Detailed Description

template<typename T>
class Argus::Rectangle< T >

Rectangle template class.

This is a Tuple specialization containing 4 elements corresponding to the positions of the left, top, right, and bottom edges of a rectangle, in that order. Values can be accessed using the named methods.

Definition at line 754 of file Types.h.

Inheritance diagram for Argus::Rectangle< T >:

[legend]

Collaboration diagram for Argus::Rectangle< T >:

[legend]

Public Member Functions
	Rectangle ()

	Rectangle (const Tuple< 4, T > &other)

	Rectangle (T init)

	Rectangle (T _left, T _top, T _right, T _bottom)

T &	left ()

const T &	left () const

T &	top ()

const T &	top () const

T &	right ()

const T &	right () const

T &	bottom ()

const T &	bottom () const

T	width () const
	Returns the width of the rectangle. More...

T	height () const
	Returns the height of the rectangle. More...

T	area () const
	Returns the area of the rectangle (width * height). More...

bool	operator== (const Tuple< N, T > &rhs) const
	Returns true when every element in the two tuples are identical. More...

bool	operator!= (const Tuple< N, T > &rhs) const
	Returns true if there are any differences between the two tuples. More...

Tuple< N, T > &	operator+= (const Tuple< N, T > &rhs)
	Adds every element of another tuple to the elements of this tuple. More...

Tuple< N, T > &	operator-= (const Tuple< N, T > &rhs)
	Subtracts every element of another tuple from the elements of this tuple. More...

Tuple< N, T > &	operator*= (const T &rhs)
	Multiplies every element in the tuple by a single value. More...

Tuple< N, T > &	operator/= (const T &rhs)
	Divides every element in the tuple by a single value. More...

const Tuple< N, T >	operator+ (const Tuple< N, T > &rhs) const
	Returns the result of adding another tuple to this tuple. More...

const Tuple< N, T >	operator- (const Tuple< N, T > &rhs) const
	Returns the result of subtracting another tuple from this tuple. More...

const Tuple< N, T >	operator* (const T &rhs) const
	Returns the result of multiplying this tuple by a single value. More...

const Tuple< N, T >	operator/ (const T &rhs) const
	Returns the result of dividing this tuple by a single value. More...

T &	operator[] (unsigned int i)

const T &	operator[] (unsigned int i) const

Static Public Member Functions
static unsigned int	tupleSize ()
	Returns the number of elements in the tuple. More...

Protected Attributes
T	m_data [N]

Constructor & Destructor Documentation

◆ Rectangle() [1/4]

template<typename T >

Argus::Rectangle< T >::Rectangle ( )

inline

Definition at line 757 of file Types.h.

◆ Rectangle() [2/4]

template<typename T >

Argus::Rectangle< T >::Rectangle ( const Tuple< 4, T > & other )

inline

Definition at line 758 of file Types.h.

◆ Rectangle() [3/4]

template<typename T >

Argus::Rectangle< T >::Rectangle ( T init )

inline

Definition at line 760 of file Types.h.

◆ Rectangle() [4/4]

template<typename T >

Argus::Rectangle< T >::Rectangle	(	T	_left,
		T	_top,
		T	_right,
		T	_bottom
	)

inline

Definition at line 765 of file Types.h.

Member Function Documentation

◆ area()

template<typename T >

T Argus::Rectangle< T >::area ( ) const

inline

Returns the area of the rectangle (width * height).

Definition at line 789 of file Types.h.

◆ bottom() [1/2]

template<typename T >

T& Argus::Rectangle< T >::bottom ( )

inline

Definition at line 779 of file Types.h.

Referenced by Argus::Rectangle< uint32_t >::height(), and Argus::Rectangle< uint32_t >::Rectangle().

◆ bottom() [2/2]

template<typename T >

const T& Argus::Rectangle< T >::bottom ( ) const

inline

Definition at line 780 of file Types.h.

◆ height()

template<typename T >

T Argus::Rectangle< T >::height ( ) const

inline

Returns the height of the rectangle.

Definition at line 786 of file Types.h.

Referenced by Argus::Rectangle< uint32_t >::area().

◆ left() [1/2]

template<typename T >

T& Argus::Rectangle< T >::left ( )

inline

Definition at line 773 of file Types.h.

Referenced by Argus::Rectangle< uint32_t >::Rectangle(), and Argus::Rectangle< uint32_t >::width().

◆ left() [2/2]

template<typename T >

const T& Argus::Rectangle< T >::left ( ) const

inline

Definition at line 774 of file Types.h.

◆ operator!=()

bool Argus::Tuple< N, T >::operator!= ( const Tuple< N, T > & rhs ) const

inlineinherited

Returns true if there are any differences between the two tuples.

Definition at line 517 of file Types.h.

◆ operator*()

const Tuple<N, T> Argus::Tuple< N, T >::operator* ( const T & rhs ) const

inlineinherited

Returns the result of multiplying this tuple by a single value.

Definition at line 567 of file Types.h.

◆ operator*=()

Tuple<N, T>& Argus::Tuple< N, T >::operator*= ( const T & rhs )

inlineinherited

Multiplies every element in the tuple by a single value.

Definition at line 539 of file Types.h.

◆ operator+()

const Tuple<N, T> Argus::Tuple< N, T >::operator+ ( const Tuple< N, T > & rhs ) const

inlineinherited

Returns the result of adding another tuple to this tuple.

Definition at line 555 of file Types.h.

◆ operator+=()

Tuple<N, T>& Argus::Tuple< N, T >::operator+= ( const Tuple< N, T > & rhs )

inlineinherited

Adds every element of another tuple to the elements of this tuple.

Definition at line 523 of file Types.h.

◆ operator-()

const Tuple<N, T> Argus::Tuple< N, T >::operator- ( const Tuple< N, T > & rhs ) const

inlineinherited

Returns the result of subtracting another tuple from this tuple.

Definition at line 561 of file Types.h.

◆ operator-=()

Tuple<N, T>& Argus::Tuple< N, T >::operator-= ( const Tuple< N, T > & rhs )

inlineinherited

Subtracts every element of another tuple from the elements of this tuple.

Definition at line 531 of file Types.h.

◆ operator/()

const Tuple<N, T> Argus::Tuple< N, T >::operator/ ( const T & rhs ) const

inlineinherited

Returns the result of dividing this tuple by a single value.

Definition at line 573 of file Types.h.

◆ operator/=()

Tuple<N, T>& Argus::Tuple< N, T >::operator/= ( const T & rhs )

inlineinherited

Divides every element in the tuple by a single value.

Definition at line 547 of file Types.h.

◆ operator==()

bool Argus::Tuple< N, T >::operator== ( const Tuple< N, T > & rhs ) const

inlineinherited

Returns true when every element in the two tuples are identical.

Definition at line 511 of file Types.h.

◆ operator[]() [1/2]

T& Argus::Tuple< N, T >::operator[] ( unsigned int i )

inlineinherited

Definition at line 578 of file Types.h.

◆ operator[]() [2/2]

const T& Argus::Tuple< N, T >::operator[] ( unsigned int i ) const

inlineinherited

Definition at line 579 of file Types.h.

◆ right() [1/2]

template<typename T >

T& Argus::Rectangle< T >::right ( )

inline

Definition at line 777 of file Types.h.

Referenced by Argus::Rectangle< uint32_t >::Rectangle(), and Argus::Rectangle< uint32_t >::width().

◆ right() [2/2]

template<typename T >

const T& Argus::Rectangle< T >::right ( ) const

inline

Definition at line 778 of file Types.h.

◆ top() [1/2]

template<typename T >

T& Argus::Rectangle< T >::top ( )

inline

Definition at line 775 of file Types.h.

Referenced by Argus::Rectangle< uint32_t >::height(), and Argus::Rectangle< uint32_t >::Rectangle().

◆ top() [2/2]

template<typename T >

const T& Argus::Rectangle< T >::top ( ) const

inline

Definition at line 776 of file Types.h.

◆ tupleSize()

static unsigned int Argus::Tuple< N, T >::tupleSize

inlinestaticinherited

Returns the number of elements in the tuple.

Definition at line 582 of file Types.h.

◆ width()

template<typename T >

T Argus::Rectangle< T >::width ( ) const

inline

Returns the width of the rectangle.

Definition at line 783 of file Types.h.

Referenced by Argus::Rectangle< uint32_t >::area().

Field Documentation

◆ m_data

T Argus::Tuple< N, T >::m_data[N]

protectedinherited

Definition at line 585 of file Types.h.

The documentation for this class was generated from the following file:

Argus/Types.h
