_NvBufSurfTransformCompositeBlendParamsEx Struct Reference
Buffer Management API module » NvBufSurfTransform Types and Functions

Detailed Description

Holds extended composite blend parameters for NvBufSurfTransformMultiInputBufCompositeBlend and NvBufSurfTransformMultiInputBufCompositeBlendAsync API.

Definition at line 261 of file nvbufsurftransform.h.

Collaboration diagram for _NvBufSurfTransformCompositeBlendParamsEx:
Collaboration graph
[legend]

Data Fields

NvBufSurfTransformCompositeBlendParams params
 Holds legacy composite blend parameters. More...

NvBufSurfTransformRect * src_comp_rect
 Holds source rectangle coordinates of input buffers for compositing. More...

NvBufSurfTransformRect * dst_comp_rect
 Holds destination rectangle coordinates of input buffers for compositing. More...

NvBufSurfTransform_Inter * composite_blend_filter
 Holds composite filters to use for composition/blending. More...

float * alpha
 Holds alpha values of input buffers for the blending. More...

void * reserved [STRUCTURE_PADDING]
 reserved fields. More...


Field Documentation

◆ alpha

float* _NvBufSurfTransformCompositeBlendParamsEx::alpha

Holds alpha values of input buffers for the blending.

Definition at line 272 of file nvbufsurftransform.h.

◆ composite_blend_filter

NvBufSurfTransform_Inter* _NvBufSurfTransformCompositeBlendParamsEx::composite_blend_filter

Holds composite filters to use for composition/blending.

Definition at line 270 of file nvbufsurftransform.h.

◆ dst_comp_rect

NvBufSurfTransformRect* _NvBufSurfTransformCompositeBlendParamsEx::dst_comp_rect

Holds destination rectangle coordinates of input buffers for compositing.

Definition at line 268 of file nvbufsurftransform.h.

◆ params

NvBufSurfTransformCompositeBlendParams _NvBufSurfTransformCompositeBlendParamsEx::params

Holds legacy composite blend parameters.

Definition at line 264 of file nvbufsurftransform.h.

◆ reserved

void* _NvBufSurfTransformCompositeBlendParamsEx::reserved[STRUCTURE_PADDING]

reserved fields.

Definition at line 274 of file nvbufsurftransform.h.

◆ src_comp_rect

NvBufSurfTransformRect* _NvBufSurfTransformCompositeBlendParamsEx::src_comp_rect

Holds source rectangle coordinates of input buffers for compositing.

Definition at line 266 of file nvbufsurftransform.h.

The documentation for this struct was generated from the following file:
