Detailed Description

Defines a helper class for V4L2 Video Encoder.

The video encoder device node is "/dev/nvhost-msenc". The category name for the encoder is "NVENC".

Refer to V4L2 Video Encoder for more information on the encoder.

Definition at line 61 of file NvVideoEncoder.h.

Inheritance diagram for NvVideoEncoder:

[legend]

Collaboration diagram for NvVideoEncoder:

[legend]

Public Member Functions
	~NvVideoEncoder ()

int	setOutputPlaneFormat (uint32_t pixfmt, uint32_t width, uint32_t height, enum v4l2_colorspace cs=V4L2_COLORSPACE_SMPTE170M)
	Sets the format on the encoder output plane. More...

int	setCapturePlaneFormat (uint32_t pixfmt, uint32_t width, uint32_t height, uint32_t sizeimage)
	Sets the format on the converter capture plane. More...

int	setFrameRate (uint32_t framerate_num, uint32_t framerate_den)
	Sets the encode framerate. More...

int	setBitrate (uint32_t bitrate)
	Sets the encoder bitrate. More...

int	setPeakBitrate (uint32_t peak_bitrate)
	Sets the encoder peak bitrate. More...

int	setProfile (uint32_t profile)
	Sets the encoder profile. More...

int	setEncoderCommand (int cmd, int flags)
	Sets the encoder command. More...

int	setLevel (uint32_t level)
	Set the encoder level. More...

int	setMaxPerfMode (int flag)
	Sets the encoder for maximum performance. More...

int	setConstantQp (bool enabled_rc)
	Sets constant QP for encoder. More...

int	setRateControlMode (enum v4l2_mpeg_video_bitrate_mode mode)
	Sets the encoder rate control mode. More...

int	setIFrameInterval (uint32_t interval)
	Sets the encoder I-frame interval. More...

int	setIDRInterval (uint32_t interval)
	Sets the encoder IDR interval. More...

int	forceIDR ()
	Forces an IDR frame. More...

int	setTemporalTradeoff (v4l2_enc_temporal_tradeoff_level_type level)
	Sets the encoder Temporal Tradeoff. More...

int	setSliceLength (v4l2_enc_slice_length_type type, uint32_t length)
	Sets the encoder output slice length. More...

int	setHWPresetType (v4l2_enc_hw_preset_type type)
	Sets the encoder HW Preset Type. More...

int	setROIParams (uint32_t buffer_index, v4l2_enc_frame_ROI_params &params)
	Sets the Region of Interest (ROI) parameters for the next buffer, which will be queued on the output plane with index buffer_index. More...

int	setPPEInitParams (v4l2_enc_ppe_init_params &params)
	Sets the preprocessing enhancement (PPE) initialization parameters at the start of the session. More...

int	enableROI (v4l2_enc_enable_roi_param &params)
	Enables External ROI. More...

int	enableReconCRC (v4l2_enc_enable_reconcrc_param &params)
	Enables Recon CRC. More...

int	enableExternalRPS (v4l2_enc_enable_ext_rps_ctr &params)
	Enable External RPS. More...

int	enableExternalRC (v4l2_enc_enable_ext_rate_ctr &params)
	Enable External Picture RC. More...

int	enableAV1Tile (v4l2_enc_av1_tile_config &params)
	Enable AV1 Multi-tile configuration. More...

int	setAV1SsimRdo (bool enabled)
	Enable AV1 variance based SSIM RDO. More...

int	setAV1DisableCDFUpdate (bool disabled)
	Disable AV1 CDF update in the symbol decoding process. More...

int	setAV1ErrResilienceMode (bool enabled)
	Enable Error Resilient Mode for AV1. More...

int	setAV1FrameIDPresentFlag (bool enabled)
	Enable AV1 frame_id_numbers_present_flag. More...

int	enableAV1TileGroups (bool enabled)
	Enable AV1 frame_id_numbers_present_flag. More...

int	SetInputMetaParams (uint32_t buffer_index, v4l2_ctrl_videoenc_input_metadata &params)
	Set input Metadata parameters for the next buffer which will be queued on output plane with index buffer_index. More...

int	setVirtualBufferSize (uint32_t size)
	Sets the virtual buffer size of the encoder. More...

int	setNumReferenceFrames (uint32_t num_frames)
	Sets the number of reference frames of the encoder. More...

int	setSliceIntrarefresh (uint32_t interval)
	Sets slice intra-refresh interval params. More...

int	setNumBFrames (uint32_t num)
	Sets the number of B frames to P frames. More...

int	setInsertSpsPpsAtIdrEnabled (bool enabled)
	Enables/disables insert SPS PPS at every IDR. More...

int	setCABAC (bool enabled)
	Enables/disables CABAC entropy encoding for H264. More...

int	setSliceLevelEncode (bool enabled)
	Enables/disables Slice level encoding for H264 / HEVC. More...

int	enableMotionVectorReporting ()
	Enables video encoder output motion vector metadata reporting. More...

int	getMetadata (uint32_t buffer_index, v4l2_ctrl_videoenc_outputbuf_metadata &enc_metadata)
	Gets metadata for the encoded capture plane buffer. More...

int	getMotionVectors (uint32_t buffer_index, v4l2_ctrl_videoenc_outputbuf_metadata_MV &enc_mv_metadata)
	Gets motion vector metadata for the encoded capture plane buffer. More...

int	setQpRange (uint32_t MinQpI, uint32_t MaxQpI, uint32_t MinQpP, uint32_t MaxQpP, uint32_t MinQpB, uint32_t MaxQpB)
	Sets QP values for I/P/B frames. More...

int	setSampleAspectRatioWidth (uint32_t sar_width)
	Sets Sample Aspect Ratio width for VUI encoding. More...

int	setSampleAspectRatioHeight (uint32_t sar_height)
	Sets Sample Aspect Ratio height for VUI encoding. More...

int	setInsertVuiEnabled (bool enabled)
	Enables/disables insert VUI. More...

int	setExtendedColorFormat (bool enabled)
	Enables/disables extended color format. More...

int	setInsertAudEnabled (bool enabled)
	Enables/disables insert AUD. More...

int	setAlliFramesEncode (bool enabled)
	Enables/disables all i-frame encode. More...

int	setPocType (uint32_t pocType)
	Sets the encoder Picture Order Control type. More...

int	setInitQP (uint32_t IinitQP, uint32_t PinitQP, uint32_t BinitQP)
	Sets the initial QP for I/P/B frames. More...

int	setFramesToEncode (uint32_t framesToEncode)
	Sets the number of frames to encode. More...

int	setChromaFactorIDC (uint8_t crfactor)
	Sets the H.265 encoder Chroma Format IDC. More...

int	setLossless (bool enabled)
	Sets the lossless encoding for H.264/H.265. More...

int	setDisableAMP (bool enabled)
	Sets the Disable AMP types to true for H.265. More...

int	enableTwoPassCBR ()
	Sets whether to enable two pass CBR for H.264/H.265. More...

int	DevicePoll (v4l2_ctrl_video_device_poll *devicepoll)
	Issues Poll on the device which blocks until : a) Either there is something to dequeue from capture or output plane or any events. More...

int	SetPollInterrupt ()
	Sets the polling interrupt, now if the application calls Poll, the device should not block, in other words polling is disabled. More...

int	ClearPollInterrupt ()
	Clears the polling interrupt, now if the application calls Poll, the device should block until the event is triggered, in other words polling is enabled. More...

int	subscribeEvent (uint32_t type, uint32_t id, uint32_t flags)
	Subscribes to an V4L2 event. More...

int	dqEvent (struct v4l2_event &event, uint32_t max_wait_ms)
	Dequeues an event from the element. More...

int	setControl (uint32_t id, int32_t value)
	Sets the value of a control. More...

int	getControl (uint32_t id, int32_t &value)
	Gets the value of a control. More...

int	setExtControls (struct v4l2_ext_controls &ctl)
	Sets the value of several controls. More...

int	getExtControls (struct v4l2_ext_controls &ctl)
	Gets the value of several controls. More...

virtual int	isInError ()

int	abort ()
	Terminates processing of queued buffers immediately. More...

virtual int	waitForIdle (uint32_t max_wait_ms)
	Waits until the element processes all the output plane buffers. More...

void	enableProfiling ()
	Enables profiling for the V4l2Element. More...

void	getProfilingData (NvElementProfiler::NvElementProfilerData &data)
	Gets profiling data for the element. More...

void	printProfilingStats (std::ostream &out_stream=std::cout)
	Prints profiling data for the element to an output stream. More...

bool	isProfilingEnabled ()
	Checks whether profiling is enabled for the element. More...

Static Public Member Functions
static NvVideoEncoder *	createVideoEncoder (const char *name, int flags=0)
	Creates a new V4L2 Video Encoder object named name. More...

Data Fields
NvV4l2ElementPlane	output_plane
	Sets the output plane. More...

NvV4l2ElementPlane	capture_plane
	Sets the capture plane. More...

void *	app_data
	A pointer to the application-specific data. More...

Protected Attributes
int	fd
	Specifies the FD of the device opened using `v4l2_open`. More...

uint32_t	output_plane_pixfmt
	Pixel format of output plane buffers. More...

uint32_t	capture_plane_pixfmt
	Pixel format of capture plane buffers. More...

int	is_in_error
	Indicates if an error was encountered during the operation of the element. More...

const char *	comp_name
	Specifies the name of the component, for debugging. More...

NvElementProfiler	profiler
	Profiler for the element. More...

Constructor & Destructor Documentation

◆ ~NvVideoEncoder()

NvVideoEncoder::~NvVideoEncoder ( )

Member Function Documentation

◆ abort()

int NvV4l2Element::abort ( )

inherited

Terminates processing of queued buffers immediately.

All the buffers are returned to the application.

Calls VIDIOC_STREAMOFF IOCTL on both of the planes internally.

Returns: 0 for success, -1 otherwise.

◆ ClearPollInterrupt()

int NvVideoEncoder::ClearPollInterrupt ( )

Clears the polling interrupt, now if the application calls Poll, the device should block until the event is triggered, in other words polling is enabled.

◆ createVideoEncoder()

static NvVideoEncoder* NvVideoEncoder::createVideoEncoder	(	const char *	name,
		int	flags = `0`
	)

static

Creates a new V4L2 Video Encoder object named name.

This method internally calls v4l2_open on the encoder dev node "/dev/nvhost-msenc" and checks for V4L2_CAP_VIDEO_M2M_MPLANE capability on the device. This method allows the caller to specify additional flags with which the device must be opened.

The device is opened in blocking mode, which can be modified by passing the O_NONBLOCK flag to this method.

Returns: Reference to the newly created encoder object, else NULL in case of failure during initialization.

◆ DevicePoll()

int NvVideoEncoder::DevicePoll ( v4l2_ctrl_video_device_poll * devicepoll )

Issues Poll on the device which blocks until : a) Either there is something to dequeue from capture or output plane or any events.

b) Poll was interrupted by a call to the device using V4L2_CID_SET_POLL_INTERRUPT c) Application has already interrupted polling by V4L2_CID_SET_POLL_INTERRUPT

◆ dqEvent()

int NvV4l2Element::dqEvent	(	struct v4l2_event &	event,
		uint32_t	max_wait_ms
	)

inherited

Dequeues an event from the element.

Calls VIDIOC_DQEVENT IOCTL internally. The caller can specify the maximum time to wait for dequeuing the event. The call blocks until an event is dequeued successfully or timeout is reached.

Parameters

[in,out]	event	A reference to the `v4l2_event` structure to fill.
[in]	max_wait_ms	Specifies the max wait time for dequeuing an event, in milliseconds.

Returns: 0 for success, -1 otherwise.

◆ enableAV1Tile()

int NvVideoEncoder::enableAV1Tile ( v4l2_enc_av1_tile_config & params )

Enable AV1 Multi-tile configuration.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEOENC_AV1_TILE_CONFIGURATION. Must be called after setFormat on both the planes and before requestBuffers on any of the planes.

Parameters

[in] params Parameters to be applied, structure of type #v4l2_enc_av1_tile_config

Returns: 0 for success, -1 otherwise.

◆ enableAV1TileGroups()

int NvVideoEncoder::enableAV1TileGroups ( bool enabled )

Enable AV1 frame_id_numbers_present_flag.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEOENC_AV1_ENABLE_TILE_GROUPS. Must be called after setFormat on both the planes.

Parameters

[in] enabled Boolean value indicating whether to enable/disable the control.

Returns: 0 for success, -1 otherwise.

◆ enableExternalRC()

int NvVideoEncoder::enableExternalRC ( v4l2_enc_enable_ext_rate_ctr & params )

Enable External Picture RC.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEOENC_ENABLE_EXTERNAL_RATE_CONTROL. Must be called after requesting buffer on both the planes.

Parameters

[in] params Parameters to be applied on the frame, structure of type #v4l2_enc_enable_ext_rate_ctr

Returns: 0 for success, -1 otherwise.

◆ enableExternalRPS()

int NvVideoEncoder::enableExternalRPS ( v4l2_enc_enable_ext_rps_ctr & params )

Enable External RPS.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEOENC_ENABLE_EXTERNAL_RPS_CONTROL. Must be called after requesting buffer on both the planes.

Parameters

[in] params Parameters to be applied on the frame, structure of type v4l2_enc_enable_ext_rps_ctr

Returns: 0 for success, -1 otherwise.

◆ enableMotionVectorReporting()

int NvVideoEncoder::enableMotionVectorReporting ( )

Enables video encoder output motion vector metadata reporting.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEOENC_METADATA_MV. Must be called after setFormat on both the planes and before requestBuffers on any of the planes.

Returns: 0 for success, -1 otherwise.

◆ enableProfiling()

void NvV4l2Element::enableProfiling ( )

virtualinherited

Enables profiling for the V4l2Element.

Must be called before setting either plane formats.

Reimplemented from NvElement.

◆ enableReconCRC()

int NvVideoEncoder::enableReconCRC ( v4l2_enc_enable_reconcrc_param & params )

Enables Recon CRC.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEOENC_ENABLE_RECONCRC_PARAM. Must be called after requesting buffer on both the planes.

Parameters

[in] params Parameters to be applied on the frame, structure of type v4l2_enc_enable_reconcrc_param.

Returns: 0 for success, -1 otherwise.

◆ enableROI()

int NvVideoEncoder::enableROI ( v4l2_enc_enable_roi_param & params )

Enables External ROI.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEOENC_ENABLE_ROI_PARAM. Must be called after requesting buffer on both the planes.

Parameters

[in] params Parameters to be applied on the frame, structure of type v4l2_enc_enable_roi_param.

Returns: 0 for success, -1 otherwise.

◆ enableTwoPassCBR()

int NvVideoEncoder::enableTwoPassCBR ( )

Sets whether to enable two pass CBR for H.264/H.265.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEOENC_TWO_PASS_CBR. Must be called after setFormat on both the planes and before requestBuffers on any of the planes.

Returns: 0 for success, -1 otherwise.

◆ forceIDR()

int NvVideoEncoder::forceIDR ( )

Forces an IDR frame.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_MFC51_VIDEO_FORCE_FRAME_TYPE. Must be called after setFormat on both the planes.

Returns: 0 for success, -1 otherwise.

◆ getControl()

int NvV4l2Element::getControl	(	uint32_t	id,
		int32_t &	value
	)

inherited

Gets the value of a control.

Calls VIDIOC_G_CTRL IOCTL internally.

Parameters

[in]	id	ID of the control to get.
[out]	value	A reference to the variable into which the control value is read.

Returns: 0 for success, -1 otherwise.

◆ getExtControls()

int NvV4l2Element::getExtControls ( struct v4l2_ext_controls & ctl )

inherited

Gets the value of several controls.

Calls VIDIOC_G_EXT_CTRLS IOCTL internally.

Parameters

[in,out] ctl A pointer to the controls to get.

Returns: 0 for success, -1 otherwise.

◆ getMetadata()

int NvVideoEncoder::getMetadata	(	uint32_t	buffer_index,
		v4l2_ctrl_videoenc_outputbuf_metadata &	enc_metadata
	)

Gets metadata for the encoded capture plane buffer.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEOENC_METADATA. Must be called for a buffer that has been dequeued from the capture plane. The returned metadata corresponds to the last dequeued buffer with index buffer_index.

Parameters

[in]	buffer_index	Index of the capture plane buffer whose metadata is required.
[in,out]	enc_metadata	Reference to the metadata structure v4l2_ctrl_videoenc_outputbuf_metadata to be filled.

Returns: 0 for success, -1 otherwise.

◆ getMotionVectors()

int NvVideoEncoder::getMotionVectors	(	uint32_t	buffer_index,
		v4l2_ctrl_videoenc_outputbuf_metadata_MV &	enc_mv_metadata
	)

Gets motion vector metadata for the encoded capture plane buffer.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEOENC_METADATA_MV. Must be called for a buffer that has been dequeued from the capture plane. The returned metadata corresponds to the last dequeued buffer with index buffer_index.

Parameters

[in]	buffer_index	Index of the capture plane buffer whose metadata is required.
[in,out]	enc_mv_metadata	Reference to the metadata structure v4l2_ctrl_videoenc_outputbuf_metadata_MV to be filled.

Returns: 0 for success, -1 otherwise.

◆ getProfilingData()

void NvElement::getProfilingData ( NvElementProfiler::NvElementProfilerData & data )

inherited

Gets profiling data for the element.

Returns: A constant reference to the element's profiling data.

◆ isInError()

virtual int NvV4l2Element::isInError ( )

virtualinherited

Reimplemented from NvElement.

◆ isProfilingEnabled()

bool NvElement::isProfilingEnabled ( )

inherited

Checks whether profiling is enabled for the element.

Returns: Boolean value indicating if profiling is enabled.

◆ printProfilingStats()

void NvElement::printProfilingStats ( std::ostream & out_stream = std::cout )

inherited

Prints profiling data for the element to an output stream.

Parameters

[in] out_stream Output stream of type std::ostream to print the data to. It takes the default value std::cout if not specified.

◆ setAlliFramesEncode()

int NvVideoEncoder::setAlliFramesEncode ( bool enabled )

Enables/disables all i-frame encode.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEOENC_ENABLE_ALLIFRAME_ENCODE. Must be called after setFormat on both the planes.

Parameters

[in] enabled Boolean value indicating whether to enable/disable the control.

Returns: 0 for success, -1 otherwise.

◆ setAV1DisableCDFUpdate()

int NvVideoEncoder::setAV1DisableCDFUpdate ( bool disabled )

Disable AV1 CDF update in the symbol decoding process.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEOENC_AV1_DISABLE_CDF_UPDATE. The value true disables the CDF update. Must be called after setFormat on both the planes.

Parameters

[in] disabled Boolean value indicating whether to enable/disable the control.

Returns: 0 for success, -1 otherwise.

◆ setAV1ErrResilienceMode()

int NvVideoEncoder::setAV1ErrResilienceMode ( bool enabled )

Enable Error Resilient Mode for AV1.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEOENC_AV1_ERR_RESILIENT_MODE. The value true disables the control. Must be called after setFormat on both the planes.

Parameters

[in] enabled Boolean value indicating whether to enable/disable the control.

Returns: 0 for success, -1 otherwise.

◆ setAV1FrameIDPresentFlag()

int NvVideoEncoder::setAV1FrameIDPresentFlag ( bool enabled )

Enable AV1 frame_id_numbers_present_flag.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEOENC_AV1_ENABLE_FRAMEID_NUMBERS. Must be called after setFormat on both the planes.

Parameters

[in] enabled Boolean value indicating whether to enable/disable the control.

Returns: 0 for success, -1 otherwise.

◆ setAV1SsimRdo()

int NvVideoEncoder::setAV1SsimRdo ( bool enabled )

Enable AV1 variance based SSIM RDO.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEOENC_AV1_ENABLE_SSIMRDO. Must be called after setFormat on both the planes.

Parameters

[in] enabled Boolean value indicating whether to enable/disable the control.

Returns: 0 for success, -1 otherwise.

◆ setBitrate()

int NvVideoEncoder::setBitrate ( uint32_t bitrate )

Sets the encoder bitrate.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEO_BITRATE. Can be called any time after setFormat on both the planes.

Parameters

[in] bitrate Bitrate of the encoded stream, in bits per second.

Returns: 0 for success, -1 otherwise.

◆ setCABAC()

int NvVideoEncoder::setCABAC ( bool enabled )

Enables/disables CABAC entropy encoding for H264.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEO_H264_ENTROPY_MODE. Must be called after setFormat on both the planes.

Parameters

[in] enabled Boolean value indicating whether to enable/disable the control.

Returns: 0 for success, -1 otherwise.

◆ setCapturePlaneFormat()

int NvVideoEncoder::setCapturePlaneFormat	(	uint32_t	pixfmt,
		uint32_t	width,
		uint32_t	height,
		uint32_t	sizeimage
	)

Sets the format on the converter capture plane.

Calls VIDIOC_S_FMT IOCTL internally on the capture plane.

Parameters

[in]	pixfmt	One of the coded V4L2 pixel formats.
[in]	width	Width of the input buffers in pixels.
[in]	height	Height of the input buffers in pixels.
[in]	sizeimage	Maximum size of the encoded buffers on the capture. plane in bytes

Returns: 0 for success, -1 otherwise.

◆ setChromaFactorIDC()

int NvVideoEncoder::setChromaFactorIDC ( uint8_t crfactor )

Sets the H.265 encoder Chroma Format IDC.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEOENC_H265_CHROMA_FACTOR_IDC. Must be called after setFormat on both the planes and before requestBuffers on any of the planes.

Parameters

[in] crfactor Set chroma_factor_idc for the encoder.

Returns: 0 for success, -1 otherwise.

◆ setConstantQp()

int NvVideoEncoder::setConstantQp ( bool enabled_rc )

Sets constant QP for encoder.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEO_FRAME_RC_ENABLE to enable/disable rate control. If the value false is given, it disables RC and set constant QP parameters. Must be called after setFormat on both the planes and before requestBuffers on any of the planes.

Parameters

[in] enabled_rc Boolean value indicating whether to enable/disable the control.

Returns: 0 for success, -1 otherwise.

◆ setControl()

int NvV4l2Element::setControl	(	uint32_t	id,
		int32_t	value
	)

inherited

Sets the value of a control.

Calls VIDIOC_S_CTRL IOCTL internally.

Parameters

[in]	id	ID of the control to be set.
[in]	value	Value to be set on the control.

Returns: 0 for success, -1 otherwise.

◆ setDisableAMP()

int NvVideoEncoder::setDisableAMP ( bool enabled )

Sets the Disable AMP types to true for H.265.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEOENC_H265_DISABLE_AMP. Must be called after setFormat on both the planes and before requestBuffers on any of the planes.

Parameters

[in] enabled Indicates whether to enable or disable the control.

Returns: 0 for success, -1 otherwise.

◆ setEncoderCommand()

int NvVideoEncoder::setEncoderCommand	(	int	cmd,
		int	flags
	)

Sets the encoder command.

Calls the VIDIOC_ENCODER_CMD internally with encoder commands.

Returns: 0 for succes, -1 otherwise.

◆ setExtControls()

int NvV4l2Element::setExtControls ( struct v4l2_ext_controls & ctl )

inherited

Sets the value of several controls.

Calls VIDIOC_S_EXT_CTRLS IOCTL internally.

Parameters

[in] ctl A pointer to the controls to set.

Returns: 0 for success, -1 otherwise.

◆ setExtendedColorFormat()

int NvVideoEncoder::setExtendedColorFormat ( bool enabled )

Enables/disables extended color format.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEOENC_EXTEDED_COLORFORMAT. Must be called after setFormat on both the planes.

Parameters

[in] enabled Boolean value indicating whether to enable/disable the control.

Returns: 0 for success, -1 otherwise.

◆ setFrameRate()

int NvVideoEncoder::setFrameRate	(	uint32_t	framerate_num,
		uint32_t	framerate_den
	)

Sets the encode framerate.

Calls the VIDIOC_S_PARM IOCTL on the encoder capture plane. Can be called any time after setFormat on both the planes.

Parameters

[in]	framerate_num	Numerator part of the framerate fraction.
[in]	framerate_den	Denominator part of the framerate fraction.

Returns: 0 for success, -1 otherwise.

◆ setFramesToEncode()

int NvVideoEncoder::setFramesToEncode ( uint32_t framesToEncode )

Sets the number of frames to encode.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEOENC_FRAMES_TO_ENCODE. Must be called after setFormat on both the planes.

Parameters

[in] framesToEncode Set the number of frames to encode.

Returns: 0 for success, -1 otherwise.

◆ setHWPresetType()

int NvVideoEncoder::setHWPresetType ( v4l2_enc_hw_preset_type type )

Sets the encoder HW Preset Type.

Calls the VIDIOC_S_EXT_CTRLS ioctl internally with Control ID V4L2_CID_MPEG_VIDEOENC_HW_PRESET_TYPE_PARAM. Must be called after setFormat() on both the planes and before requestBuffers on any of the planes.

Parameters

[in] type HW Preset Type, one of enum v4l2_enc_hw_preset_type_param.

Returns: 0 for success, -1 otherwise.

◆ setIDRInterval()

int NvVideoEncoder::setIDRInterval ( uint32_t interval )

Sets the encoder IDR interval.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEO_IDR_INTERVAL. Must be called after setFormat on both the planes and before requestBuffers on any of the planes.

Parameters

[in] interval Interval between two IDR frames, in number of frames.

Returns: 0 for success, -1 otherwise.

◆ setIFrameInterval()

int NvVideoEncoder::setIFrameInterval ( uint32_t interval )

Sets the encoder I-frame interval.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEO_GOP_SIZE. Must be called after setFormat on both the planes and before requestBuffers on any of the planes.

Parameters

[in] interval Interval between two I frames, in number of frames.

Returns: 0 for success, -1 otherwise.

◆ setInitQP()

int NvVideoEncoder::setInitQP	(	uint32_t	IinitQP,
		uint32_t	PinitQP,
		uint32_t	BinitQP
	)

Sets the initial QP for I/P/B frames.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with control Id V4L2_CID_MPEG_VIDEOENC_INIT_FRAME_QP. Must be called after setFormat on both the planes.

Parameters

[in]	IinitQP	Qp Value for I frame.
[in]	PinitQP	Qp Value for P frame.
[in]	BinitQP	Qp Value for B frame.

Returns: 0 for success, -1 otherwise.

◆ SetInputMetaParams()

int NvVideoEncoder::SetInputMetaParams	(	uint32_t	buffer_index,
		v4l2_ctrl_videoenc_input_metadata &	params
	)

Set input Metadata parameters for the next buffer which will be queued on output plane with index buffer_index.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEOENC_INPUT_METADATA. Must be called after requesting buffer on both the planes.

Parameters

[in]	buffer_index	Index of output plane buffer on which the external RC params should be applied.
[in]	params	Parameters to be applied on the frame, structure of type v4l2_ctrl_videoenc_input_metadata

Returns: 0 for success, -1 otherwise.

◆ setInsertAudEnabled()

int NvVideoEncoder::setInsertAudEnabled ( bool enabled )

Enables/disables insert AUD.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEO_H264_AUD_SAR_ENABLE. Must be called after setFormat on both the planes.

Parameters

[in] enabled Boolean value indicating whether to enable/disable the control.

Returns: 0 for success, -1 otherwise.

◆ setInsertSpsPpsAtIdrEnabled()

int NvVideoEncoder::setInsertSpsPpsAtIdrEnabled ( bool enabled )

Enables/disables insert SPS PPS at every IDR.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEOENC_INSERT_SPS_PPS_AT_IDR. Must be called after setFormat on both the planes.

Parameters

[in] enabled Boolean value indicating whether to enable/disable the control.

Returns: 0 for success, -1 otherwise.

◆ setInsertVuiEnabled()

int NvVideoEncoder::setInsertVuiEnabled ( bool enabled )

Enables/disables insert VUI.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEOENC_INSERT_VUI. Must be called after setFormat on both the planes.

Parameters

[in] enabled Boolean value indicating whether to enable/disable the control.

Returns: 0 for success, -1 otherwise.

◆ setLevel()

int NvVideoEncoder::setLevel ( uint32_t level )

Set the encoder level.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEO_H264_LEVEL or V4L2_CID_MPEG_VIDEOENC_H265_LEVEL, depending on encoder type. Must be called after setFormat on both the planes and before requestBuffers on any of the planes.

Parameters

[in] level Level to be used for encoding

Returns: 0 for success, -1 otherwise.

◆ setLossless()

int NvVideoEncoder::setLossless ( bool enabled )

Sets the lossless encoding for H.264/H.265.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEOENC_ENABLE_LOSSLESS. Must be called after setFormat on both the planes and before requestBuffers on any of the planes.

Parameters

[in] enabled Indicates whether to enable or disable the control.

Returns: 0 for success, -1 otherwise.

◆ setMaxPerfMode()

int NvVideoEncoder::setMaxPerfMode ( int flag )

Sets the encoder for maximum performance.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEO_MAX_PERFORMANCE. Must be called after setFormat on both the planes and before requestBuffers on any of the planes.

Parameters

[in] flag Integer variable to indicate whether max performance is to be enabled/disabled.

Returns: 0 for success, -1 otherwise.

◆ setNumBFrames()

int NvVideoEncoder::setNumBFrames ( uint32_t num )

Sets the number of B frames to P frames.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEOENC_NUM_BFRAMES. Must be called after setFormat on both the planes.

Parameters

[in] num Number of B frames.

Returns: 0 for success, -1 otherwise.

◆ setNumReferenceFrames()

int NvVideoEncoder::setNumReferenceFrames ( uint32_t num_frames )

Sets the number of reference frames of the encoder.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEOENC_NUM_REFERENCE_FRAMES. Must be called after setFormat on both the planes.

Parameters

[in] num_frames Number of reference frames.

Returns: 0 for success, -1 otherwise.

◆ setOutputPlaneFormat()

int NvVideoEncoder::setOutputPlaneFormat	(	uint32_t	pixfmt,
		uint32_t	width,
		uint32_t	height,
		enum v4l2_colorspace	cs = `V4L2_COLORSPACE_SMPTE170M`
	)

Sets the format on the encoder output plane.

Calls VIDIOC_S_FMT IOCTL internally on the output plane.

Precondition: Applications must set the capture plane format using setCapturePlaneFormat before calling this method.

Parameters

[in]	pixfmt	One of the raw V4L2 pixel formats.
[in]	width	Width of the input buffers in pixels.
[in]	height	Height of the input buffers in pixels.

Returns: 0 for success, -1 otherwise.

◆ setPeakBitrate()

int NvVideoEncoder::setPeakBitrate ( uint32_t peak_bitrate )

Sets the encoder peak bitrate.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEO_BITRATE_PEAK. Can be called any time after setFormat on both the planes. Takes effect in VBR mode

Parameters

[in] peak_bitrate Peak Bitrate of the encoded stream, in bits per second.

Returns: 0 for success, -1 otherwise.

◆ setPocType()

int NvVideoEncoder::setPocType ( uint32_t pocType )

Sets the encoder Picture Order Control type.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEOENC_POC_TYPE. Must be called after setFormat on both the planes and before requestBuffers on any of the planes.

Parameters

[in] pocType Set the Picture Order Count for the encoder.

Returns: 0 for success, -1 otherwise.

◆ SetPollInterrupt()

int NvVideoEncoder::SetPollInterrupt ( )

Sets the polling interrupt, now if the application calls Poll, the device should not block, in other words polling is disabled.

◆ setPPEInitParams()

int NvVideoEncoder::setPPEInitParams ( v4l2_enc_ppe_init_params & params )

Sets the preprocessing enhancement (PPE) initialization parameters at the start of the session.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEOENC_PPE_INIT_PARAMS. Must be called after requesting buffer on both the planes.

Parameters

[in] params A reference to the parameters to be applied on the frame, structure of type v4l2_enc_ppe_init_params.

Returns: 0 for success, -1 otherwise.

◆ setProfile()

int NvVideoEncoder::setProfile ( uint32_t profile )

Sets the encoder profile.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEO_H264_PROFILE or V4L2_CID_MPEG_VIDEO_H265_PROFILE, depending on the encoder type. Must be called after setFormat on both the planes and before requestBuffers on any of the planes.

Parameters

[in] profile Profile to be used for encoding.

Returns: 0 for success, -1 otherwise.

◆ setQpRange()

int NvVideoEncoder::setQpRange	(	uint32_t	MinQpI,
		uint32_t	MaxQpI,
		uint32_t	MinQpP,
		uint32_t	MaxQpP,
		uint32_t	MinQpB,
		uint32_t	MaxQpB
	)

Sets QP values for I/P/B frames.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with control Id V4L2_CID_MPEG_VIDEOENC_QP_RANGE. Must be called after setFormat on both the planes.

Parameters

[in]	MinQpI	Minimum Qp Value for I frame.
[in]	MaxQpI	Minimum Qp Value for I frame.
[in]	MinQpP	Minimum Qp Value for P frame.
[in]	MaxQpP	Minimum Qp Value for P frame.
[in]	MinQpB	Minimum Qp Value for B frame.
[in]	MaxQpB	Minimum Qp Value for B frame.

Returns: 0 for success, -1 otherwise.

◆ setRateControlMode()

int NvVideoEncoder::setRateControlMode ( enum v4l2_mpeg_video_bitrate_mode mode )

Sets the encoder rate control mode.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEO_BITRATE_MODE. Must be called after setFormat on both the planes and before requestBuffers on any of the planes.

Parameters

[in] mode Type of rate control, one of enum v4l2_mpeg_video_bitrate_mode.

Returns: 0 for success, -1 otherwise.

◆ setROIParams()

int NvVideoEncoder::setROIParams	(	uint32_t	buffer_index,
		v4l2_enc_frame_ROI_params &	params
	)

Sets the Region of Interest (ROI) parameters for the next buffer, which will be queued on the output plane with index buffer_index.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEOENC_ROI_PARAMS. Must be called after requesting buffer on both the planes.

Parameters

[in]	buffer_index	Index of the output plane buffer to apply the ROI params.
[in]	params	A reference to the parameters to be applied on the frame, structure of type v4l2_enc_frame_ROI_params.

Returns: 0 for success, -1 otherwise.

◆ setSampleAspectRatioHeight()

int NvVideoEncoder::setSampleAspectRatioHeight ( uint32_t sar_height )

Sets Sample Aspect Ratio height for VUI encoding.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with control Id V4L2_CID_MPEG_VIDEO_H264_VUI_EXT_SAR_HEIGHT or V4L2_CID_MPEG_VIDEOENC_H265_VUI_EXT_SAR_HEIGHT, depending on the encoder type. Must be called after setFormat on both the planes.

Parameters

[in] sar_height SAR for height.

Returns: 0 for success, -1 otherwise.

◆ setSampleAspectRatioWidth()

int NvVideoEncoder::setSampleAspectRatioWidth ( uint32_t sar_width )

Sets Sample Aspect Ratio width for VUI encoding.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with control Id V4L2_CID_MPEG_VIDEO_H264_VUI_EXT_SAR_WIDTH or V4L2_CID_MPEG_VIDEOENC_H265_VUI_EXT_SAR_WIDTH, depending on the encoder type. Must be called after setFormat on both the planes.

Parameters

[in] sar_width SAR for width.

Returns: 0 for success, -1 otherwise.

◆ setSliceIntrarefresh()

int NvVideoEncoder::setSliceIntrarefresh ( uint32_t interval )

Sets slice intra-refresh interval params.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEOENC_SLICE_INTRAREFRESH_PARAM. Must be called after setFormat on both the planes.

Parameters

[in] interval Slice intra-refresh interval, in number of slices.

Returns: 0 for success, -1 otherwise.

◆ setSliceLength()

int NvVideoEncoder::setSliceLength	(	v4l2_enc_slice_length_type	type,
		uint32_t	length
	)

Sets the encoder output slice length.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEOENC_SLICE_LENGTH_PARAM. Must be called after setFormat on both the planes and before requestBuffers on any of the planes.

Parameters

[in]	type	Slice length type, one of enum v4l2_enc_slice_length_type.
[in]	length	Length of the slice, in bytes if the type is V4L2_ENC_SLICE_LENGTH_TYPE_BITS, else in number of MBs if the type is V4L2_ENC_SLICE_LENGTH_TYPE_MBLK.

Returns: 0 for success, -1 otherwise.

◆ setSliceLevelEncode()

int NvVideoEncoder::setSliceLevelEncode ( bool enabled )

Enables/disables Slice level encoding for H264 / HEVC.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEOENC_ENABLE_SLICE_LEVEL_ENCODE. Must be called after setFormat on both the planes.

Parameters

[in] enabled Boolean value indicating whether to enable/disable the control.

Returns: 0 for success, -1 otherwise.

◆ setTemporalTradeoff()

int NvVideoEncoder::setTemporalTradeoff ( v4l2_enc_temporal_tradeoff_level_type level )

Sets the encoder Temporal Tradeoff.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEOENC_TEMPORAL_TRADEOFF_LEVEL. Must be called after setFormat on both the planes and before requestBuffers on any of the planes.

Parameters

[in] level Temporal tradeoff level, one of v4l2_enc_temporal_tradeoff_level_type.

Returns: 0 for success, -1 otherwise.

◆ setVirtualBufferSize()

int NvVideoEncoder::setVirtualBufferSize ( uint32_t size )

Sets the virtual buffer size of the encoder.

Calls the VIDIOC_S_EXT_CTRLS IOCTL internally with Control ID V4L2_CID_MPEG_VIDEOENC_VIRTUALBUFFER_SIZE. Must be called after setFormat on both the planes.

Parameters

[in] size Virtual buffer size, in bytes.

Returns: 0 for success, -1 otherwise.

◆ subscribeEvent()

int NvV4l2Element::subscribeEvent	(	uint32_t	type,
		uint32_t	id,
		uint32_t	flags
	)

inherited

Subscribes to an V4L2 event.

Calls VIDIOC_SUBSCRIBE_EVENT IOCTL internally.

Parameters

[in]	type	Type of the event.
[in]	id	ID of the event source.
[in]	flags	Event flags.

Returns: 0 for success, -1 otherwise.

◆ waitForIdle()

virtual int NvV4l2Element::waitForIdle ( uint32_t max_wait_ms )

virtualinherited

Waits until the element processes all the output plane buffers.

Objects extending V4l2Element must implement this because the idle condition is component-specific.

Parameters

[in] max_wait_ms Max time to wait in milliseconds.

Returns: 0 for success, -1 otherwise.

Field Documentation

◆ app_data

void* NvV4l2Element::app_data

inherited

A pointer to the application-specific data.

Definition at line 169 of file NvV4l2Element.h.

◆ capture_plane

NvV4l2ElementPlane NvV4l2Element::capture_plane

inherited

Sets the capture plane.

Capture plane of the element

Definition at line 145 of file NvV4l2Element.h.

◆ capture_plane_pixfmt

uint32_t NvV4l2Element::capture_plane_pixfmt

protectedinherited

Pixel format of capture plane buffers.

Definition at line 182 of file NvV4l2Element.h.

◆ comp_name

const char* NvElement::comp_name

protectedinherited

Specifies the name of the component, for debugging.

Definition at line 122 of file NvElement.h.

◆ fd

int NvV4l2Element::fd

protectedinherited

Specifies the FD of the device opened using v4l2_open.

Definition at line 179 of file NvV4l2Element.h.

◆ is_in_error

int NvElement::is_in_error

protectedinherited

Indicates if an error was encountered during the operation of the element.

Definition at line 120 of file NvElement.h.

Referenced by NvElement::isInError().

◆ output_plane

NvV4l2ElementPlane NvV4l2Element::output_plane

inherited

Sets the output plane.

Output plane of the element

Definition at line 141 of file NvV4l2Element.h.

◆ output_plane_pixfmt

uint32_t NvV4l2Element::output_plane_pixfmt

protectedinherited

Pixel format of output plane buffers.

Definition at line 181 of file NvV4l2Element.h.

◆ profiler

NvElementProfiler NvElement::profiler

protectedinherited

Profiler for the element.

Definition at line 124 of file NvElement.h.

The documentation for this class was generated from the following file:

multimedia_api/ll_samples/include/NvVideoEncoder.h


Jetson Linux API Reference	36.4 Release

Jetson Linux API Reference

36.4 Release

Detailed Description

Public Member Functions

Static Public Member Functions

Data Fields

Protected Attributes

Constructor & Destructor Documentation

◆ ~NvVideoEncoder()

Member Function Documentation

◆ abort()

◆ ClearPollInterrupt()

◆ createVideoEncoder()

◆ DevicePoll()

◆ dqEvent()

◆ enableAV1Tile()

◆ enableAV1TileGroups()

◆ enableExternalRC()

◆ enableExternalRPS()

◆ enableMotionVectorReporting()

◆ enableProfiling()

◆ enableReconCRC()

◆ enableROI()

◆ enableTwoPassCBR()

◆ forceIDR()

◆ getControl()

◆ getExtControls()

◆ getMetadata()

◆ getMotionVectors()

◆ getProfilingData()

◆ isInError()

◆ isProfilingEnabled()

◆ printProfilingStats()

◆ setAlliFramesEncode()

◆ setAV1DisableCDFUpdate()

◆ setAV1ErrResilienceMode()

◆ setAV1FrameIDPresentFlag()

◆ setAV1SsimRdo()

◆ setBitrate()

◆ setCABAC()

◆ setCapturePlaneFormat()

◆ setChromaFactorIDC()

◆ setConstantQp()

◆ setControl()

◆ setDisableAMP()

◆ setEncoderCommand()

◆ setExtControls()

◆ setExtendedColorFormat()

◆ setFrameRate()

◆ setFramesToEncode()

◆ setHWPresetType()

◆ setIDRInterval()

◆ setIFrameInterval()

◆ setInitQP()

◆ SetInputMetaParams()

◆ setInsertAudEnabled()

◆ setInsertSpsPpsAtIdrEnabled()

◆ setInsertVuiEnabled()

◆ setLevel()

◆ setLossless()

◆ setMaxPerfMode()

◆ setNumBFrames()

◆ setNumReferenceFrames()

◆ setOutputPlaneFormat()

◆ setPeakBitrate()

◆ setPocType()

◆ SetPollInterrupt()

◆ setPPEInitParams()

◆ setProfile()

◆ setQpRange()

◆ setRateControlMode()

◆ setROIParams()

◆ setSampleAspectRatioHeight()

◆ setSampleAspectRatioWidth()

◆ setSliceIntrarefresh()

◆ setSliceLength()

◆ setSliceLevelEncode()

◆ setTemporalTradeoff()

◆ setVirtualBufferSize()

◆ subscribeEvent()
