MODE_LOWER then the elements in the lower triangular part of the triangular matrix \(A\) are packed together column by column without gaps, so that the element \(A(i,j)\) is stored in the memory location AP[i+((2*n-j+1)*j)/2] for \(j = 1,\ldots,n\) and \(i \geq j\) . Consequently, the packed format requires only \(\frac{n(n + 1)}{2}\) elements for storage.

If uplo == CUBLAS_FILL_MODE_UPPER then the elements in the upper triangular part of the triangular matrix \(A\) are packed together column by column without gaps, so that the element \(A(i,j)\) is stored in the memory location AP[i+(j*(j+1))/2] for \(j = 1,\ldots,n\) and \(i \leq j\) . Consequently, the packed format requires only \(\frac{n(n + 1)}{2}\) elements for storage.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

uplo

input

indicates if matrix A lower or upper part is stored, the other part is not referenced and is inferred from the stored elements.

trans

input

operation op(A) that is non- or (conj.) transpose.

diag

input

indicates if the elements on the main diagonal of matrix are unity and should not be accessed.

n

input

number of rows and columns of matrix A.

AP

device

input

<type> array with A stored in packed format.

x

device

in/out

<type> vector with n elements.

incx

input

stride between consecutive elements of x.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If n < 0 or

  • if incx = 0 or

  • if trans != CUBLAS_OP_N, CUBLAS_OP_C, CUBLAS_OP_T or

  • if uplo != CUBLAS_FILL_MODE_LOWER, CUBLAS_FILL_MODE_UPPER or

  • diag != CUBLAS_DIAG_UNIT, CUBLAS_DIAG_NON_UNIT

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

stpsv, dtpsv, ctpsv, ztpsv

2.6.15. cublas<t>trmv()

cublasStatus_t cublasStrmv(cublasHandle_t handle, cublasFillMode_t uplo,
                           cublasOperation_t trans, cublasDiagType_t diag,
                           int n, const float           *A, int lda,
                           float           *x, int incx)
cublasStatus_t cublasDtrmv(cublasHandle_t handle, cublasFillMode_t uplo,
                           cublasOperation_t trans, cublasDiagType_t diag,
                           int n, const double          *A, int lda,
                           double          *x, int incx)
cublasStatus_t cublasCtrmv(cublasHandle_t handle, cublasFillMode_t uplo,
                           cublasOperation_t trans, cublasDiagType_t diag,
                           int n, const cuComplex       *A, int lda,
                           cuComplex       *x, int incx)
cublasStatus_t cublasZtrmv(cublasHandle_t handle, cublasFillMode_t uplo,
                           cublasOperation_t trans, cublasDiagType_t diag,
                           int n, const cuDoubleComplex *A, int lda,
                           cuDoubleComplex *x, int incx)

This function supports the 64-bit Integer Interface.

This function performs the triangular matrix-vector multiplication

\(\textbf{x} = \text{op}(A)\textbf{x}\)

where \(A\) is a triangular matrix stored in lower or upper mode with or without the main diagonal, and \(\mathbf{x}\) is a vector. Also, for matrix \(A\)

\(\text{op}(A) = \left\{ \begin{matrix} A & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_N}$}} \\ A^{T} & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_T}$}} \\ A^{H} & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_C}$}} \\ \end{matrix} \right.\)

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

uplo

input

indicates if matrix A lower or upper part is stored, the other part is not referenced and is inferred from the stored elements.

trans

input

operation op(A) (that is, non- or conj.) transpose.

diag

input

indicates if the elements on the main diagonal of matrix A are unity and should not be accessed.

n

input

number of rows and columns of matrix A.

A

device

input

<type> array of dimensions lda x n , with lda>=max(1,n).

lda

input

leading dimension of two-dimensional array used to store matrix A.

x

device

in/out

<type> vector with n elements.

incx

input

stride between consecutive elements of x.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If n < 0 or

  • if incx = 0 or

  • if trans != CUBLAS_OP_N, CUBLAS_OP_C, CUBLAS_OP_T or

  • if uplo != CUBLAS_FILL_MODE_LOWER, CUBLAS_FILL_MODE_UPPER or

  • if diag != CUBLAS_DIAG_UNIT, CUBLAS_DIAG_NON_UNIT or

  • lda < max(1, n)

CUBLAS_STATUS_ALLOC_FAILED

the allocation of internal scratch memory failed

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

strmv, dtrmv, ctrmv, ztrmv

2.6.16. cublas<t>trsv()

cublasStatus_t cublasStrsv(cublasHandle_t handle, cublasFillMode_t uplo,
                           cublasOperation_t trans, cublasDiagType_t diag,
                           int n, const float           *A, int lda,
                           float           *x, int incx)
cublasStatus_t cublasDtrsv(cublasHandle_t handle, cublasFillMode_t uplo,
                           cublasOperation_t trans, cublasDiagType_t diag,
                           int n, const double          *A, int lda,
                           double          *x, int incx)
cublasStatus_t cublasCtrsv(cublasHandle_t handle, cublasFillMode_t uplo,
                           cublasOperation_t trans, cublasDiagType_t diag,
                           int n, const cuComplex       *A, int lda,
                           cuComplex       *x, int incx)
cublasStatus_t cublasZtrsv(cublasHandle_t handle, cublasFillMode_t uplo,
                           cublasOperation_t trans, cublasDiagType_t diag,
                           int n, const cuDoubleComplex *A, int lda,
                           cuDoubleComplex *x, int incx)

This function supports the 64-bit Integer Interface.

This function solves the triangular linear system with a single right-hand-side

\(\text{op}(A)\textbf{x} = \textbf{b}\)

where \(A\) is a triangular matrix stored in lower or upper mode with or without the main diagonal, and \(\mathbf{x}\) and \(\mathbf{b}\) are vectors. Also, for matrix \(A\)

\(\text{op}(A) = \left\{ \begin{matrix} A & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_N}$}} \\ A^{T} & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_T}$}} \\ A^{H} & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_C}$}} \\ \end{matrix} \right.\)

The solution \(\mathbf{x}\) overwrites the right-hand-sides \(\mathbf{b}\) on exit.

No test for singularity or near-singularity is included in this function.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

uplo

input

indicates if matrix A lower or upper part is stored, the other part is not referenced and is inferred from the stored elements.

trans

input

operation op(A) that is non- or (conj.) transpose.

diag

input

indicates if the elements on the main diagonal of matrix A are unity and should not be accessed.

n

input

number of rows and columns of matrix A.

A

device

input

<type> array of dimension lda x n, with lda>=max(1,n).

lda

input

leading dimension of two-dimensional array used to store matrix A.

x

device

in/out

<type> vector with n elements.

incx

input

stride between consecutive elements of x.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If n < 0 or

  • if incx = 0 or

  • if trans != CUBLAS_OP_N, CUBLAS_OP_C, CUBLAS_OP_T or

  • if uplo != CUBLAS_FILL_MODE_LOWER, CUBLAS_FILL_MODE_UPPER or

  • if diag != CUBLAS_DIAG_UNIT, CUBLAS_DIAG_NON_UNIT or

  • lda < max(1, n)

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

strsv, dtrsv, ctrsv, ztrsv

2.6.17. cublas<t>hemv()

cublasStatus_t cublasChemv(cublasHandle_t handle, cublasFillMode_t uplo,
                           int n, const cuComplex       *alpha,
                           const cuComplex       *A, int lda,
                           const cuComplex       *x, int incx,
                           const cuComplex       *beta,
                           cuComplex       *y, int incy)
cublasStatus_t cublasZhemv(cublasHandle_t handle, cublasFillMode_t uplo,
                           int n, const cuDoubleComplex *alpha,
                           const cuDoubleComplex *A, int lda,
                           const cuDoubleComplex *x, int incx,
                           const cuDoubleComplex *beta,
                           cuDoubleComplex *y, int incy)

This function supports the 64-bit Integer Interface.

This function performs the Hermitian matrix-vector multiplication

\(\textbf{y} = \alpha A\textbf{x} + \beta\textbf{y}\)

where \(A\) is a \(n \times n\) Hermitian matrix stored in lower or upper mode, \(\mathbf{x}\) and \(\mathbf{y}\) are vectors, and \(\alpha\) and \(\beta\) are scalars.

This function has an alternate faster implementation using atomics that can be enabled with

Please see the section on the for more details about the usage of atomics

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

uplo

input

indicates if matrix A lower or upper part is stored, the other Hermitian part is not referenced and is inferred from the stored elements.

n

input

number of rows and columns of matrix A.

alpha

host or device

input

<type> scalar used for multiplication.

A

device

input

<type> array of dimension lda x n, with lda>=max(1,n). The imaginary parts of the diagonal elements are assumed to be zero.

lda

input

leading dimension of two-dimensional array used to store matrix A.

x

device

input

<type> vector with n elements.

incx

input

stride between consecutive elements of x.

beta

host or device

input

<type> scalar used for multiplication, if beta==0 then y does not have to be a valid input.

y

device

in/out

<type> vector with n elements.

incy

input

stride between consecutive elements of y.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If n < 0 or

  • if incx = 0 or incy = 0 or

  • if uplo != CUBLAS_FILL_MODE_LOWER, CUBLAS_FILL_MODE_UPPER or

  • lda < n

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

chemv, zhemv

2.6.18. cublas<t>hbmv()

cublasStatus_t cublasChbmv(cublasHandle_t handle, cublasFillMode_t uplo,
                          int n, int k, const cuComplex       *alpha,
                          const cuComplex       *A, int lda,
                          const cuComplex       *x, int incx,
                          const cuComplex       *beta,
                          cuComplex       *y, int incy)
cublasStatus_t cublasZhbmv(cublasHandle_t handle, cublasFillMode_t uplo,
                          int n, int k, const cuDoubleComplex *alpha,
                          const cuDoubleComplex *A, int lda,
                          const cuDoubleComplex *x, int incx,
                          const cuDoubleComplex *beta,
                          cuDoubleComplex *y, int incy)

This function supports the 64-bit Integer Interface.

This function performs the Hermitian banded matrix-vector multiplication

\(\textbf{y} = \alpha A\textbf{x} + \beta\textbf{y}\)

where \(A\) is a \(n \times n\) Hermitian banded matrix with \(k\) subdiagonals and superdiagonals, \(\mathbf{x}\) and \(\mathbf{y}\) are vectors, and \(\alpha\) and \(\beta\) are scalars.

If uplo == CUBLAS_FILL_MODE_LOWER then the Hermitian banded matrix \(A\) is stored column by column, with the main diagonal of the matrix stored in row 1, the first subdiagonal in row 2 (starting at first position), the second subdiagonal in row 3 (starting at first position), etc. So that in general, the element \(A(i,j)\) is stored in the memory location A(1+i-j,j) for \(j = 1,\ldots,n\) and \(i \in \lbrack j,\min(m,j + k)\rbrack\) . Also, the elements in the array A that do not conceptually correspond to the elements in the banded matrix (the bottom right \(k \times k\) triangle) are not referenced.

If uplo == CUBLAS_FILL_MODE_UPPER then the Hermitian banded matrix \(A\) is stored column by column, with the main diagonal of the matrix stored in row k+1, the first superdiagonal in row k (starting at second position), the second superdiagonal in row k-1 (starting at third position), etc. So that in general, the element \(A(i,j)\) is stored in the memory location A(1+k+i-j,j) for \(j = 1,\ldots,n\) and \(i \in \lbrack\max(1,j - k),j\rbrack\) . Also, the elements in the array A that do not conceptually correspond to the elements in the banded matrix (the top left \(k \times k\) triangle) are not referenced.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

uplo

input

indicates if matrix A lower or upper part is stored, the other Hermitian part is not referenced and is inferred from the stored elements.

n

input

number of rows and columns of matrix A.

k

input

number of sub- and super-diagonals of matrix A.

alpha

host or device

input

<type> scalar used for multiplication.

A

device

input

<type> array of dimensions lda x n, with lda>=k+1. The imaginary parts of the diagonal elements are assumed to be zero.

lda

input

leading dimension of two-dimensional array used to store matrix A.

x

device

input

<type> vector with n elements.

incx

input

stride between consecutive elements of x.

beta

host or device

input

<type> scalar used for multiplication, if beta==0 then does not have to be a valid input.

y

device

in/out

<type> vector with n elements.

incy

input

stride between consecutive elements of y.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If n < 0 or k < 0 or

  • if incx = 0 or incy = 0 or

  • if uplo != CUBLAS_FILL_MODE_LOWER, CUBLAS_FILL_MODE_UPPER or

  • if lda < (k + 1) or

  • alpha == NULL or beta == NULL

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

chbmv, zhbmv

2.6.19. cublas<t>hpmv()

cublasStatus_t cublasChpmv(cublasHandle_t handle, cublasFillMode_t uplo,
                           int n, const cuComplex       *alpha,
                           const cuComplex       *AP,
                           const cuComplex       *x, int incx,
                           const cuComplex       *beta,
                           cuComplex       *y, int incy)
cublasStatus_t cublasZhpmv(cublasHandle_t handle, cublasFillMode_t uplo,
                           int n, const cuDoubleComplex *alpha,
                           const cuDoubleComplex *AP,
                           const cuDoubleComplex *x, int incx,
                           const cuDoubleComplex *beta,
                           cuDoubleComplex *y, int incy)

This function supports the 64-bit Integer Interface.

This function performs the Hermitian packed matrix-vector multiplication

\(\textbf{y} = \alpha A\textbf{x} + \beta\textbf{y}\)

where \(A\) is a \(n \times n\) Hermitian matrix stored in packed format, \(\mathbf{x}\) and \(\mathbf{y}\) are vectors, and \(\alpha\) and \(\beta\) are scalars.

If uplo == CUBLAS_FILL_MODE_LOWER then the elements in the lower triangular part of the Hermitian matrix \(A\) are packed together column by column without gaps, so that the element \(A(i,j)\) is stored in the memory location AP[i+((2*n-j+1)*j)/2] for \(j = 1,\ldots,n\) and \(i \geq j\) . Consequently, the packed format requires only \(\frac{n(n + 1)}{2}\) elements for storage.

If uplo == CUBLAS_FILL_MODE_UPPER then the elements in the upper triangular part of the Hermitian matrix \(A\) are packed together column by column without gaps, so that the element \(A(i,j)\) is stored in the memory location AP[i+(j*(j+1))/2] for \(j = 1,\ldots,n\) and \(i \leq j\) . Consequently, the packed format requires only \(\frac{n(n + 1)}{2}\) elements for storage.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

uplo

input

indicates if matrix A lower or upper part is stored, the other Hermitian part is not referenced and is inferred from the stored elements.

n

input

number of rows and columns of matrix A.

alpha

host or device

input

<type> scalar used for multiplication.

AP

device

input

<type> array with A stored in packed format. The imaginary parts of the diagonal elements are assumed to be zero.

x

device

input

<type> vector with n elements.

incx

input

stride between consecutive elements of x.

beta

host or device

input

<type> scalar used for multiplication, if beta==0 then y does not have to be a valid input.

y

device

in/out

<type> vector with n elements.

incy

input

stride between consecutive elements of y.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If n < 0 or

  • if incx == 0 or incy == 0 or

  • if uplo != CUBLAS_FILL_MODE_UPPER, CUBLAS_FILL_MODE_LOWER or

  • alpha == NULL or beta == NULL

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

chpmv, zhpmv

2.6.20. cublas<t>her()

cublasStatus_t cublasCher(cublasHandle_t handle, cublasFillMode_t uplo,
                          int n, const float  *alpha,
                          const cuComplex       *x, int incx,
                          cuComplex       *A, int lda)
cublasStatus_t cublasZher(cublasHandle_t handle, cublasFillMode_t uplo,
                          int n, const double *alpha,
                          const cuDoubleComplex *x, int incx,
                          cuDoubleComplex *A, int lda)

This function supports the 64-bit Integer Interface.

This function performs the Hermitian rank-1 update

\(A = \alpha\textbf{x}\textbf{x}^{H} + A\)

where \(A\) is a \(n \times n\) Hermitian matrix stored in column-major format, \(\mathbf{x}\) is a vector, and \(\alpha\) is a scalar.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

uplo

input

indicates if matrix A lower or upper part is stored, the other Hermitian part is not referenced and is inferred from the stored elements.

n

input

number of rows and columns of matrix A.

alpha

host or device

input

<type> scalar used for multiplication.

x

device

input

<type> vector with n elements.

incx

input

stride between consecutive elements of x.

A

device

in/out

<type> array of dimensions lda x n, with lda>=max(1,n). The imaginary parts of the diagonal elements are assumed and set to zero.

lda

input

leading dimension of two-dimensional array used to store matrix A.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If n < 0 or

  • if incx == 0 or

  • if uplo != CUBLAS_FILL_MODE_UPPER, CUBLAS_FILL_MODE_LOWER or

  • if lda < max(1, n) or

  • alpha == NULL

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

cher, zher

2.6.21. cublas<t>her2()

cublasStatus_t cublasCher2(cublasHandle_t handle, cublasFillMode_t uplo,
                           int n, const cuComplex       *alpha,
                           const cuComplex       *x, int incx,
                           const cuComplex       *y, int incy,
                           cuComplex       *A, int lda)
cublasStatus_t cublasZher2(cublasHandle_t handle, cublasFillMode_t uplo,
                           int n, const cuDoubleComplex *alpha,
                           const cuDoubleComplex *x, int incx,
                           const cuDoubleComplex *y, int incy,
                           cuDoubleComplex *A, int lda)

This function supports the 64-bit Integer Interface.

This function performs the Hermitian rank-2 update

\(A = \alpha\textbf{x}\textbf{y}^{H} + \overset{ˉ}{\alpha}\textbf{y}\textbf{x}^{H} + A\)

where \(A\) is a \(n \times n\) Hermitian matrix stored in column-major format, \(\mathbf{x}\) and \(\mathbf{y}\) are vectors, and \(\alpha\) is a scalar.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

uplo

input

indicates if matrix A lower or upper part is stored, the other Hermitian part is not referenced and is inferred from the stored elements.

n

input

number of rows and columns of matrix A.

alpha

host or device

input

<type> scalar used for multiplication.

x

device

input

<type> vector with n elements.

incx

input

stride between consecutive elements of x.

y

device

input

<type> vector with n elements.

incy

input

stride between consecutive elements of y.

A

device

in/out

<type> array of dimension lda x n with lda>=max(1,n). The imaginary parts of the diagonal elements are assumed and set to zero.

lda

input

leading dimension of two-dimensional array used to store matrix A.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If n < 0 or

  • if incx == 0 or incy == 0 or

  • if uplo != CUBLAS_FILL_MODE_UPPER, CUBLAS_FILL_MODE_LOWER or

  • if lda < max(1, n) or

  • alpha == NULL

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

cher2, zher2

2.6.22. cublas<t>hpr()

cublasStatus_t cublasChpr(cublasHandle_t handle, cublasFillMode_t uplo,
                          int n, const float *alpha,
                          const cuComplex       *x, int incx,
                          cuComplex       *AP)
cublasStatus_t cublasZhpr(cublasHandle_t handle, cublasFillMode_t uplo,
                          int n, const double *alpha,
                          const cuDoubleComplex *x, int incx,
                          cuDoubleComplex *AP)

This function supports the 64-bit Integer Interface.

This function performs the packed Hermitian rank-1 update

\(A = \alpha\textbf{x}\textbf{x}^{H} + A\)

where \(A\) is a \(n \times n\) Hermitian matrix stored in packed format, \(\mathbf{x}\) is a vector, and \(\alpha\) is a scalar.

If uplo == CUBLAS_FILL_MODE_LOWER then the elements in the lower triangular part of the Hermitian matrix \(A\) are packed together column by column without gaps, so that the element \(A(i,j)\) is stored in the memory location AP[i+((2*n-j+1)*j)/2] for \(j = 1,\ldots,n\) and \(i \geq j\) . Consequently, the packed format requires only \(\frac{n(n + 1)}{2}\) elements for storage.

If uplo == CUBLAS_FILL_MODE_UPPER then the elements in the upper triangular part of the Hermitian matrix \(A\) are packed together column by column without gaps, so that the element \(A(i,j)\) is stored in the memory location AP[i+(j*(j+1))/2] for \(j = 1,\ldots,n\) and \(i \leq j\) . Consequently, the packed format requires only \(\frac{n(n + 1)}{2}\) elements for storage.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

uplo

input

indicates if matrix A lower or upper part is stored, the other Hermitian part is not referenced and is inferred from the stored elements.

n

input

number of rows and columns of matrix A.

alpha

host or device

input

<type> scalar used for multiplication.

x

device

input

<type> vector with n elements.

incx

input

stride between consecutive elements of x.

AP

device

in/out

<type> array with A stored in packed format. The imaginary parts of the diagonal elements are assumed and set to zero.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If n < 0 or

  • if incx == 0 or

  • if uplo != CUBLAS_FILL_MODE_UPPER, CUBLAS_FILL_MODE_LOWER or

  • alpha == NULL

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

chpr, zhpr

2.6.23. cublas<t>hpr2()

cublasStatus_t cublasChpr2(cublasHandle_t handle, cublasFillMode_t uplo,
                           int n, const cuComplex       *alpha,
                           const cuComplex       *x, int incx,
                           const cuComplex       *y, int incy,
                           cuComplex       *AP)
cublasStatus_t cublasZhpr2(cublasHandle_t handle, cublasFillMode_t uplo,
                           int n, const cuDoubleComplex *alpha,
                           const cuDoubleComplex *x, int incx,
                           const cuDoubleComplex *y, int incy,
                           cuDoubleComplex *AP)

This function supports the 64-bit Integer Interface.

This function performs the packed Hermitian rank-2 update

\(A = \alpha\textbf{x}\textbf{y}^{H} + \overset{ˉ}{\alpha}\textbf{y}\textbf{x}^{H} + A\)

where \(A\) is a \(n \times n\) Hermitian matrix stored in packed format, \(\mathbf{x}\) and \(\mathbf{y}\) are vectors, and \(\alpha\) is a scalar.

If uplo == CUBLAS_FILL_MODE_LOWER then the elements in the lower triangular part of the Hermitian matrix \(A\) are packed together column by column without gaps, so that the element \(A(i,j)\) is stored in the memory location AP[i+((2*n-j+1)*j)/2] for \(j = 1,\ldots,n\) and \(i \geq j\) . Consequently, the packed format requires only \(\frac{n(n + 1)}{2}\) elements for storage.

If uplo == CUBLAS_FILL_MODE_UPPER then the elements in the upper triangular part of the Hermitian matrix \(A\) are packed together column by column without gaps, so that the element \(A(i,j)\) is stored in the memory location AP[i+(j*(j+1))/2] for \(j = 1,\ldots,n\) and \(i \leq j\) . Consequently, the packed format requires only \(\frac{n(n + 1)}{2}\) elements for storage.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

uplo

input

indicates if matrix A lower or upper part is stored, the other Hermitian part is not referenced and is inferred from the stored elements.

n

input

number of rows and columns of matrix A.

alpha

host or device

input

<type> scalar used for multiplication.

x

device

input

<type> vector with n elements.

incx

input

stride between consecutive elements of x.

y

device

input

<type> vector with n elements.

incy

input

stride between consecutive elements of y.

AP

device

in/out

<type> array with A stored in packed format. The imaginary parts of the diagonal elements are assumed and set to zero.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If n < 0 or

  • if incx == 0 or incy == 0 or

  • if uplo != CUBLAS_FILL_MODE_UPPER, CUBLAS_FILL_MODE_LOWER or

  • alpha == NULL

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

chpr2, zhpr2

2.6.24. cublas<t>gemvBatched()

cublasStatus_t cublasSgemvBatched(cublasHandle_t handle, cublasOperation_t trans,
                                  int m, int n,
                                  const float           *alpha,
                                  const float           *const Aarray[], int lda,
                                  const float           *const xarray[], int incx,
                                  const float           *beta,
                                  float           *const yarray[], int incy,
                                  int batchCount)
cublasStatus_t cublasDgemvBatched(cublasHandle_t handle, cublasOperation_t trans,
                                  int m, int n,
                                  const double          *alpha,
                                  const double          *const Aarray[], int lda,
                                  const double          *const xarray[], int incx,
                                  const double          *beta,
                                  double          *const yarray[], int incy,
                                  int batchCount)
cublasStatus_t cublasCgemvBatched(cublasHandle_t handle, cublasOperation_t trans,
                                  int m, int n,
                                  const cuComplex       *alpha,
                                  const cuComplex       *const Aarray[], int lda,
                                  const cuComplex       *const xarray[], int incx,
                                  const cuComplex       *beta,
                                  cuComplex       *const yarray[], int incy,
                                  int batchCount)
cublasStatus_t cublasZgemvBatched(cublasHandle_t handle, cublasOperation_t trans,
                                  int m, int n,
                                  const cuDoubleComplex *alpha,
                                  const cuDoubleComplex *const Aarray[], int lda,
                                  const cuDoubleComplex *const xarray[], int incx,
                                  const cuDoubleComplex *beta,
                                  cuDoubleComplex *const yarray[], int incy,
                                  int batchCount)

#if defined(__cplusplus)
cublasStatus_t cublasHSHgemvBatched(cublasHandle_t handle, cublasOperation_t trans,
                                    int m, int n,
                                    const float           *alpha,
                                    const __half          *const Aarray[], int lda,
                                    const __half          *const xarray[], int incx,
                                    const float           *beta,
                                    __half                *const yarray[], int incy,
                                    int batchCount)
cublasStatus_t cublasHSSgemvBatched(cublasHandle_t handle, cublasOperation_t trans,
                                    int m, int n,
                                    const float           *alpha,
                                    const __half          *const Aarray[], int lda,
                                    const __half          *const xarray[], int incx,
                                    const float           *beta,
                                    float                 *const yarray[], int incy,
                                    int batchCount)
cublasStatus_t cublasTSTgemvBatched(cublasHandle_t handle, cublasOperation_t trans,
                                    int m, int n,
                                    const float           *alpha,
                                    const __nv_bfloat16   *const Aarray[], int lda,
                                    const __nv_bfloat16   *const xarray[], int incx,
                                    const float           *beta,
                                    __nv_bfloat16         *const yarray[], int incy,
                                    int batchCount)
cublasStatus_t cublasTSSgemvBatched(cublasHandle_t handle, cublasOperation_t trans,
                                    int m, int n,
                                    const float           *alpha,
                                    const __nv_bfloat16   *const Aarray[], int lda,
                                    const __nv_bfloat16   *const xarray[], int incx,
                                    const float           *beta,
                                    float                 *const yarray[], int incy,
                                    int batchCount)
#endif

This function supports the 64-bit Integer Interface.

This function performs the matrix-vector multiplication of a batch of matrices and vectors. The batch is considered to be “uniform”, i.e. all instances have the same dimensions (m, n), leading dimension (lda), increments (incx, incy) and transposition (trans) for their respective A matrix, x and y vectors. The address of the input matrix and vector, and the output vector of each instance of the batch are read from arrays of pointers passed to the function by the caller.

\(\textbf{y}\lbrack i\rbrack = \alpha\text{op}(A\lbrack i\rbrack)\textbf{x}\lbrack i\rbrack + \beta\textbf{y}\lbrack i\rbrack,\text{ for i} \in \lbrack 0,batchCount - 1\rbrack\)

where \(\alpha\) and \(\beta\) are scalars, and \(A\) is an array of pointers to matrice \(A\lbrack i\rbrack\) stored in column-major format with dimension \(m \times n\) , and \(\textbf{x}\) and \(\textbf{y}\) are arrays of pointers to vectors. Also, for matrix \(A\lbrack i\rbrack\) ,

\(\text{op}(A\lbrack i\rbrack) = \left\{ \begin{matrix} {A\lbrack i\rbrack} & {\text{if }\textsf{trans == $\mathrm{CUBLAS\_OP\_N}$}} \\ {A\lbrack i\rbrack}^{T} & {\text{if }\textsf{trans == $\mathrm{CUBLAS\_OP\_T}$}} \\ {A\lbrack i\rbrack}^{H} & {\text{if }\textsf{trans == $\mathrm{CUBLAS\_OP\_C}$}} \\ \end{matrix} \right.\)

Note

\(\textbf{y}\lbrack i\rbrack\) vectors must not overlap, i.e. the individual gemv operations must be computable independently; otherwise, undefined behavior is expected.

On certain problem sizes, it might be advantageous to make multiple calls to cublas<t>gemv in different CUDA streams, rather than use this API.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

trans

input

operation op(A[i]) that is non- or (conj.) transpose.

m

input

number of rows of matrix A[i].

n

input

number of columns of matrix A[i].

alpha

host or device

input

<type> scalar used for multiplication.

Aarray

device

input

array of pointers to <type> array, with each array of dim. lda x n with lda>=max(1,m).

All pointers must meet certain alignment criteria. Please see below for details.

lda

input

leading dimension of two-dimensional array used to store each matrix A[i].

xarray

device

input

array of pointers to <type> array, with each dimension n if trans==CUBLAS_OP_N and m otherwise.

All pointers must meet certain alignment criteria. Please see below for details.

incx

input

stride of each one-dimensional array x[i].

beta

host or device

input

<type> scalar used for multiplication. If beta == 0, y does not have to be a valid input.

yarray

device

in/out

array of pointers to <type> array. It has dimensions m if trans==CUBLAS_OP_N and n otherwise. Vectors y[i] should not overlap; otherwise, undefined behavior is expected.

All pointers must meet certain alignment criteria. Please see below for details.

incy

input

stride of each one-dimensional array y[i].

batchCount

input

number of pointers contained in Aarray, xarray and yarray.

If math mode enables fast math modes when using cublasSgemvBatched(), pointers (not the pointer arrays) placed in the GPU memory must be properly aligned to avoid misaligned memory access errors. Ideally all pointers are aligned to at least 16 Bytes. Otherwise it is recommended that they meet the following rule:

  • if k % 4==0 then ensure intptr_t(ptr) % 16 == 0,

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

the parameters m,n,batchCount<0

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

2.6.25. cublas<t>gemvStridedBatched()

cublasStatus_t cublasSgemvStridedBatched(cublasHandle_t handle,
                                         cublasOperation_t trans,
                                         int m, int n,
                                         const float           *alpha,
                                         const float           *A, int lda,
                                         long long int         strideA,
                                         const float           *x, int incx,
                                         long long int         stridex,
                                         const float           *beta,
                                         float                 *y, int incy,
                                         long long int         stridey,
                                         int batchCount)
cublasStatus_t cublasDgemvStridedBatched(cublasHandle_t handle,
                                         cublasOperation_t trans,
                                         int m, int n,
                                         const double          *alpha,
                                         const double          *A, int lda,
                                         long long int         strideA,
                                         const double          *x, int incx,
                                         long long int         stridex,
                                         const double          *beta,
                                         double                *y, int incy,
                                         long long int         stridey,
                                         int batchCount)
cublasStatus_t cublasCgemvStridedBatched(cublasHandle_t handle,
                                         cublasOperation_t trans,
                                         int m, int n,
                                         const cuComplex       *alpha,
                                         const cuComplex       *A, int lda,
                                         long long int         strideA,
                                         const cuComplex       *x, int incx,
                                         long long int         stridex,
                                         const cuComplex       *beta,
                                         cuComplex             *y, int incy,
                                         long long int         stridey,
                                         int batchCount)
cublasStatus_t cublasZgemvStridedBatched(cublasHandle_t handle,
                                         cublasOperation_t trans,
                                         int m, int n,
                                         const cuDoubleComplex *alpha,
                                         const cuDoubleComplex *A, int lda,
                                         long long int         strideA,
                                         const cuDoubleComplex *x, int incx,
                                         long long int         stridex,
                                         const cuDoubleComplex *beta,
                                         cuDoubleComplex       *y, int incy,
                                         long long int         stridey,
                                         int batchCount)
cublasStatus_t cublasHSHgemvStridedBatched(cublasHandle_t handle,
                                           cublasOperation_t trans,
                                           int m, int n,
                                           const float           *alpha,
                                           const __half          *A, int lda,
                                           long long int         strideA,
                                           const __half          *x, int incx,
                                           long long int         stridex,
                                           const float           *beta,
                                           __half                *y, int incy,
                                           long long int         stridey,
                                           int batchCount)
cublasStatus_t cublasHSSgemvStridedBatched(cublasHandle_t handle,
                                           cublasOperation_t trans,
                                           int m, int n,
                                           const float           *alpha,
                                           const __half          *A, int lda,
                                           long long int         strideA,
                                           const __half          *x, int incx,
                                           long long int         stridex,
                                           const float           *beta,
                                           float                 *y, int incy,
                                           long long int         stridey,
                                           int batchCount)
cublasStatus_t cublasTSTgemvStridedBatched(cublasHandle_t handle,
                                           cublasOperation_t trans,
                                           int m, int n,
                                           const float           *alpha,
                                           const __nv_bfloat16   *A, int lda,
                                           long long int         strideA,
                                           const __nv_bfloat16   *x, int incx,
                                           long long int         stridex,
                                           const float           *beta,
                                           __nv_bfloat16         *y, int incy,
                                           long long int         stridey,
                                           int batchCount)
cublasStatus_t cublasTSSgemvStridedBatched(cublasHandle_t handle,
                                           cublasOperation_t trans,
                                           int m, int n,
                                           const float           *alpha,
                                           const __nv_bfloat16   *A, int lda,
                                           long long int         strideA,
                                           const __nv_bfloat16   *x, int incx,
                                           long long int         stridex,
                                           const float           *beta,
                                           float                 *y, int incy,
                                           long long int         stridey,
                                           int batchCount)

This function supports the 64-bit Integer Interface.

This function performs the matrix-vector multiplication of a batch of matrices and vectors. The batch is considered to be “uniform”, i.e. all instances have the same dimensions (m, n), leading dimension (lda), increments (incx, incy) and transposition (trans) for their respective A matrix, x and y vectors. Input matrix A and vector x, and output vector y for each instance of the batch are located at fixed offsets in number of elements from their locations in the previous instance. Pointers to A matrix, x and y vectors for the first instance are passed to the function by the user along with offsets in number of elements - strideA, stridex and stridey that determine the locations of input matrices and vectors, and output vectors in future instances.

\(\textbf{y} + i*{stridey} = \alpha\text{op}(A + i*{strideA})(\textbf{x} + i*{stridex}) + \beta(\textbf{y} + i*{stridey}),\text{ for i } \in \lbrack 0,batchCount - 1\rbrack\)

where \(\alpha\) and \(\beta\) are scalars, and \(A\) is an array of pointers to matrix stored in column-major format with dimension \(A\lbrack i\rbrack\) \(m \times n\) , and \(\textbf{x}\) and \(\textbf{y}\) are arrays of pointers to vectors. Also, for matrix \(A\lbrack i\rbrack\)

\(\text{op}(A\lbrack i\rbrack) = \left\{ \begin{matrix} {A\lbrack i\rbrack} & {\text{if }\textsf{trans == $\mathrm{CUBLAS\_OP\_N}$}} \\ {A\lbrack i\rbrack}^{T} & {\text{if }\textsf{trans == $\mathrm{CUBLAS\_OP\_T}$}} \\ {A\lbrack i\rbrack}^{H} & {\text{if }\textsf{trans == $\mathrm{CUBLAS\_OP\_C}$}} \\ \end{matrix} \right.\)

Note

\(\textbf{y}\lbrack i\rbrack\) matrices must not overlap, i.e. the individual gemv operations must be computable independently; otherwise, undefined behavior is expected.

On certain problem sizes, it might be advantageous to make multiple calls to cublas<t>gemv in different CUDA streams, rather than use this API.

Note

In the table below, we use A[i], x[i], y[i] as notation for A matrix, and x and y vectors in the ith instance of the batch, implicitly assuming they are respectively offsets in number of elements strideA, stridex, stridey away from A[i-1], x[i-1], y[i-1]. The unit for the offset is number of elements and must not be zero .

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

trans

input

operation op(A[i]) that is non- or (conj.) transpose.

m

input

number of rows of matrix A[i].

n

input

number of columns of matrix A[i].

alpha

host or device

input

<type> scalar used for multiplication.

A

device

input

<type>* pointer to the A matrix corresponding to the first instance of the batch, with dimensions lda x n with lda>=max(1,m).

lda

input

leading dimension of two-dimensional array used to store each matrix A[i].

strideA

input

Value of type long long int that gives the offset in number of elements between A[i] and A[i+1]

x

device

input

<type>* pointer to the x vector corresponding to the first instance of the batch, with each dimension n if trans==CUBLAS_OP_N and m otherwise.

incx

input

stride of each one-dimensional array x[i].

stridex

input

Value of type long long int that gives the offset in number of elements between x[i] and x[i+1]

beta

host or device

input

<type> scalar used for multiplication. If beta == 0, y does not have to be a valid input.

y

device

in/out

<type>* pointer to the y vector corresponding to the first instance of the batch, with each dimension m if trans==CUBLAS_OP_N and n otherwise. Vectors y[i] should not overlap; otherwise, undefined behavior is expected.

incy

input

stride of each one-dimensional array y[i].

stridey

input

Value of type long long int that gives the offset in number of elements between y[i] and y[i+1]

batchCount

input

number of GEMVs to perform in the batch.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

the parameters m,n,batchCount<0

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

2.7. cuBLAS Level-3 Function Reference

In this chapter we describe the Level-3 Basic Linear Algebra Subprograms (BLAS3) functions that perform matrix-matrix operations.

2.7.1. cublas<t>gemm()

cublasStatus_t cublasSgemm(cublasHandle_t handle,
                           cublasOperation_t transa, cublasOperation_t transb,
                           int m, int n, int k,
                           const float           *alpha,
                           const float           *A, int lda,
                           const float           *B, int ldb,
                           const float           *beta,
                           float           *C, int ldc)
cublasStatus_t cublasDgemm(cublasHandle_t handle,
                           cublasOperation_t transa, cublasOperation_t transb,
                           int m, int n, int k,
                           const double          *alpha,
                           const double          *A, int lda,
                           const double          *B, int ldb,
                           const double          *beta,
                           double          *C, int ldc)
cublasStatus_t cublasCgemm(cublasHandle_t handle,
                           cublasOperation_t transa, cublasOperation_t transb,
                           int m, int n, int k,
                           const cuComplex       *alpha,
                           const cuComplex       *A, int lda,
                           const cuComplex       *B, int ldb,
                           const cuComplex       *beta,
                           cuComplex       *C, int ldc)
cublasStatus_t cublasZgemm(cublasHandle_t handle,
                           cublasOperation_t transa, cublasOperation_t transb,
                           int m, int n, int k,
                           const cuDoubleComplex *alpha,
                           const cuDoubleComplex *A, int lda,
                           const cuDoubleComplex *B, int ldb,
                           const cuDoubleComplex *beta,
                           cuDoubleComplex *C, int ldc)
cublasStatus_t cublasHgemm(cublasHandle_t handle,
                           cublasOperation_t transa, cublasOperation_t transb,
                           int m, int n, int k,
                           const __half *alpha,
                           const __half *A, int lda,
                           const __half *B, int ldb,
                           const __half *beta,
                           __half *C, int ldc)

This function supports the 64-bit Integer Interface.

This function performs the matrix-matrix multiplication

\(C = \alpha\text{op}(A)\text{op}(B) + \beta C\)

where \(\alpha\) and \(\beta\) are scalars, and \(A\) , \(B\) and \(C\) are matrices stored in column-major format with dimensions \(\text{op}(A)\) \(m \times k\) , \(\text{op}(B)\) \(k \times n\) and \(C\) \(m \times n\) , respectively. Also, for matrix \(A\)

\(\text{op}(A) = \left\{ \begin{matrix} A & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_N}$}} \\ A^{T} & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_T}$}} \\ A^{H} & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_C}$}} \\ \end{matrix} \right.\)

and \(\text{op}(B)\) is defined similarly for matrix \(B\) .

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

transa

input

operation op(A) that is non- or (conj.) transpose.

transb

input

operation op(B) that is non- or (conj.) transpose.

m

input

number of rows of matrix op(A) and C.

n

input

number of columns of matrix op(B) and C.

k

input

number of columns of op(A) and rows of op(B).

alpha

host or device

input

<type> scalar used for multiplication.

A

device

input

<type> array of dimensions lda x k with lda>=max(1,m) if transa == CUBLAS_OP_N and lda x m with lda>=max(1,k) otherwise.

lda

input

leading dimension of two-dimensional array used to store the matrix A.

B

device

input

<type> array of dimension ldb x n with ldb>=max(1,k) if transb == CUBLAS_OP_N and ldb x k with ldb>=max(1,n) otherwise.

ldb

input

leading dimension of two-dimensional array used to store matrix B.

beta

host or device

input

<type> scalar used for multiplication. If beta==0, C does not have to be a valid input.

C

device

in/out

<type> array of dimensions ldc x n with ldc>=max(1,m).

ldc

input

leading dimension of a two-dimensional array used to store the matrix C.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If m, n, k < 0 or

  • if transa, transb != CUBLAS_OP_N, CUBLAS_OP_C, CUBLAS_OP_T or

  • if lda < max(1, m) if transa == CUBLAS_OP_N and lda < max(1, k) otherwise or

  • if ldb < max(1, k) if transb == CUBLAS_OP_N and ldb < max(1, n) otherwise or

  • if ldc < max(1, m) or

  • if alpha, beta == NULL or

  • C == NULL if C needs to be scaled

CUBLAS_STATUS_ARCH_MISMATCH

in the case of cublasHgemm() the device does not support math in half precision.

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

sgemm, dgemm, cgemm, zgemm

2.7.2. cublas<t>gemm3m()

cublasStatus_t cublasCgemm3m(cublasHandle_t handle,
                           cublasOperation_t transa, cublasOperation_t transb,
                           int m, int n, int k,
                           const cuComplex       *alpha,
                           const cuComplex       *A, int lda,
                           const cuComplex       *B, int ldb,
                           const cuComplex       *beta,
                           cuComplex       *C, int ldc)
cublasStatus_t cublasZgemm3m(cublasHandle_t handle,
                           cublasOperation_t transa, cublasOperation_t transb,
                           int m, int n, int k,
                           const cuDoubleComplex *alpha,
                           const cuDoubleComplex *A, int lda,
                           const cuDoubleComplex *B, int ldb,
                           const cuDoubleComplex *beta,
                           cuDoubleComplex *C, int ldc)

This function supports the 64-bit Integer Interface.

This function performs the complex matrix-matrix multiplication, using Gauss complexity reduction algorithm. This can lead to an increase in performance up to 25%

\(C = \alpha\text{op}(A)\text{op}(B) + \beta C\)

where \(\alpha\) and \(\beta\) are scalars, and \(A\) , \(B\) and \(C\) are matrices stored in column-major format with dimensions \(\text{op}(A)\) \(m \times k\) , \(\text{op}(B)\) \(k \times n\) and \(C\) \(m \times n\) , respectively. Also, for matrix \(A\)

\(\text{op}(A) = \left\{ \begin{matrix} A & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_N}$}} \\ A^{T} & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_T}$}} \\ A^{H} & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_C}$}} \\ \end{matrix} \right.\)

and \(\text{op}(B)\) is defined similarly for matrix \(B\) .

Note

These 2 routines are only supported on GPUs with architecture capabilities equal to or greater than 5.0

Param.

Memory

In/out

Meaning

handle

input

Handle to the cuBLAS library context.

transa

input

Operation op(A) that is non- or (conj.) transpose.

transb

input

Operation op(B) that is non- or (conj.) transpose.

m

input

Number of rows of matrix op(A) and C.

n

input

Number of columns of matrix op(B) and C.

k

input

Number of columns of op(A) and rows of op(B).

alpha

host or device

input

<type> scalar used for multiplication.

A

device

input

<type> array of dimensions lda x k with lda>=max(1,m) if transa == CUBLAS_OP_N and lda x m with lda>=max(1,k) otherwise.

lda

input

Leading dimension of two-dimensional array used to store the matrix A.

B

device

input

<type> array of dimension ldb x n with ldb>=max(1,k) if transb == CUBLAS_OP_N and ldb x k with ldb>=max(1,n) otherwise.

ldb

input

Leading dimension of two-dimensional array used to store matrix B.

beta

host or device

input

<type> scalar used for multiplication. If beta==0, C does not have to be a valid input.

C

device

in/out

<type> array of dimensions ldc x n with ldc>=max(1,m).

ldc

input

Leading dimension of a two-dimensional array used to store the matrix C.

The possible error values returned by this function and their meanings are listed in the following table:

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

The operation completed successfully.

CUBLAS_STATUS_NOT_INITIALIZED

The library was not initialized.

CUBLAS_STATUS_INVALID_VALUE

  • If m, n, k < 0 or

  • if transa, transb != CUBLAS_OP_N, CUBLAS_OP_C, CUBLAS_OP_T or

  • if lda < max(1, m) if transa == CUBLAS_OP_N and lda < max(1, k) otherwise or

  • if ldb < max(1, k) if transb == CUBLAS_OP_N and ldb < max(1, n) otherwise or

  • if ldc < max(1, m) or

  • if alpha, beta == NULL or

  • C == NULL if C needs to be scaled

CUBLAS_STATUS_ARCH_MISMATCH

The device has a compute capabilites lower than 5.0.

CUBLAS_STATUS_EXECUTION_FAILED

The function failed to launch on the GPU.

For references please refer to:

cgemm, zgemm

2.7.3. cublas<t>gemmBatched()

cublasStatus_t cublasHgemmBatched(cublasHandle_t handle,
                                  cublasOperation_t transa,
                                  cublasOperation_t transb,
                                  int m, int n, int k,
                                  const __half          *alpha,
                                  const __half          *const Aarray[], int lda,
                                  const __half          *const Barray[], int ldb,
                                  const __half          *beta,
                                  __half          *const Carray[], int ldc,
                                  int batchCount)
cublasStatus_t cublasSgemmBatched(cublasHandle_t handle,
                                  cublasOperation_t transa,
                                  cublasOperation_t transb,
                                  int m, int n, int k,
                                  const float           *alpha,
                                  const float           *const Aarray[], int lda,
                                  const float           *const Barray[], int ldb,
                                  const float           *beta,
                                  float           *const Carray[], int ldc,
                                  int batchCount)
cublasStatus_t cublasDgemmBatched(cublasHandle_t handle,
                                  cublasOperation_t transa,
                                  cublasOperation_t transb,
                                  int m, int n, int k,
                                  const double          *alpha,
                                  const double          *const Aarray[], int lda,
                                  const double          *const Barray[], int ldb,
                                  const double          *beta,
                                  double          *const Carray[], int ldc,
                                  int batchCount)
cublasStatus_t cublasCgemmBatched(cublasHandle_t handle,
                                  cublasOperation_t transa,
                                  cublasOperation_t transb,
                                  int m, int n, int k,
                                  const cuComplex       *alpha,
                                  const cuComplex       *const Aarray[], int lda,
                                  const cuComplex       *const Barray[], int ldb,
                                  const cuComplex       *beta,
                                  cuComplex       *const Carray[], int ldc,
                                  int batchCount)
cublasStatus_t cublasZgemmBatched(cublasHandle_t handle,
                                  cublasOperation_t transa,
                                  cublasOperation_t transb,
                                  int m, int n, int k,
                                  const cuDoubleComplex *alpha,
                                  const cuDoubleComplex *const Aarray[], int lda,
                                  const cuDoubleComplex *const Barray[], int ldb,
                                  const cuDoubleComplex *beta,
                                  cuDoubleComplex *const Carray[], int ldc,
                                  int batchCount)

This function supports the 64-bit Integer Interface.

This function performs the matrix-matrix multiplication of a batch of matrices. The batch is considered to be “uniform”, i.e. all instances have the same dimensions (m, n, k), leading dimensions (lda, ldb, ldc) and transpositions (transa, transb) for their respective A, B and C matrices. The address of the input matrices and the output matrix of each instance of the batch are read from arrays of pointers passed to the function by the caller.

\(C\lbrack i\rbrack = \alpha\text{op}(A\lbrack i\rbrack)\text{op}(B\lbrack i\rbrack) + \beta C\lbrack i\rbrack,\text{ for i } \in \lbrack 0,batchCount - 1\rbrack\)

where \(\alpha\) and \(\beta\) are scalars, and \(A\) , \(B\) and \(C\) are arrays of pointers to matrices stored in column-major format with dimensions \(\text{op}(A\lbrack i\rbrack)\) \(m \times k\) , \(\text{op}(B\lbrack i\rbrack)\) \(k \times n\) and \(C\lbrack i\rbrack\) \(m \times n\) , respectively. Also, for matrix \(A\)

\(\text{op}(A) = \left\{ \begin{matrix} A & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_N}$}} \\ A^{T} & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_T}$}} \\ A^{H} & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_C}$}} \\ \end{matrix} \right.\)

and \(\text{op}(B\lbrack i\rbrack)\) is defined similarly for matrix \(B\lbrack i\rbrack\) .

Note

\(C\lbrack i\rbrack\) matrices must not overlap, that is, the individual gemm operations must be computable independently; otherwise, undefined behavior is expected.

On certain problem sizes, it might be advantageous to make multiple calls to cublas<t>gemm in different CUDA streams, rather than use this API.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

transa

input

operation op(A[i]) that is non- or (conj.) transpose.

transb

input

operation op(B[i]) that is non- or (conj.) transpose.

m

input

number of rows of matrix op(A[i]) and C[i].

n

input

number of columns of op(B[i]) and C[i].

k

input

number of columns of op(A[i]) and rows of op(B[i]).

alpha

host or device

input

<type> scalar used for multiplication.

Aarray

device

input

array of pointers to <type> array, with each array of dim. lda x k with lda>=max(1,m) if transa==CUBLAS_OP_N and lda x m with lda>=max(1,k) otherwise.

All pointers must meet certain alignment criteria. Please see below for details.

lda

input

leading dimension of two-dimensional array used to store each matrix A[i].

Barray

device

input

array of pointers to <type> array, with each array of dim. ldb x n with ldb>=max(1,k) if transb==CUBLAS_OP_N and ldb x k with ldb>=max(1,n) max(1,) otherwise.

All pointers must meet certain alignment criteria. Please see below for details.

ldb

input

leading dimension of two-dimensional array used to store each matrix B[i].

beta

host or device

input

<type> scalar used for multiplication. If beta == 0, C does not have to be a valid input.

Carray

device

in/out

array of pointers to <type> array. It has dimensions ldc x n with ldc>=max(1,m). Matrices C[i] should not overlap; otherwise, undefined behavior is expected.

All pointers must meet certain alignment criteria. Please see below for details.

ldc

input

leading dimension of two-dimensional array used to store each matrix C[i].

batchCount

input

number of pointers contained in Aarray, Barray and Carray.

If math mode enables fast math modes when using cublasSgemmBatched(), pointers (not the pointer arrays) placed in the GPU memory must be properly aligned to avoid misaligned memory access errors. Ideally all pointers are aligned to at least 16 Bytes. Otherwise it is recommended that they meet the following rule:

  • if k%4==0 then ensure intptr_t(ptr) % 16 == 0,

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If m, n, k, batchCount < 0 or

  • if transa, transb != CUBLAS_OP_N, CUBLAS_OP_C, CUBLAS_OP_T or

  • if lda < max(1, m) if transa == CUBLAS_OP_N and lda < max(1, k) otherwise or

  • if ldb < max(1, k) if transb == CUBLAS_OP_N and ldb < max(1, n) otherwise or

  • if ldc < max(1, m)

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

CUBLAS_STATUS_ARCH_MISMATCH

cublasHgemmBatched() is only supported for GPU with architecture capabilities equal or greater than 5.3

2.7.4. cublas<t>gemmStridedBatched()

cublasStatus_t cublasHgemmStridedBatched(cublasHandle_t handle,
                                  cublasOperation_t transa,
                                  cublasOperation_t transb,
                                  int m, int n, int k,
                                  const __half           *alpha,
                                  const __half           *A, int lda,
                                  long long int          strideA,
                                  const __half           *B, int ldb,
                                  long long int          strideB,
                                  const __half           *beta,
                                  __half                 *C, int ldc,
                                  long long int          strideC,
                                  int batchCount)
cublasStatus_t cublasSgemmStridedBatched(cublasHandle_t handle,
                                  cublasOperation_t transa,
                                  cublasOperation_t transb,
                                  int m, int n, int k,
                                  const float           *alpha,
                                  const float           *A, int lda,
                                  long long int          strideA,
                                  const float           *B, int ldb,
                                  long long int          strideB,
                                  const float           *beta,
                                  float                 *C, int ldc,
                                  long long int          strideC,
                                  int batchCount)
cublasStatus_t cublasDgemmStridedBatched(cublasHandle_t handle,
                                  cublasOperation_t transa,
                                  cublasOperation_t transb,
                                  int m, int n, int k,
                                  const double          *alpha,
                                  const double          *A, int lda,
                                  long long int          strideA,
                                  const double          *B, int ldb,
                                  long long int          strideB,
                                  const double          *beta,
                                  double                *C, int ldc,
                                  long long int          strideC,
                                  int batchCount)
cublasStatus_t cublasCgemmStridedBatched(cublasHandle_t handle,
                                  cublasOperation_t transa,
                                  cublasOperation_t transb,
                                  int m, int n, int k,
                                  const cuComplex       *alpha,
                                  const cuComplex       *A, int lda,
                                  long long int          strideA,
                                  const cuComplex       *B, int ldb,
                                  long long int          strideB,
                                  const cuComplex       *beta,
                                  cuComplex             *C, int ldc,
                                  long long int          strideC,
                                  int batchCount)
cublasStatus_t cublasCgemm3mStridedBatched(cublasHandle_t handle,
                                  cublasOperation_t transa,
                                  cublasOperation_t transb,
                                  int m, int n, int k,
                                  const cuComplex       *alpha,
                                  const cuComplex       *A, int lda,
                                  long long int          strideA,
                                  const cuComplex       *B, int ldb,
                                  long long int          strideB,
                                  const cuComplex       *beta,
                                  cuComplex             *C, int ldc,
                                  long long int          strideC,
                                  int batchCount)
cublasStatus_t cublasZgemmStridedBatched(cublasHandle_t handle,
                                  cublasOperation_t transa,
                                  cublasOperation_t transb,
                                  int m, int n, int k,
                                  const cuDoubleComplex *alpha,
                                  const cuDoubleComplex *A, int lda,
                                  long long int          strideA,
                                  const cuDoubleComplex *B, int ldb,
                                  long long int          strideB,
                                  const cuDoubleComplex *beta,
                                  cuDoubleComplex       *C, int ldc,
                                  long long int          strideC,
                                  int batchCount)

This function supports the 64-bit Integer Interface.

This function performs the matrix-matrix multiplication of a batch of matrices. The batch is considered to be “uniform”, i.e. all instances have the same dimensions (m, n, k), leading dimensions (lda, ldb, ldc) and transpositions (transa, transb) for their respective A, B and C matrices. Input matrices A, B and output matrix C for each instance of the batch are located at fixed offsets in number of elements from their locations in the previous instance. Pointers to A, B and C matrices for the first instance are passed to the function by the user along with offsets in number of elements - strideA, strideB and strideC that determine the locations of input and output matrices in future instances.

\(C + i*{strideC} = \alpha\text{op}(A + i*{strideA})\text{op}(B + i*{strideB}) + \beta(C + i*{strideC}),\text{ for i } \in \lbrack 0,batchCount - 1\rbrack\)

where \(\alpha\) and \(\beta\) are scalars, and \(A\) , \(B\) and \(C\) are arrays of pointers to matrices stored in column-major format with dimensions \(\text{op}(A\lbrack i\rbrack)\) \(m \times k\) , \(\text{op}(B\lbrack i\rbrack)\) \(k \times n\) and \(C\lbrack i\rbrack\) \(m \times n\) , respectively. Also, for matrix \(A\)

\(\text{op}(A) = \left\{ \begin{matrix} A & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_N}$}} \\ A^{T} & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_T}$}} \\ A^{H} & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_C}$}} \\ \end{matrix} \right.\)

and \(\text{op}(B\lbrack i\rbrack)\) is defined similarly for matrix \(B\lbrack i\rbrack\) .

Note

\(C\lbrack i\rbrack\) matrices must not overlap, i.e. the individual gemm operations must be computable independently; otherwise, undefined behavior is expected.

On certain problem sizes, it might be advantageous to make multiple calls to cublas<t>gemm in different CUDA streams, rather than use this API.

Note

In the table below, we use A[i], B[i], C[i] as notation for A, B and C matrices in the ith instance of the batch, implicitly assuming they are respectively offsets in number of elements strideA, strideB, strideC away from A[i-1], B[i-1], C[i-1]. The unit for the offset is number of elements and must not be zero .

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

transa

input

operation op(A[i]) that is non- or (conj.) transpose.

transb

input

operation op(B[i]) that is non- or (conj.) transpose.

m

input

number of rows of matrix op(A[i]) and C[i].

n

input

number of columns of op(B[i]) and C[i].

k

input

number of columns of op(A[i]) and rows of op(B[i]).

alpha

host or device

input

<type> scalar used for multiplication.

A

device

input

<type>* pointer to the A matrix corresponding to the first instance of the batch, with dimensions lda x k with lda>=max(1,m) if transa==CUBLAS_OP_N and lda x m with lda>=max(1,k) otherwise.

lda

input

leading dimension of two-dimensional array used to store each matrix A[i].

strideA

input

Value of type long long int that gives the offset in number of elements between A[i] and A[i+1]

B

device

input

<type>* pointer to the B matrix corresponding to the first instance of the batch, with dimensions ldb x n with ldb>=max(1,k) if transb==CUBLAS_OP_N and ldb x k with ldb>=max(1,n) max(1,) otherwise.

ldb

input

leading dimension of two-dimensional array used to store each matrix B[i].

strideB

input

Value of type long long int that gives the offset in number of elements between B[i] and B[i+1]

beta

host or device

input

<type> scalar used for multiplication. If beta == 0, C does not have to be a valid input.

C

device

in/out

<type>* pointer to the C matrix corresponding to the first instance of the batch, with dimensions ldc x n with ldc>=max(1,m). Matrices C[i] should not overlap; otherwise, undefined behavior is expected.

ldc

input

leading dimension of two-dimensional array used to store each matrix C[i].

strideC

input

Value of type long long int that gives the offset in number of elements between C[i] and C[i+1]

batchCount

input

number of GEMMs to perform in the batch.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If m, n, k, batchCount < 0 or

  • if transa, transb != CUBLAS_OP_N, CUBLAS_OP_C, CUBLAS_OP_T or

  • if lda < max(1, m) if transa == CUBLAS_OP_N and lda < max(1, k) otherwise or

  • if ldb < max(1, k) if transb == CUBLAS_OP_N and ldb < max(1, n) otherwise or

  • if ldc < max(1, m)

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

CUBLAS_STATUS_ARCH_MISMATCH

cublasHgemmStridedBatched() is only supported for GPU with architecture capabilities equal or greater than 5.3

2.7.5. cublas<t>gemmGroupedBatched()

cublasStatus_t cublasSgemmGroupedBatched(cublasHandle_t handle,
                                         const cublasOperation_t transa_array[],
                                         const cublasOperation_t transb_array[],
                                         const int m_array[],
                                         const int n_array[],
                                         const int k_array[],
                                         const float  alpha_array[],
                                         const float *const  Aarray[],
                                         const int lda_array[],
                                         const float *const  Barray[],
                                         const int ldb_array[],
                                         const float  beta_array[],
                                         float *const  Carray[],
                                         const int ldc_array[],
                                         int group_count,
                                         const int group_size[])
cublasStatus_t cublasDgemmGroupedBatched(cublasHandle_t handle,
                                         const cublasOperation_t transa_array[],
                                         const cublasOperation_t transb_array[],
                                         const int m_array[],
                                         const int n_array[],
                                         const int k_array[],
                                         const double alpha_array[],
                                         const double *const Aarray[],
                                         const int lda_array[],
                                         const double *const Barray[],
                                         const int ldb_array[],
                                         const double beta_array[],
                                         double *const Carray[],
                                         const int ldc_array[],
                                         int group_count,
                                         const int group_size[])

This function supports the 64-bit Integer Interface.

This function performs the matrix-matrix multiplication on groups of matrices. A given group is considered to be “uniform”, i.e. all instances have the same dimensions (m, n, k), leading dimensions (lda, ldb, ldc) and transpositions (transa, transb) for their respective A, B and C matrices. However, the dimensions, leading dimensions, transpositions, and scaling factors (alpha, beta) may vary between groups. The address of the input matrices and the output matrix of each instance of the batch are read from arrays of pointers passed to the function by the caller. This is functionally equivalent to the following:

idx = 0;
for i = 0:group_count - 1
    for j = 0:group_size[i] - 1
        gemm(transa_array[i], transb_array[i], m_array[i], n_array[i], k_array[i],
             alpha_array[i], Aarray[idx], lda_array[i], Barray[idx], ldb_array[i],
             beta_array[i], Carray[idx], ldc_array[i]);
        idx += 1;
    end
end

where \(\text{$\mathrm{alpha\_array}$}\) and \(\text{$\mathrm{beta\_array}$}\) are arrays of scaling factors, and \(\text{Aarray}\), \(\text{Barray}\) and \(\text{Carray}\) are arrays of pointers to matrices stored in column-major format. For a given index, \(\text{idx}\), that is part of group \(i\), the dimensions are:

  • \(\text{op}(\text{Aarray}\lbrack\text{idx}\rbrack)\): \(\text{$\mathrm{m\_array}$}\lbrack i\rbrack \times \text{$\mathrm{k\_array}$}\lbrack i\rbrack\)

  • \(\text{op}(\text{Barray}\lbrack\text{idx}\rbrack)\): \(\text{$\mathrm{k\_array}$}\lbrack i\rbrack \times \text{$\mathrm{n\_array}$}\lbrack i\rbrack\)

  • \(\text{Carray}\lbrack\text{idx}\rbrack\): \(\text{$\mathrm{m\_array}$}\lbrack i\rbrack \times \text{$\mathrm{n\_array}$}\lbrack i\rbrack\)

Note

This API takes arrays of two different lengths. The arrays of dimensions, leading dimensions, transpositions, and scaling factors are of length group_count and the arrays of matrices are of length problem_count where \(\text{$\mathrm{problem\_count}$} = \sum_{i = 0}^{\text{$\mathrm{group\_count}$} - 1} \text{$\mathrm{group\_size}$}\lbrack i\rbrack\)

For matrix \(A[\text{idx}]\) in group \(i\)

\(\text{op}(A[\text{idx}]) = \left\{ \begin{matrix} A[\text{idx}] & {\text{if }\textsf{$\mathrm{transa\_array}\lbrack i\rbrack$ == $\mathrm{CUBLAS\_OP\_N}$}} \\ A[\text{idx}]^{T} & {\text{if }\textsf{$\mathrm{transa\_array}\lbrack i\rbrack$ == $\mathrm{CUBLAS\_OP\_T}$}} \\ A[\text{idx}]^{H} & {\text{if }\textsf{$\mathrm{transa\_array}\lbrack i\rbrack$ == $\mathrm{CUBLAS\_OP\_C}$}} \\ \end{matrix} \right.\)

and \(\text{op}(B[\text{idx}])\) is defined similarly for matrix \(B[\text{idx}]\) in group \(i\).

Note

\(C\lbrack\text{idx}\rbrack\) matrices must not overlap, that is, the individual gemm operations must be computable independently; otherwise, undefined behavior is expected.

On certain problem sizes, it might be advantageous to make multiple calls to cublas<t>gemmBatched in different CUDA streams, rather than use this API.

Param.

Memory

In/out

Meaning

Array Length

handle

input

handle to the cuBLAS library context.

transa_array

host

input

array containing the operations, op(A[idx]), that is non- or (conj.) transpose for each group.

group_count

transb_array

host

input

array containing the operations, op(B[idx]), that is non- or (conj.) transpose for each group.

group_count

m_array

host

input

array containing the number of rows of matrix op(A[idx]) and C[idx] for each group.

group_count

n_array

host

input

array containing the number of columns of op(B[idx]) and C[idx] for each group.

group_count

k_array

host

input

array containing the number of columns of op(A[idx]) and rows of op(B[idx]) for each group.

group_count

alpha_array

host

input

array containing the <type> scalar used for multiplication for each group.

group_count

Aarray

device

input

array of pointers to <type> array, with each array of dim. lda[i] x k[i] with lda[i]>=max(1,m[i]) if transa[i]==CUBLAS_OP_N and lda[i] x m[i] with lda[i]>=max(1,k[i]) otherwise.

All pointers must meet certain alignment criteria. Please see below for details.

problem_count

lda_array

host

input

array containing the leading dimensions of two-dimensional arrays used to store each matrix A[idx] for each group.

group_count

Barray

device

input

array of pointers to <type> array, with each array of dim. ldb[i] x n[i] with ldb[i]>=max(1,k[i]) if transb[i]==CUBLAS_OP_N and ldb[i] x k[i] with ldb[i]>=max(1,n[i]) otherwise.

All pointers must meet certain alignment criteria. Please see below for details.

problem_count

ldb_array

host

input

array containing the leading dimensions of two-dimensional arrays used to store each matrix B[idx] for each group.

group_count

beta_array

host

input

array containing the <type> scalar used for multiplication for each group.

group_count

Carray

device

in/out

array of pointers to <type> array. It has dimensions ldc[i] x n[i] with ldc[i]>=max(1,m[i]). Matrices C[idx] should not overlap; otherwise, undefined behavior is expected.

All pointers must meet certain alignment criteria. Please see below for details.

problem_count

ldc_array

host

input

array containing the leading dimensions of two-dimensional arrays used to store each matrix C[idx] for each group.

group_count

group_count

host

input

number of groups

group_size

host

input

array containg the number of pointers contained in Aarray, Barray and Carray for each group.

group_count

If math mode enables fast math modes when using cublasSgemmGroupedBatched(), pointers (not the pointer arrays) placed in the GPU memory must be properly aligned to avoid misaligned memory access errors. Ideally all pointers are aligned to at least 16 Bytes. Otherwise it is recommended that they meet the following rule:

  • if k%4==0 then ensure intptr_t(ptr) % 16 == 0,

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If transa_array, transb_array, m_array, n_array, k_array, alpha_array, lda_array, ldb_array, beta_array, ldc_array, or group_size are NULL or

  • if group_count < 0 or

  • if m_array[i], n_array[i], k_array[i], group_size[i] < 0 or

  • if transa_array[i], transb_array[i] != CUBLAS_OP_N, CUBLAS_OP_C, CUBLAS_OP_T or

  • if lda_array[i] < max(1, m_array[i]) if transa_array[i] == CUBLAS_OP_N and lda_array[i] < max(1, k_array[i]) otherwise or

  • if ldb_array[i] < max(1, k_array[i]) if transb_array[i] == CUBLAS_OP_N and ldb_array[i] < max(1, n_array[i]) otherwise or

  • if ldc_array[i] < max(1, m_array[i])

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

CUBLAS_STATUS_NOT_SUPPORTED

the pointer mode is set to CUBLAS_POINTER_MODE_DEVICE

2.7.6. cublas<t>symm()

cublasStatus_t cublasSsymm(cublasHandle_t handle,
                           cublasSideMode_t side, cublasFillMode_t uplo,
                           int m, int n,
                           const float           *alpha,
                           const float           *A, int lda,
                           const float           *B, int ldb,
                           const float           *beta,
                           float           *C, int ldc)
cublasStatus_t cublasDsymm(cublasHandle_t handle,
                           cublasSideMode_t side, cublasFillMode_t uplo,
                           int m, int n,
                           const double          *alpha,
                           const double          *A, int lda,
                           const double          *B, int ldb,
                           const double          *beta,
                           double          *C, int ldc)
cublasStatus_t cublasCsymm(cublasHandle_t handle,
                           cublasSideMode_t side, cublasFillMode_t uplo,
                           int m, int n,
                           const cuComplex       *alpha,
                           const cuComplex       *A, int lda,
                           const cuComplex       *B, int ldb,
                           const cuComplex       *beta,
                           cuComplex       *C, int ldc)
cublasStatus_t cublasZsymm(cublasHandle_t handle,
                           cublasSideMode_t side, cublasFillMode_t uplo,
                           int m, int n,
                           const cuDoubleComplex *alpha,
                           const cuDoubleComplex *A, int lda,
                           const cuDoubleComplex *B, int ldb,
                           const cuDoubleComplex *beta,
                           cuDoubleComplex *C, int ldc)

This function supports the 64-bit Integer Interface.

This function performs the symmetric matrix-matrix multiplication

\(C = \left\{ \begin{matrix} {\alpha AB + \beta C} & {\text{if }\textsf{side == $\mathrm{CUBLAS\_SIDE\_LEFT}$}} \\ {\alpha BA + \beta C} & {\text{if }\textsf{side == $\mathrm{CUBLAS\_SIDE\_RIGHT}$}} \\ \end{matrix} \right.\)

where \(A\) is a symmetric matrix stored in lower or upper mode, \(B\) and \(C\) are \(m \times n\) matrices, and \(\alpha\) and \(\beta\) are scalars.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

side

input

indicates if matrix A is on the left or right of B.

uplo

input

indicates if matrix A lower or upper part is stored, the other symmetric part is not referenced and is inferred from the stored elements.

m

input

number of rows of matrix C and B, with matrix A sized accordingly.

n

input

number of columns of matrix C and B, with matrix A sized accordingly.

alpha

host or device

input

<type> scalar used for multiplication.

A

device

input

<type> array of dimension lda x m with lda>=max(1,m) if side == CUBLAS_SIDE_LEFT and lda x n with lda>=max(1,n) otherwise.

lda

input

leading dimension of two-dimensional array used to store matrix A.

B

device

input

<type> array of dimension ldb x n with ldb>=max(1,m).

ldb

input

leading dimension of two-dimensional array used to store matrix B.

beta

host or device

input

<type> scalar used for multiplication, if beta == 0 then C does not have to be a valid input.

C

device

in/out

<type> array of dimension ldc x n with ldc>=max(1,m).

ldc

input

leading dimension of two-dimensional array used to store matrix C.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If m, n < 0 or

  • if side != CUBLAS_SIDE_LEFT, CUBLAS_SIDE_RIGHT or

  • if uplo != CUBLAS_FILL_MODE_LOWER, CUBLAS_FILL_MODE_UPPER or

  • if lda < max(1, m) if side == CUBLAS_SIDE_LEFT and lda < max(1, n) otherwise or

  • if ldb < max(1, m) or

  • if ldc < max(1, m) or

  • if alpha == NULL or beta == NULL or

  • C == NULL if C needs to be scaled

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

ssymm, dsymm, csymm, zsymm

2.7.7. cublas<t>syrk()

cublasStatus_t cublasSsyrk(cublasHandle_t handle,
                           cublasFillMode_t uplo, cublasOperation_t trans,
                           int n, int k,
                           const float           *alpha,
                           const float           *A, int lda,
                           const float           *beta,
                           float           *C, int ldc)
cublasStatus_t cublasDsyrk(cublasHandle_t handle,
                           cublasFillMode_t uplo, cublasOperation_t trans,
                           int n, int k,
                           const double          *alpha,
                           const double          *A, int lda,
                           const double          *beta,
                           double          *C, int ldc)
cublasStatus_t cublasCsyrk(cublasHandle_t handle,
                           cublasFillMode_t uplo, cublasOperation_t trans,
                           int n, int k,
                           const cuComplex       *alpha,
                           const cuComplex       *A, int lda,
                           const cuComplex       *beta,
                           cuComplex       *C, int ldc)
cublasStatus_t cublasZsyrk(cublasHandle_t handle,
                           cublasFillMode_t uplo, cublasOperation_t trans,
                           int n, int k,
                           const cuDoubleComplex *alpha,
                           const cuDoubleComplex *A, int lda,
                           const cuDoubleComplex *beta,
                           cuDoubleComplex *C, int ldc)

This function supports the 64-bit Integer Interface.

This function performs the symmetric rank- \(k\) update

\(C = \alpha\text{op}(A)\text{op}(A)^{T} + \beta C\)

where \(\alpha\) and \(\beta\) are scalars, \(C\) is a symmetric matrix stored in lower or upper mode, and \(A\) is a matrix with dimensions \(\text{op}(A)\) \(n \times k\) . Also, for matrix \(A\)

\(\text{op}(A) = \left\{ \begin{matrix} A & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_N}$}} \\ A^{T} & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_T}$}} \\ \end{matrix} \right.\)

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

uplo

input

indicates if matrix C lower or upper part is stored, the other symmetric part is not referenced and is inferred from the stored elements.

trans

input

operation op(A) that is non- or transpose.

n

input

number of rows of matrix op(A) and C.

k

input

number of columns of matrix op(A).

alpha

host or device

input

<type> scalar used for multiplication.

A

device

input

<type> array of dimension lda x k with lda>=max(1,n) if trans == CUBLAS_OP_N and lda x n with lda>=max(1,k) otherwise.

lda

input

leading dimension of two-dimensional array used to store matrix A.

beta

host or device

input

<type> scalar used for multiplication, if beta==0 then C does not have to be a valid input.

C

device

in/out

<type> array of dimension ldc x n, with ldc>=max(1,n).

ldc

input

leading dimension of two-dimensional array used to store matrix C.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If n, k < 0 or

  • if trans != CUBLAS_OP_N, CUBLAS_OP_C, CUBLAS_OP_T or

  • if uplo != CUBLAS_FILL_MODE_LOWER, CUBLAS_FILL_MODE_UPPER or

  • if lda < max(1, n) if trans == CUBLAS_OP_N and lda < max(1, k) otherwise or

  • if ldc < max(1, n) or

  • if alpha == NULL or beta == NULL or

  • C == NULL if C needs to be scaled

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

ssyrk, dsyrk, csyrk, zsyrk

2.7.8. cublas<t>syr2k()

cublasStatus_t cublasSsyr2k(cublasHandle_t handle,
                            cublasFillMode_t uplo, cublasOperation_t trans,
                            int n, int k,
                            const float           *alpha,
                            const float           *A, int lda,
                            const float           *B, int ldb,
                            const float           *beta,
                            float           *C, int ldc)
cublasStatus_t cublasDsyr2k(cublasHandle_t handle,
                            cublasFillMode_t uplo, cublasOperation_t trans,
                            int n, int k,
                            const double          *alpha,
                            const double          *A, int lda,
                            const double          *B, int ldb,
                            const double          *beta,
                            double          *C, int ldc)
cublasStatus_t cublasCsyr2k(cublasHandle_t handle,
                            cublasFillMode_t uplo, cublasOperation_t trans,
                            int n, int k,
                            const cuComplex       *alpha,
                            const cuComplex       *A, int lda,
                            const cuComplex       *B, int ldb,
                            const cuComplex       *beta,
                            cuComplex       *C, int ldc)
cublasStatus_t cublasZsyr2k(cublasHandle_t handle,
                            cublasFillMode_t uplo, cublasOperation_t trans,
                            int n, int k,
                            const cuDoubleComplex *alpha,
                            const cuDoubleComplex *A, int lda,
                            const cuDoubleComplex *B, int ldb,
                            const cuDoubleComplex *beta,
                            cuDoubleComplex *C, int ldc)

This function supports the 64-bit Integer Interface.

This function performs the symmetric rank- \(2k\) update

\(C = \alpha(\text{op}(A)\text{op}(B)^{T} + \text{op}(B)\text{op}(A)^{T}) + \beta C\)

where \(\alpha\) and \(\beta\) are scalars, \(C\) is a symmetric matrix stored in lower or upper mode, and \(A\) and \(B\) are matrices with dimensions \(\text{op}(A)\) \(n \times k\) and \(\text{op}(B)\) \(n \times k\) , respectively. Also, for matrix \(A\) and \(B\)

\(\text{op(}A\text{) and op(}B\text{)} = \left\{ \begin{matrix} {A\text{ and }B} & {\text{if }\textsf{trans == $\mathrm{CUBLAS\_OP\_N}$}} \\ {A^{T}\text{ and }B^{T}} & {\text{if }\textsf{trans == $\mathrm{CUBLAS\_OP\_T}$}} \\ \end{matrix} \right.\)

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

uplo

input

indicates if matrix C lower or upper part, is stored, the other symmetric part is not referenced and is inferred from the stored elements.

trans

input

operation op(A) that is non- or transpose.

n

input

number of rows of matrix op(A), op(B) and C.

k

input

number of columns of matrix op(A) and op(B).

alpha

host or device

input

<type> scalar used for multiplication.

A

device

input

<type> array of dimension lda x k with lda>=max(1,n) if transa == CUBLAS_OP_N and lda x n with lda>=max(1,k) otherwise.

lda

input

leading dimension of two-dimensional array used to store matrix A.

B

device

input

<type> array of dimensions ldb x k with ldb>=max(1,n) if transb == CUBLAS_OP_N and ldb x n with ldb>=max(1,k) otherwise.

ldb

input

leading dimension of two-dimensional array used to store matrix B.

beta

host or device

input

<type> scalar used for multiplication, if beta==0, then C does not have to be a valid input.

C

device

in/out

<type> array of dimensions ldc x n with ldc>=max(1,n).

ldc

input

leading dimension of two-dimensional array used to store matrix C.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If n, k < 0 or

  • if trans != CUBLAS_OP_N, CUBLAS_OP_C, CUBLAS_OP_T or

  • if uplo != CUBLAS_FILL_MODE_LOWER, CUBLAS_FILL_MODE_UPPER or

  • if lda < max(1, n) if trans == CUBLAS_OP_N and lda < max(1, k) otherwise or

  • if ldb < max(1, n) if trans == CUBLAS_OP_N and lda < max(1, k) otherwise or

  • if ldc < max(1, n) or

  • if alpha == NULL or beta == NULL or

  • C == NULL if C needs to be scaled

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

ssyr2k, dsyr2k, csyr2k, zsyr2k

2.7.9. cublas<t>syrkx()

cublasStatus_t cublasSsyrkx(cublasHandle_t handle,
                            cublasFillMode_t uplo, cublasOperation_t trans,
                            int n, int k,
                            const float           *alpha,
                            const float           *A, int lda,
                            const float           *B, int ldb,
                            const float           *beta,
                            float           *C, int ldc)
cublasStatus_t cublasDsyrkx(cublasHandle_t handle,
                            cublasFillMode_t uplo, cublasOperation_t trans,
                            int n, int k,
                            const double          *alpha,
                            const double          *A, int lda,
                            const double          *B, int ldb,
                            const double          *beta,
                            double          *C, int ldc)
cublasStatus_t cublasCsyrkx(cublasHandle_t handle,
                            cublasFillMode_t uplo, cublasOperation_t trans,
                            int n, int k,
                            const cuComplex       *alpha,
                            const cuComplex       *A, int lda,
                            const cuComplex       *B, int ldb,
                            const cuComplex       *beta,
                            cuComplex       *C, int ldc)
cublasStatus_t cublasZsyrkx(cublasHandle_t handle,
                            cublasFillMode_t uplo, cublasOperation_t trans,
                            int n, int k,
                            const cuDoubleComplex *alpha,
                            const cuDoubleComplex *A, int lda,
                            const cuDoubleComplex *B, int ldb,
                            const cuDoubleComplex *beta,
                            cuDoubleComplex *C, int ldc)

This function supports the 64-bit Integer Interface.

This function performs a variation of the symmetric rank- \(k\) update

\(C = \alpha\text{op}(A)\text{op}(B)^{T} + \beta C\)

where \(\alpha\) and \(\beta\) are scalars, \(C\) is a symmetric matrix stored in lower or upper mode, and \(A\) and \(B\) are matrices with dimensions \(\text{op}(A)\) \(n \times k\) and \(\text{op}(B)\) \(n \times k\) , respectively. Also, for matrices \(A\) and \(B\)

\(\text{op(}A\text{) and op(}B\text{)} = \left\{ \begin{matrix} {A\text{ and }B} & {\text{if }\textsf{trans == $\mathrm{CUBLAS\_OP\_N}$}} \\ {A^{T}\text{ and }B^{T}} & {\text{if }\textsf{trans == $\mathrm{CUBLAS\_OP\_T}$}} \\ \end{matrix} \right.\)

This routine can be used when B is in such way that the result is guaranteed to be symmetric. A usual example is when the matrix B is a scaled form of the matrix A: this is equivalent to B being the product of the matrix A and a diagonal matrix. For an efficient computation of the product of a regular matrix with a diagonal matrix, refer to the routine cublas<t>dgmm.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

uplo

input

indicates if matrix C lower or upper part, is stored, the other symmetric part is not referenced and is inferred from the stored elements.

trans

input

operation op(A) that is non- or transpose.

n

input

number of rows of matrix op(A), op(B) and C.

k

input

number of columns of matrix op(A) and op(B).

alpha

host or device

input

<type> scalar used for multiplication.

A

device

input

<type> array of dimension lda x k with lda>=max(1,n) if transa == CUBLAS_OP_N and lda x n with lda>=max(1,k) otherwise.

lda

input

leading dimension of two-dimensional array used to store matrix A.

B

device

input

<type> array of dimensions ldb x k with ldb>=max(1,n) if transb == CUBLAS_OP_N and ldb x n with ldb>=max(1,k) otherwise.

ldb

input

leading dimension of two-dimensional array used to store matrix B.

beta

host or device

input

<type> scalar used for multiplication, if beta==0, then C does not have to be a valid input.

C

device

in/out

<type> array of dimensions ldc x n with ldc>=max(1,n).

ldc

input

leading dimension of two-dimensional array used to store matrix C.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If n, k < 0 or

  • if trans != CUBLAS_OP_N, CUBLAS_OP_C, CUBLAS_OP_T or

  • if uplo != CUBLAS_FILL_MODE_LOWER, CUBLAS_FILL_MODE_UPPER or

  • if lda < max(1, n) if trans == CUBLAS_OP_N and lda < max(1, k) otherwise or

  • if ldb < max(1, n) if trans == CUBLAS_OP_N and lda < max(1, k) otherwise or

  • if ldc < max(1, n) or

  • if alpha == NULL or beta == NULL or

  • C == NULL if C needs to be scaled

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

ssyrk, dsyrk, csyrk, zsyrk and

ssyr2k, dsyr2k, csyr2k, zsyr2k

2.7.10. cublas<t>trmm()

cublasStatus_t cublasStrmm(cublasHandle_t handle,
                           cublasSideMode_t side, cublasFillMode_t uplo,
                           cublasOperation_t trans, cublasDiagType_t diag,
                           int m, int n,
                           const float           *alpha,
                           const float           *A, int lda,
                           const float           *B, int ldb,
                           float                 *C, int ldc)
cublasStatus_t cublasDtrmm(cublasHandle_t handle,
                           cublasSideMode_t side, cublasFillMode_t uplo,
                           cublasOperation_t trans, cublasDiagType_t diag,
                           int m, int n,
                           const double          *alpha,
                           const double          *A, int lda,
                           const double          *B, int ldb,
                           double                *C, int ldc)
cublasStatus_t cublasCtrmm(cublasHandle_t handle,
                           cublasSideMode_t side, cublasFillMode_t uplo,
                           cublasOperation_t trans, cublasDiagType_t diag,
                           int m, int n,
                           const cuComplex       *alpha,
                           const cuComplex       *A, int lda,
                           const cuComplex       *B, int ldb,
                           cuComplex             *C, int ldc)
cublasStatus_t cublasZtrmm(cublasHandle_t handle,
                           cublasSideMode_t side, cublasFillMode_t uplo,
                           cublasOperation_t trans, cublasDiagType_t diag,
                           int m, int n,
                           const cuDoubleComplex *alpha,
                           const cuDoubleComplex *A, int lda,
                           const cuDoubleComplex *B, int ldb,
                           cuDoubleComplex       *C, int ldc)

This function supports the 64-bit Integer Interface.

This function performs the triangular matrix-matrix multiplication

\(C = \left\{ \begin{matrix} {\alpha\text{op}(A)B} & {\text{if }\textsf{side == $\mathrm{CUBLAS\_SIDE\_LEFT}$}} \\ {\alpha B\text{op}(A)} & {\text{if }\textsf{side == $\mathrm{CUBLAS\_SIDE\_RIGHT}$}} \\ \end{matrix} \right.\)

where \(A\) is a triangular matrix stored in lower or upper mode with or without the main diagonal, \(B\) and \(C\) are \(m \times n\) matrix, and \(\alpha\) is a scalar. Also, for matrix \(A\)

\(\text{op}(A) = \left\{ \begin{matrix} A & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_N}$}} \\ A^{T} & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_T}$}} \\ A^{H} & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_C}$}} \\ \end{matrix} \right.\)

Notice that in order to achieve better parallelism cuBLAS differs from the BLAS API only for this routine. The BLAS API assumes an in-place implementation (with results written back to B), while the cuBLAS API assumes an out-of-place implementation (with results written into C). The application can obtain the in-place functionality of BLAS in the cuBLAS API by passing the address of the matrix B in place of the matrix C. No other overlapping in the input parameters is supported.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

side

input

indicates if matrix A is on the left or right of B.

uplo

input

indicates if matrix A lower or upper part is stored, the other part is not referenced and is inferred from the stored elements.

trans

input

operation op(A) that is non- or (conj.) transpose.

diag

input

indicates if the elements on the main diagonal of matrix A are unity and should not be accessed.

m

input

number of rows of matrix B, with matrix A sized accordingly.

n

input

number of columns of matrix B, with matrix A sized accordingly.

alpha

host or device

input

<type> scalar used for multiplication, if alpha==0 then A is not referenced and B does not have to be a valid input.

A

device

input

<type> array of dimension lda x m with lda>=max(1,m) if side == CUBLAS_SIDE_LEFT and lda x n with lda>=max(1,n) otherwise.

lda

input

leading dimension of two-dimensional array used to store matrix A.

B

device

input

<type> array of dimension ldb x n with ldb>=max(1,m).

ldb

input

leading dimension of two-dimensional array used to store matrix B.

C

device

in/out

<type> array of dimension ldc x n with ldc>=max(1,m).

ldc

input

leading dimension of two-dimensional array used to store matrix C.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If m, n < 0 or

  • if trans != CUBLAS_OP_N, CUBLAS_OP_C, CUBLAS_OP_T or

  • if uplo != CUBLAS_FILL_MODE_LOWER, CUBLAS_FILL_MODE_UPPER or

  • if side != CUBLAS_SIDE_LEFT, CUBLAS_SIDE_RIGHT or

  • if lda < max(1, m) if side == CUBLAS_SIDE_LEFT and lda < max(1, n) otherwise or

  • if ldb < max(1, m) or

  • C == NULL if C needs to be scaled

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

strmm, dtrmm, ctrmm, ztrmm

2.7.11. cublas<t>trsm()

cublasStatus_t cublasStrsm(cublasHandle_t handle,
                           cublasSideMode_t side, cublasFillMode_t uplo,
                           cublasOperation_t trans, cublasDiagType_t diag,
                           int m, int n,
                           const float           *alpha,
                           const float           *A, int lda,
                           float           *B, int ldb)
cublasStatus_t cublasDtrsm(cublasHandle_t handle,
                           cublasSideMode_t side, cublasFillMode_t uplo,
                           cublasOperation_t trans, cublasDiagType_t diag,
                           int m, int n,
                           const double          *alpha,
                           const double          *A, int lda,
                           double          *B, int ldb)
cublasStatus_t cublasCtrsm(cublasHandle_t handle,
                           cublasSideMode_t side, cublasFillMode_t uplo,
                           cublasOperation_t trans, cublasDiagType_t diag,
                           int m, int n,
                           const cuComplex       *alpha,
                           const cuComplex       *A, int lda,
                           cuComplex       *B, int ldb)
cublasStatus_t cublasZtrsm(cublasHandle_t handle,
                           cublasSideMode_t side, cublasFillMode_t uplo,
                           cublasOperation_t trans, cublasDiagType_t diag,
                           int m, int n,
                           const cuDoubleComplex *alpha,
                           const cuDoubleComplex *A, int lda,
                           cuDoubleComplex *B, int ldb)

This function supports the 64-bit Integer Interface.

This function solves the triangular linear system with multiple right-hand-sides

\(\left\{ \begin{matrix} {\text{op}(A)X = \alpha B} & {\text{if }\textsf{side == $\mathrm{CUBLAS\_SIDE\_LEFT}$}} \\ {X\text{op}(A) = \alpha B} & {\text{if }\textsf{side == $\mathrm{CUBLAS\_SIDE\_RIGHT}$}} \\ \end{matrix} \right.\)

where \(A\) is a triangular matrix stored in lower or upper mode with or without the main diagonal, \(X\) and \(B\) are \(m \times n\) matrices, and \(\alpha\) is a scalar. Also, for matrix \(A\)

\(\text{op}(A) = \left\{ \begin{matrix} A & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_N}$}} \\ A^{T} & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_T}$}} \\ A^{H} & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_C}$}} \\ \end{matrix} \right.\)

The solution \(X\) overwrites the right-hand-sides \(B\) on exit.

No test for singularity or near-singularity is included in this function.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

side

input

indicates if matrix A is on the left or right of X.

uplo

input

indicates if matrix A lower or upper part is stored, the other part is not referenced and is inferred from the stored elements.

trans

input

operation op(A) that is non- or (conj.) transpose.

diag

input

indicates if the elements on the main diagonal of matrix A are unity and should not be accessed.

m

input

number of rows of matrix B, with matrix A sized accordingly.

n

input

number of columns of matrix B, with matrix A is sized accordingly.

alpha

host or device

input

<type> scalar used for multiplication, if alpha==0 then A is not referenced and B does not have to be a valid input.

A

device

input

<type> array of dimension lda x m with lda>=max(1,m) if side == CUBLAS_SIDE_LEFT and lda x n with lda>=max(1,n) otherwise.

lda

input

leading dimension of two-dimensional array used to store matrix A.

B

device

in/out

<type> array. It has dimensions ldb x n with ldb>=max(1,m).

ldb

input

leading dimension of two-dimensional array used to store matrix B.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If m < 0 or n < 0 or

  • if trans != CUBLAS_OP_N, CUBLAS_OP_C, CUBLAS_OP_T or

  • if uplo != CUBLAS_FILL_MODE_LOWER, CUBLAS_FILL_MODE_UPPER or

  • if side != CUBLAS_SIDE_LEFT, CUBLAS_SIDE_RIGHT or

  • if diag != CUBLAS_DIAG_NON_UNIT, CUBLAS_DIAG_UNIT or

  • if lda < max(1, m) if side == CUBLAS_SIDE_LEFT and lda < max(1, n) otherwise or

  • if ldb < max(1, m) or

  • alpha == NULL

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

strsm, dtrsm, ctrsm, ztrsm

2.7.12. cublas<t>trsmBatched()

cublasStatus_t cublasStrsmBatched( cublasHandle_t    handle,
                                   cublasSideMode_t  side,
                                   cublasFillMode_t  uplo,
                                   cublasOperation_t trans,
                                   cublasDiagType_t  diag,
                                   int m,
                                   int n,
                                   const float *alpha,
                                   const float *const A[],
                                   int lda,
                                   float *const B[],
                                   int ldb,
                                   int batchCount);
cublasStatus_t cublasDtrsmBatched( cublasHandle_t    handle,
                                   cublasSideMode_t  side,
                                   cublasFillMode_t  uplo,
                                   cublasOperation_t trans,
                                   cublasDiagType_t  diag,
                                   int m,
                                   int n,
                                   const double *alpha,
                                   const double *const A[],
                                   int lda,
                                   double *const B[],
                                   int ldb,
                                   int batchCount);
cublasStatus_t cublasCtrsmBatched( cublasHandle_t    handle,
                                   cublasSideMode_t  side,
                                   cublasFillMode_t  uplo,
                                   cublasOperation_t trans,
                                   cublasDiagType_t  diag,
                                   int m,
                                   int n,
                                   const cuComplex *alpha,
                                   const cuComplex *const A[],
                                   int lda,
                                   cuComplex *const B[],
                                   int ldb,
                                   int batchCount);
cublasStatus_t cublasZtrsmBatched( cublasHandle_t    handle,
                                   cublasSideMode_t  side,
                                   cublasFillMode_t  uplo,
                                   cublasOperation_t trans,
                                   cublasDiagType_t  diag,
                                   int m,
                                   int n,
                                   const cuDoubleComplex *alpha,
                                   const cuDoubleComplex *const A[],
                                   int lda,
                                   cuDoubleComplex *const B[],
                                   int ldb,
                                   int batchCount);

This function supports the 64-bit Integer Interface.

This function solves an array of triangular linear systems with multiple right-hand-sides

\(\left\{ \begin{matrix} {\text{op}(A\lbrack i\rbrack)X\lbrack i\rbrack = \alpha B\lbrack i\rbrack} & {\text{if }\textsf{side == $\mathrm{CUBLAS\_SIDE\_LEFT}$}} \\ {X\lbrack i\rbrack\text{op}(A\lbrack i\rbrack) = \alpha B\lbrack i\rbrack} & {\text{if }\textsf{side == $\mathrm{CUBLAS\_SIDE\_RIGHT}$}} \\ \end{matrix} \right.\)

where \(A\lbrack i\rbrack\) is a triangular matrix stored in lower or upper mode with or without the main diagonal, \(X\lbrack i\rbrack\) and \(B\lbrack i\rbrack\) are \(m \times n\) matrices, and \(\alpha\) is a scalar. Also, for matrix \(A\)

\(\text{op}(A\lbrack i\rbrack) = \left\{ \begin{matrix} {A\lbrack i\rbrack} & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_N}$}} \\ {A^{T}\lbrack i\rbrack} & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_T}$}} \\ {A^{H}\lbrack i\rbrack} & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_C}$}} \\ \end{matrix} \right.\)

The solution \(X\lbrack i\rbrack\) overwrites the right-hand-sides \(B\lbrack i\rbrack\) on exit.

No test for singularity or near-singularity is included in this function.

This function works for any sizes but is intended to be used for matrices of small sizes where the launch overhead is a significant factor. For bigger sizes, it might be advantageous to call batchCount times the regular cublas<t>trsm within a set of CUDA streams.

The current implementation is limited to devices with compute capability above or equal 2.0.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

side

input

indicates if matrix A[i] is on the left or right of X[i].

uplo

input

indicates if matrix A[i] lower or upper part is stored, the other part is not referenced and is inferred from the stored elements.

trans

input

operation op(A[i]) that is non- or (conj.) transpose.

diag

input

indicates if the elements on the main diagonal of matrix A[i] are unity and should not be accessed.

m

input

number of rows of matrix B[i], with matrix A[i] sized accordingly.

n

input

number of columns of matrix B[i], with matrix A[i] is sized accordingly.

alpha

host or device

input

<type> scalar used for multiplication, if alpha==0 then A[i] is not referenced and B[i] does not have to be a valid input.

A

device

input

array of pointers to <type> array, with each array of dim. lda x m with lda>=max(1,m) if side == CUBLAS_SIDE_LEFT and lda x n with lda>=max(1,n) otherwise.

lda

input

leading dimension of two-dimensional array used to store matrix A[i].

B

device

in/out

array of pointers to <type> array, with each array of dim. ldb x n with ldb>=max(1,m). Matrices B[i] should not overlap; otherwise, undefined behavior is expected.

ldb

input

leading dimension of two-dimensional array used to store matrix B[i].

batchCount

input

number of pointers contained in A and B.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If m < 0 or n < 0 or batchCount < 0 or

  • if trans != CUBLAS_OP_N, CUBLAS_OP_C, CUBLAS_OP_T or

  • if uplo != CUBLAS_FILL_MODE_LOWER, CUBLAS_FILL_MODE_UPPER or

  • if side != CUBLAS_SIDE_LEFT, CUBLAS_SIDE_RIGHT or

  • if diag != CUBLAS_DIAG_NON_UNIT, CUBLAS_DIAG_UNIT or

  • if lda < max(1, m) if side == CUBLAS_SIDE_LEFT and lda < max(1, n) otherwise or

  • ldb < max(1, m)

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

strsm, dtrsm, ctrsm, ztrsm

2.7.13. cublas<t>hemm()

cublasStatus_t cublasChemm(cublasHandle_t handle,
                           cublasSideMode_t side, cublasFillMode_t uplo,
                           int m, int n,
                           const cuComplex       *alpha,
                           const cuComplex       *A, int lda,
                           const cuComplex       *B, int ldb,
                           const cuComplex       *beta,
                           cuComplex       *C, int ldc)
cublasStatus_t cublasZhemm(cublasHandle_t handle,
                           cublasSideMode_t side, cublasFillMode_t uplo,
                           int m, int n,
                           const cuDoubleComplex *alpha,
                           const cuDoubleComplex *A, int lda,
                           const cuDoubleComplex *B, int ldb,
                           const cuDoubleComplex *beta,
                           cuDoubleComplex *C, int ldc)

This function supports the 64-bit Integer Interface.

This function performs the Hermitian matrix-matrix multiplication

\(C = \left\{ \begin{matrix} {\alpha AB + \beta C} & {\text{if }\textsf{side == $\mathrm{CUBLAS\_SIDE\_LEFT}$}} \\ {\alpha BA + \beta C} & {\text{if }\textsf{side == $\mathrm{CUBLAS\_SIDE\_RIGHT}$}} \\ \end{matrix} \right.\)

where \(A\) is a Hermitian matrix stored in lower or upper mode, \(B\) and \(C\) are \(m \times n\) matrices, and \(\alpha\) and \(\beta\) are scalars.

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

side

input

indicates if matrix A is on the left or right of B.

uplo

input

indicates if matrix A lower or upper part is stored, the other Hermitian part is not referenced and is inferred from the stored elements.

m

input

number of rows of matrix C and B, with matrix A sized accordingly.

n

input

number of columns of matrix C and B, with matrix A sized accordingly.

alpha

host or device

input

<type> scalar used for multiplication.

A

device

input

<type> array of dimension lda x m with lda>=max(1,m) if side==CUBLAS_SIDE_LEFT and lda x n with lda>=max(1,n) otherwise. The imaginary parts of the diagonal elements are assumed to be zero.

lda

input

leading dimension of two-dimensional array used to store matrix A.

B

device

input

<type> array of dimension ldb x n with ldb>=max(1,m).

ldb

input

leading dimension of two-dimensional array used to store matrix B.

beta

input

<type> scalar used for multiplication, if beta==0 then C does not have to be a valid input.

C

device

in/out

<type> array of dimensions ldc x n with ldc>=max(1,m).

ldc

input

leading dimension of two-dimensional array used to store matrix C.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If m < 0 or n < 0 or

  • if side != CUBLAS_SIDE_LEFT, CUBLAS_SIDE_RIGHT or

  • if uplo != CUBLAS_FILL_MODE_LOWER, CUBLAS_FILL_MODE_UPPER or

  • if lda < max(1, m) if side == CUBLAS_SIDE_LEFT and lda < max(1, n) otherwise or

  • if ldb < max(1, m) or

  • if ldc < max(1, m) or

  • if alpha == NULL or beta == NULL or

  • C == NULL

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

chemm, zhemm

2.7.14. cublas<t>herk()

cublasStatus_t cublasCherk(cublasHandle_t handle,
                           cublasFillMode_t uplo, cublasOperation_t trans,
                           int n, int k,
                           const float  *alpha,
                           const cuComplex       *A, int lda,
                           const float  *beta,
                           cuComplex       *C, int ldc)
cublasStatus_t cublasZherk(cublasHandle_t handle,
                           cublasFillMode_t uplo, cublasOperation_t trans,
                           int n, int k,
                           const double *alpha,
                           const cuDoubleComplex *A, int lda,
                           const double *beta,
                           cuDoubleComplex *C, int ldc)

This function supports the 64-bit Integer Interface.

This function performs the Hermitian rank- \(k\) update

\(C = \alpha\text{op}(A)\text{op}(A)^{H} + \beta C\)

where \(\alpha\) and \(\beta\) are scalars, \(C\) is a Hermitian matrix stored in lower or upper mode, and \(A\) is a matrix with dimensions \(\text{op}(A)\) \(n \times k\) . Also, for matrix \(A\)

\(\text{op}(A) = \left\{ \begin{matrix} A & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_N}$}} \\ A^{H} & {\text{if }\textsf{transa == $\mathrm{CUBLAS\_OP\_C}$}} \\ \end{matrix} \right.\)

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

uplo

input

indicates if matrix C lower or upper part is stored, the other Hermitian part is not referenced.

trans

input

operation op(A) that is non- or (conj.) transpose.

n

input

number of rows of matrix op(A) and C.

k

input

number of columns of matrix op(A).

alpha

host or device

input

<type> scalar used for multiplication.

A

device

input

<type> array of dimension lda x k with lda>=max(1,n) if transa == CUBLAS_OP_N and lda x n with lda>=max(1,k) otherwise.

lda

input

leading dimension of two-dimensional array used to store matrix A.

beta

input

<type> scalar used for multiplication, if beta==0 then C does not have to be a valid input.

C

device

in/out

<type> array of dimension ldc x n, with ldc>=max(1,n). The imaginary parts of the diagonal elements are assumed and set to zero.

ldc

input

leading dimension of two-dimensional array used to store matrix C.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If n < 0 or k < 0 or

  • if trans != CUBLAS_OP_N, CUBLAS_OP_C, CUBLAS_OP_T or

  • if uplo != CUBLAS_FILL_MODE_LOWER, CUBLAS_FILL_MODE_UPPER or

  • if lda < max(1, n) if trans == CUBLAS_OP_N and lda < max(1, k) otherwise or

  • if ldc < max(1, n) or

  • if alpha == NULL or beta == NULL or

  • C == NULL

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

cherk, zherk

2.7.15. cublas<t>her2k()

cublasStatus_t cublasCher2k(cublasHandle_t handle,
                            cublasFillMode_t uplo, cublasOperation_t trans,
                            int n, int k,
                            const cuComplex       *alpha,
                            const cuComplex       *A, int lda,
                            const cuComplex       *B, int ldb,
                            const float  *beta,
                            cuComplex       *C, int ldc)
cublasStatus_t cublasZher2k(cublasHandle_t handle,
                            cublasFillMode_t uplo, cublasOperation_t trans,
                            int n, int k,
                            const cuDoubleComplex *alpha,
                            const cuDoubleComplex *A, int lda,
                            const cuDoubleComplex *B, int ldb,
                            const double *beta,
                            cuDoubleComplex *C, int ldc)

This function supports the 64-bit Integer Interface.

This function performs the Hermitian rank- \(2k\) update

\(C = \alpha\text{op}(A)\text{op}(B)^{H} + \overset{ˉ}{\alpha}\text{op}(B)\text{op}(A)^{H} + \beta C\)

where \(\alpha\) and \(\beta\) are scalars, \(C\) is a Hermitian matrix stored in lower or upper mode, and \(A\) and \(B\) are matrices with dimensions \(\text{op}(A)\) \(n \times k\) and \(\text{op}(B)\) \(n \times k\) , respectively. Also, for matrix \(A\) and \(B\)

\(\text{op(}A\text{) and op(}B\text{)} = \left\{ \begin{matrix} {A\text{ and }B} & {\text{if }\textsf{trans == $\mathrm{CUBLAS\_OP\_N}$}} \\ {A^{H}\text{ and }B^{H}} & {\text{if }\textsf{trans == $\mathrm{CUBLAS\_OP\_C}$}} \\ \end{matrix} \right.\)

Param.

Memory

In/out

Meaning

handle

input

handle to the cuBLAS library context.

uplo

input

indicates if matrix C lower or upper part is stored, the other Hermitian part is not referenced.

trans

input

operation op(A) that is non- or (conj.) transpose.

n

input

number of rows of matrix op(A), op(B) and C.

k

input

number of columns of matrix op(A) and op(B).

alpha

host or device

input

<type> scalar used for multiplication.

A

device

input

<type> array of dimension lda x k with lda>=max(1,n) if transa == CUBLAS_OP_N and lda x n with lda>=max(1,k) otherwise.

lda

input

leading dimension of two-dimensional array used to store matrix A.

B

device

input

<type> array of dimension ldb x k with ldb>=max(1,n) if transb == CUBLAS_OP_N and ldb x n with ldb>=max(1,k) otherwise.

ldb

input

leading dimension of two-dimensional array used to store matrix B.

beta

host or device

input

<type> scalar used for multiplication, if beta==0 then C does not have to be a valid input.

C

device

in/out

<type> array of dimension ldc x n, with ldc>=max(1,n). The imaginary parts of the diagonal elements are assumed and set to zero.

ldc

input

leading dimension of two-dimensional array used to store matrix C.

The possible error values returned by this function and their meanings are listed below.

Error Value

Meaning

CUBLAS_STATUS_SUCCESS

the operation completed successfully

CUBLAS_STATUS_NOT_INITIALIZED

the library was not initialized

CUBLAS_STATUS_INVALID_VALUE

  • If n < 0 or k < 0 or

  • if trans != CUBLAS_OP_N, CUBLAS_OP_C, CUBLAS_OP_T or

  • if uplo != CUBLAS_FILL_MODE_LOWER, CUBLAS_FILL_MODE_UPPER or

  • if lda < max(1, n) if trans == CUBLAS_OP_N and lda < max(1, k) otherwise or

  • if ldb < max(1, n) if trans == CUBLAS_OP_N and lda < max(1, k) otherwise or

  • if ldc < max(1, n) or

  • if alpha == NULL or beta == NULL or

  • C == NULL

CUBLAS_STATUS_EXECUTION_FAILED

the function failed to launch on the GPU

For references please refer to:

cher2k, zher2k

2.7.16. cublas<t>herkx()

cublasStatus_t cublasCherkx(cublasHandle_t handle,
                            cublasFillMode_t uplo, cublasOperation_t trans,
                            int n, int k,
                            const cuComplex       *alpha,
                            const cuComplex       *A, int lda,
                            const cuComplex       *B, int ldb,
                            const float  *beta,
                            cuComplex       *C, int ldc)
cublasStatus_t cublasZherkx(cublasHandle_t handle,
                            cublasFillMode_t uplo, cublasOperation_t trans,
                            int n, int k,
                            const cuDoubleComplex *alpha,
                            const cuDoubleComplex *A, int lda,
                            const cuDoubleComplex *B, int ldb,
                            const double *beta,
                            cuDoubleComplex *C, int ldc)

This function supports the 64-bit Integer Interface.

This function performs a variation of the Hermitian rank- \(k\) update

\(C = \alpha\text{op}(A)\text{op}(B)^{H} + \beta C\)

where \(\alpha\) and \(\beta\) are scalars, \(C\) is a Hermitian matrix stored in lower or upper mode, and \(A\) and \(B\) are matrices with dimensions \(\text{op}(A)\) \(n \times k\) and \(\text{op}(B)\) \(n \times k\) , respectively. Also, for matrix \(A\) and \(B\)

\(\text{op(}A\text{) and op(}B\text{)} = \left\{ \begin{matrix} {A\text{ and }B} & {\text{if }\textsf{trans == $\mathrm{CUBLAS\_OP\_N}$}} \\ {A^{H}\text{ and }B^{H}} & {\text{if }\textsf{trans == $\mathrm{CUBLAS\_OP\_C}$}} \\ \end{matrix} \right.\)

This routine can be used when the matrix B is in such way that the result is guaranteed to be hermitian. An usual example is when the matr
