Argus::Ext::ISensorTimestampTsc Class Reference

Detailed Description

Interface used to get TSC HW timestamp

Definition at line 63 of file SensorTimestampTsc.h.

Inheritance diagram for Argus::Ext::ISensorTimestampTsc:

Collaboration diagram for Argus::Ext::ISensorTimestampTsc:

Public Member Functions
virtual uint64_t	getSensorSofTimestampTsc () const =0
	Returns the VI HW (SOF) timestamp based on tegra wide timestamp system counter (TSC) This is the start timestamp for the sensor (in nanoseconds). More...
virtual uint64_t	getSensorSofTimestampTsc2 () const =0
	Returns the VI HW (SOF) timestamp for second sensor based on tegra wide timestamp system counter (TSC) This is the start timestamp for the sensor (in nanoseconds). More...
virtual uint64_t	getSensorEofTimestampTsc () const =0
	Returns the VI HW (EOF) timestamp based on tegra wide timestamp system counter (TSC) This is the end timestamp for the sensor (in nanoseconds). More...

Static Public Member Functions
static const InterfaceID &	id ()

Protected Member Functions
	~ISensorTimestampTsc ()

Constructor & Destructor Documentation

~ISensorTimestampTsc()

Argus::Ext::ISensorTimestampTsc::~ISensorTimestampTsc ( )

inlineprotected

Definition at line 88 of file SensorTimestampTsc.h.

Member Function Documentation

getSensorEofTimestampTsc()

virtual uint64_t Argus::Ext::ISensorTimestampTsc::getSensorEofTimestampTsc ( ) const

pure virtual

Returns the VI HW (EOF) timestamp based on tegra wide timestamp system counter (TSC) This is the end timestamp for the sensor (in nanoseconds).

getSensorSofTimestampTsc()

virtual uint64_t Argus::Ext::ISensorTimestampTsc::getSensorSofTimestampTsc ( ) const

pure virtual

Returns the VI HW (SOF) timestamp based on tegra wide timestamp system counter (TSC) This is the start timestamp for the sensor (in nanoseconds).

getSensorSofTimestampTsc2()

virtual uint64_t Argus::Ext::ISensorTimestampTsc::getSensorSofTimestampTsc2 ( ) const

pure virtual

Returns the VI HW (SOF) timestamp for second sensor based on tegra wide timestamp system counter (TSC) This is the start timestamp for the sensor (in nanoseconds).

id()

static const InterfaceID& Argus::Ext::ISensorTimestampTsc::id ( )

inlinestatic

Definition at line 66 of file SensorTimestampTsc.h.

---

The documentation for this class was generated from the following file:

• Argus/Ext/SensorTimestampTsc.h
