Detailed Description
Definition at line 60 of file gstnvdsaudiotemplate.h.
Data Fields | |
| GstBaseTransform | base_trans |
| DSCustomLibrary_Factory * | algo_factory |
| Custom Library Factory and Interface. More... | |
| IDSCustomLibrary * | algo_ctx |
| gchar * | custom_lib_name |
| Custom Library Name and output caps string. More... | |
| std::vector< Property > * | vecProp |
| gchar * | custom_prop_string |
| gboolean | stop |
| Boolean to signal output thread to stop. More... | |
| GstAudioInfo | in_audio_info |
| Input and Output audio info (resolution, color format, framerate, etc) More... | |
| GstAudioInfo | out_audio_info |
| guint | gpu_id |
| GPU ID on which we expect to execute the task. More... | |
| nvtxDomainHandle_t | nvtx_domain |
| NVTX Domain. More... | |
| GstCaps * | sinkcaps |
| GstCaps * | srccaps |
| guint | frame_number |
| guint | num_batch_buffers |
Field Documentation
◆ algo_ctx
| IDSCustomLibrary* _GstNvDsAudioTemplate::algo_ctx |
Definition at line 66 of file gstnvdsaudiotemplate.h.
◆ algo_factory
| DSCustomLibrary_Factory* _GstNvDsAudioTemplate::algo_factory |
Custom Library Factory and Interface.
Definition at line 65 of file gstnvdsaudiotemplate.h.
◆ base_trans
| GstBaseTransform _GstNvDsAudioTemplate::base_trans |
Definition at line 62 of file gstnvdsaudiotemplate.h.
◆ custom_lib_name
| gchar* _GstNvDsAudioTemplate::custom_lib_name |
Custom Library Name and output caps string.
Definition at line 69 of file gstnvdsaudiotemplate.h.
◆ custom_prop_string
| gchar* _GstNvDsAudioTemplate::custom_prop_string |
Definition at line 73 of file gstnvdsaudiotemplate.h.
◆ frame_number
| guint _GstNvDsAudioTemplate::frame_number |
Definition at line 91 of file gstnvdsaudiotemplate.h.
◆ gpu_id
| guint _GstNvDsAudioTemplate::gpu_id |
GPU ID on which we expect to execute the task.
Definition at line 83 of file gstnvdsaudiotemplate.h.
◆ in_audio_info
| GstAudioInfo _GstNvDsAudioTemplate::in_audio_info |
Input and Output audio info (resolution, color format, framerate, etc)
Definition at line 79 of file gstnvdsaudiotemplate.h.
◆ num_batch_buffers
| guint _GstNvDsAudioTemplate::num_batch_buffers |
Definition at line 92 of file gstnvdsaudiotemplate.h.
◆ nvtx_domain
| nvtxDomainHandle_t _GstNvDsAudioTemplate::nvtx_domain |
NVTX Domain.
Definition at line 86 of file gstnvdsaudiotemplate.h.
◆ out_audio_info
| GstAudioInfo _GstNvDsAudioTemplate::out_audio_info |
Definition at line 80 of file gstnvdsaudiotemplate.h.
◆ sinkcaps
| GstCaps* _GstNvDsAudioTemplate::sinkcaps |
Definition at line 88 of file gstnvdsaudiotemplate.h.
◆ srccaps
| GstCaps* _GstNvDsAudioTemplate::srccaps |
Definition at line 89 of file gstnvdsaudiotemplate.h.
◆ stop
| gboolean _GstNvDsAudioTemplate::stop |
Boolean to signal output thread to stop.
Definition at line 76 of file gstnvdsaudiotemplate.h.
◆ vecProp
| std::vector<Property>* _GstNvDsAudioTemplate::vecProp |
Definition at line 72 of file gstnvdsaudiotemplate.h.
The documentation for this struct was generated from the following file:
