Detailed Description
Holds extended parameters for a hardware buffer.
Definition at line 488 of file nvbuf_utils.h.
Data Fields | |
| NvBufferParams | params |
| nvbuffer basic parameters. More... | |
| int32_t | startofvaliddata |
| offset in bytes from the start of the buffer to the first valid byte. More... | |
| int32_t | sizeofvaliddatainbytes |
| size of the valid data from the first to the last valid byte. More... | |
| NvBufferDisplayScanFormat | scanformat [MAX_NUM_PLANES] |
| display scan format - progressive/interlaced. More... | |
| uint32_t | secondfieldoffset [MAX_NUM_PLANES] |
| offset of the second field for interlaced buffer. More... | |
| uint32_t | blockheightlog2 [MAX_NUM_PLANES] |
| block height of the planes for blockLinear layout hardware buffer. More... | |
| uint32_t | physicaladdress [MAX_NUM_PLANES] |
| physical address of allocated planes. More... | |
| uint64_t | flags [MAX_NUM_PLANES] |
| flags associated with planes More... | |
| void * | payloadmetaInfo |
| metadata associated with the hardware buffer. More... | |
| NvBufferChromaSubsamplingParams | chromaSubsampling |
| chroma subsampling parameters More... | |
| bool | is_protected |
| get buffer vpr information. More... | |
| NvBufferSyncObj | syncobj |
| buffer sync point object parameters More... | |
| NvBufferCDEParams * | cde_params |
| CDE parameters. More... | |
Field Documentation
◆ blockheightlog2
| uint32_t _NvBufferParamsEx::blockheightlog2[MAX_NUM_PLANES] |
block height of the planes for blockLinear layout hardware buffer.
Definition at line 503 of file nvbuf_utils.h.
◆ cde_params
| NvBufferCDEParams* _NvBufferParamsEx::cde_params |
CDE parameters.
Definition at line 517 of file nvbuf_utils.h.
◆ chromaSubsampling
| NvBufferChromaSubsamplingParams _NvBufferParamsEx::chromaSubsampling |
chroma subsampling parameters
Definition at line 511 of file nvbuf_utils.h.
◆ flags
| uint64_t _NvBufferParamsEx::flags[MAX_NUM_PLANES] |
flags associated with planes
Definition at line 507 of file nvbuf_utils.h.
◆ is_protected
| bool _NvBufferParamsEx::is_protected |
get buffer vpr information.
Definition at line 513 of file nvbuf_utils.h.
◆ params
| NvBufferParams _NvBufferParamsEx::params |
nvbuffer basic parameters.
Definition at line 491 of file nvbuf_utils.h.
◆ payloadmetaInfo
| void* _NvBufferParamsEx::payloadmetaInfo |
metadata associated with the hardware buffer.
Definition at line 509 of file nvbuf_utils.h.
◆ physicaladdress
| uint32_t _NvBufferParamsEx::physicaladdress[MAX_NUM_PLANES] |
physical address of allocated planes.
Definition at line 505 of file nvbuf_utils.h.
◆ scanformat
| NvBufferDisplayScanFormat _NvBufferParamsEx::scanformat[MAX_NUM_PLANES] |
display scan format - progressive/interlaced.
Definition at line 499 of file nvbuf_utils.h.
◆ secondfieldoffset
| uint32_t _NvBufferParamsEx::secondfieldoffset[MAX_NUM_PLANES] |
offset of the second field for interlaced buffer.
Definition at line 501 of file nvbuf_utils.h.
◆ sizeofvaliddatainbytes
| int32_t _NvBufferParamsEx::sizeofvaliddatainbytes |
size of the valid data from the first to the last valid byte.
(Applicale for NvBufferPayload_MemHandle)
Definition at line 497 of file nvbuf_utils.h.
◆ startofvaliddata
| int32_t _NvBufferParamsEx::startofvaliddata |
offset in bytes from the start of the buffer to the first valid byte.
(Applicale for NvBufferPayload_MemHandle)
Definition at line 494 of file nvbuf_utils.h.
◆ syncobj
| NvBufferSyncObj _NvBufferParamsEx::syncobj |
buffer sync point object parameters
Definition at line 515 of file nvbuf_utils.h.
The documentation for this struct was generated from the following file:
- utils/nvbuf_utils/nvbuf_utils.h
