v4l2_ctrl_hevcdec_bufmetadata_ Struct Reference
Detailed Description
Holds H.265 specific decoder metadata for the frame.
Definition at line 1911 of file v4l2_nv_extensions.h.
Collaboration diagram for v4l2_ctrl_hevcdec_bufmetadata_:
Data Fields | |
| __u32 | nPocLsbBits |
| Holds the number of bits in the frame. More... | |
| __u32 | FrameType |
| Type of frame: 0 = B 1 = P 2 = I. More... | |
| v4l2_ctrl_videodec_dpbinfometadata | dpbInfo |
| Holds the current DPB information of the decoder. More... | |
| __u32 | reserved [4] |
| Reserved fields are added for extensibility. More... | |
Field Documentation
◆ dpbInfo
| v4l2_ctrl_videodec_dpbinfometadata v4l2_ctrl_hevcdec_bufmetadata_::dpbInfo |
Holds the current DPB information of the decoder.
Definition at line 1921 of file v4l2_nv_extensions.h.
◆ FrameType
| __u32 v4l2_ctrl_hevcdec_bufmetadata_::FrameType |
Type of frame: 0 = B 1 = P 2 = I.
Definition at line 1919 of file v4l2_nv_extensions.h.
◆ nPocLsbBits
| __u32 v4l2_ctrl_hevcdec_bufmetadata_::nPocLsbBits |
Holds the number of bits in the frame.
Definition at line 1914 of file v4l2_nv_extensions.h.
◆ reserved
| __u32 v4l2_ctrl_hevcdec_bufmetadata_::reserved[4] |
Reserved fields are added for extensibility.
Definition at line 1923 of file v4l2_nv_extensions.h.
The documentation for this struct was generated from the following file:
- libv4l2/include/linux/v4l2_nv_extensions.h
