Jetson Linux API Reference
35.6.0 Release
Public Member Functions | Static Public Member Functions | Protected Attributes
Argus::RGBTuple< T > Class Template Reference

Detailed Description

template<typename T>
class Argus::RGBTuple< T >

RGBTuple template class.

This is a Tuple specialization containing 3 elements corresponding to the RGB color channels: R, G, and B. Values can be accessed using the named methods or subscript indexing using the Argus::RGBChannel enum.

Definition at line 636 of file Types.h.

Inheritance diagram for Argus::RGBTuple< T >:
Inheritance graph
[legend]
Collaboration diagram for Argus::RGBTuple< T >:
Collaboration graph
[legend]

Public Member Functions

 RGBTuple ()

 RGBTuple (const Tuple< RGB_CHANNEL_COUNT, T > &other)

 RGBTuple (T init)

 RGBTuple (T _r, T _g, T _b)

T & r ()

const T & r () const

T & g ()

const T & g () const

T & b ()

const T & b () const

bool operator== (const Tuple< N, T > &rhs) const
 Returns true when every element in the two tuples are identical. More...

bool operator!= (const Tuple< N, T > &rhs) const
 Returns true if there are any differences between the two tuples. More...

Tuple< N, T > & operator+= (const Tuple< N, T > &rhs)
 Adds every element of another tuple to the elements of this tuple. More...

Tuple< N, T > & operator-= (const Tuple< N, T > &rhs)
 Subtracts every element of another tuple from the elements of this tuple. More...

Tuple< N, T > & operator*= (const T &rhs)
 Multiplies every element in the tuple by a single value. More...

Tuple< N, T > & operator/= (const T &rhs)
 Divides every element in the tuple by a single value. More...

const Tuple< N, T > operator+ (const Tuple< N, T > &rhs) const
 Returns the result of adding another tuple to this tuple. More...

const Tuple< N, T > operator- (const Tuple< N, T > &rhs) const
 Returns the result of subtracting another tuple from this tuple. More...

const Tuple< N, T > operator* (const T &rhs) const
 Returns the result of multiplying this tuple by a single value. More...

const Tuple< N, T > operator/ (const T &rhs) const
 Returns the result of dividing this tuple by a single value. More...

T & operator[] (unsigned int i)

const T & operator[] (unsigned int i) const


Static Public Member Functions

static unsigned int tupleSize ()
 Returns the number of elements in the tuple. More...


Protected Attributes

T m_data [N]


Constructor & Destructor Documentation

◆ RGBTuple() [1/4]

template<typename T >
Argus::RGBTuple< T >::RGBTuple ( )
inline

Definition at line 639 of file Types.h.

◆ RGBTuple() [2/4]

template<typename T >
Argus::RGBTuple< T >::RGBTuple ( const Tuple< RGB_CHANNEL_COUNT, T > &  other)
inline

Definition at line 640 of file Types.h.

◆ RGBTuple() [3/4]

template<typename T >
Argus::RGBTuple< T >::RGBTuple ( T  init)
inline

Definition at line 642 of file Types.h.

References Argus::RGBTuple< T >::b(), Argus::RGBTuple< T >::g(), and Argus::RGBTuple< T >::r().

◆ RGBTuple() [4/4]

template<typename T >
Argus::RGBTuple< T >::RGBTuple ( T  _r,
T  _g,
T  _b
)
inline

Definition at line 647 of file Types.h.

References Argus::RGBTuple< T >::b(), Argus::RGBTuple< T >::g(), and Argus::RGBTuple< T >::r().

Member Function Documentation

◆ b() [1/2]

template<typename T >
T& Argus::RGBTuple< T >::b ( )
inline

Definition at line 658 of file Types.h.

References Argus::RGB_CHANNEL_B.

Referenced by Argus::RGBTuple< T >::RGBTuple().

◆ b() [2/2]

template<typename T >
const T& Argus::RGBTuple< T >::b ( ) const
inline

Definition at line 659 of file Types.h.

References Argus::RGB_CHANNEL_B.

◆ g() [1/2]

template<typename T >
T& Argus::RGBTuple< T >::g ( )
inline

Definition at line 656 of file Types.h.

References Argus::RGB_CHANNEL_G.

Referenced by Argus::RGBTuple< T >::RGBTuple().

◆ g() [2/2]

template<typename T >
const T& Argus::RGBTuple< T >::g ( ) const
inline

Definition at line 657 of file Types.h.

References Argus::RGB_CHANNEL_G.

◆ operator!=()

bool Argus::Tuple< N, T >::operator!= ( const Tuple< N, T > &  rhs) const
inlineinherited

Returns true if there are any differences between the two tuples.

Definition at line 524 of file Types.h.

◆ operator*()

const Tuple<N, T> Argus::Tuple< N, T >::operator* ( const T &  rhs) const
inlineinherited

Returns the result of multiplying this tuple by a single value.

Definition at line 574 of file Types.h.

◆ operator*=()

Tuple<N, T>& Argus::Tuple< N, T >::operator*= ( const T &  rhs)
inlineinherited

Multiplies every element in the tuple by a single value.

Definition at line 546 of file Types.h.

◆ operator+()

const Tuple<N, T> Argus::Tuple< N, T >::operator+ ( const Tuple< N, T > &  rhs) const
inlineinherited

Returns the result of adding another tuple to this tuple.

Definition at line 562 of file Types.h.

◆ operator+=()

Tuple<N, T>& Argus::Tuple< N, T >::operator+= ( const Tuple< N, T > &  rhs)
inlineinherited

Adds every element of another tuple to the elements of this tuple.

Definition at line 530 of file Types.h.

◆ operator-()

const Tuple<N, T> Argus::Tuple< N, T >::operator- ( const Tuple< N, T > &  rhs) const
inlineinherited

Returns the result of subtracting another tuple from this tuple.

Definition at line 568 of file Types.h.

◆ operator-=()

Tuple<N, T>& Argus::Tuple< N, T >::operator-= ( const Tuple< N, T > &  rhs)
inlineinherited

Subtracts every element of another tuple from the elements of this tuple.

Definition at line 538 of file Types.h.

◆ operator/()

const Tuple<N, T> Argus::Tuple< N, T >::operator/ ( const T &  rhs) const
inlineinherited

Returns the result of dividing this tuple by a single value.

Definition at line 580 of file Types.h.

◆ operator/=()

Tuple<N, T>& Argus::Tuple< N, T >::operator/= ( const T &  rhs)
inlineinherited

Divides every element in the tuple by a single value.

Definition at line 554 of file Types.h.

◆ operator==()

bool Argus::Tuple< N, T >::operator== ( const Tuple< N, T > &  rhs) const
inlineinherited

Returns true when every element in the two tuples are identical.

Definition at line 518 of file Types.h.

◆ operator[]() [1/2]

T& Argus::Tuple< N, T >::operator[] ( unsigned int  i)
inlineinherited

Definition at line 585 of file Types.h.

◆ operator[]() [2/2]

const T& Argus::Tuple< N, T >::operator[] ( unsigned int  i) const
inlineinherited

Definition at line 586 of file Types.h.

◆ r() [1/2]

template<typename T >
T& Argus::RGBTuple< T >::r ( )
inline

Definition at line 654 of file Types.h.

References Argus::RGB_CHANNEL_R.

Referenced by Argus::RGBTuple< T >::RGBTuple().

◆ r() [2/2]

template<typename T >
const T& Argus::RGBTuple< T >::r ( ) const
inline

Definition at line 655 of file Types.h.

References Argus::RGB_CHANNEL_R.

◆ tupleSize()

static unsigned int Argus::Tuple< N, T >::tupleSize
inlinestaticinherited

Returns the number of elements in the tuple.

Definition at line 589 of file Types.h.

Field Documentation

◆ m_data

T Argus::Tuple< N, T >::m_data[N]
protectedinherited

Definition at line 592 of file Types.h.

The documentation for this class was generated from the following file:
