Detailed Description
Holds the metadata parameters for video encoder and decoder.
The metadata is valid for the buffer with index buffer_index after the buffer is dequeued until it is queued again.
Definition at line 2420 of file v4l2_nv_extensions.h.
Data Fields | |
| v4l2_ctrl_videodec_inputbuf_metadata * | VideoDecHeaderErrorMetadata |
| A pointer to v4l2_ctrl_videodec_inputbuf_metadata structure. More... | |
| v4l2_ctrl_videodec_outputbuf_metadata * | VideoDecMetadata |
| A pointer to v4l2_ctrl_videodec_outputbuf_metadata structure. More... | |
| v4l2_ctrl_videoenc_outputbuf_metadata * | VideoEncMetadata |
| A pointer to v4l2_ctrl_videoenc_outputbuf_metadata structure. More... | |
| v4l2_ctrl_videoenc_outputbuf_metadata_MV * | VideoEncMetadataMV |
| A pointer to v4l2_ctrl_videoenc_outputbuf_metadata_MV structure. More... | |
| __u32 | buffer_index |
| Index of the buffer whose metadata is required. More... | |
| __u32 | reserved [4] |
| Reserved fields are added for extensibility. More... | |
Field Documentation
◆ buffer_index
| __u32 v4l2_ctrl_video_metadata_::buffer_index |
Index of the buffer whose metadata is required.
Definition at line 2439 of file v4l2_nv_extensions.h.
◆ reserved
| __u32 v4l2_ctrl_video_metadata_::reserved[4] |
Reserved fields are added for extensibility.
Definition at line 2441 of file v4l2_nv_extensions.h.
◆ VideoDecHeaderErrorMetadata
| v4l2_ctrl_videodec_inputbuf_metadata* v4l2_ctrl_video_metadata_::VideoDecHeaderErrorMetadata |
A pointer to v4l2_ctrl_videodec_inputbuf_metadata structure.
This must be a valid pointer when used with V4L2_CID_MPEG_VIDEODEC_INPUT_METADATA IOCTL.
Definition at line 2425 of file v4l2_nv_extensions.h.
◆ VideoDecMetadata
| v4l2_ctrl_videodec_outputbuf_metadata* v4l2_ctrl_video_metadata_::VideoDecMetadata |
A pointer to v4l2_ctrl_videodec_outputbuf_metadata structure.
This must be a valid pointer when used with V4L2_CID_MPEG_VIDEODEC_METADATA IOCTL.
Definition at line 2429 of file v4l2_nv_extensions.h.
◆ VideoEncMetadata
| v4l2_ctrl_videoenc_outputbuf_metadata* v4l2_ctrl_video_metadata_::VideoEncMetadata |
A pointer to v4l2_ctrl_videoenc_outputbuf_metadata structure.
This must be a valid pointer when used with V4L2_CID_MPEG_VIDEOENC_METADATA IOCTL.
Definition at line 2433 of file v4l2_nv_extensions.h.
◆ VideoEncMetadataMV
| v4l2_ctrl_videoenc_outputbuf_metadata_MV* v4l2_ctrl_video_metadata_::VideoEncMetadataMV |
A pointer to v4l2_ctrl_videoenc_outputbuf_metadata_MV structure.
This must be a valid pointer when used with V4L2_CID_MPEG_VIDEOENC_METADATA_MV IOCTL.
Definition at line 2437 of file v4l2_nv_extensions.h.
The documentation for this struct was generated from the following file:
- libv4l2/include/linux/v4l2_nv_extensions.h
