Detailed Description
Holds information about each tracked object.
Definition at line 277 of file nvdstracker.h.
Data Fields | |
| uint16_t | classId |
| Holds the class ID of the object to be tracked. More... | |
| uint64_t | trackingId |
| Holds a unique ID for the object, assigned by the tracker. More... | |
| NvMOTRect | bbox |
| Holds the bounding box. More... | |
| float | confidence |
| Holds the tracking confidence of the object. More... | |
| uint32_t | age |
| Holds the track length in frames. More... | |
| NvMOTObjToTrack * | associatedObjectIn |
| Holds a pointer to the associated input object, if there is one. More... | |
| NvDsObjReid | reid |
| Each target’s reid vector information. More... | |
| float | visibility |
| Object visibility. More... | |
| float | ptImgFeet [2] |
| Foot location in frame coordinates. More... | |
| float | ptWorldFeet [2] |
| Foot location in 3D coordinates. More... | |
| NvDsObjConvexHull | convexHull |
| Convex hull information projected on frame. More... | |
| uint8_t | reserved [128] |
| Reserved custom data field. More... | |
Field Documentation
◆ age
| uint32_t _NvMOTTrackedObj::age |
Holds the track length in frames.
Definition at line 288 of file nvdstracker.h.
◆ associatedObjectIn
| NvMOTObjToTrack* _NvMOTTrackedObj::associatedObjectIn |
Holds a pointer to the associated input object, if there is one.
Definition at line 290 of file nvdstracker.h.
◆ bbox
| NvMOTRect _NvMOTTrackedObj::bbox |
Holds the bounding box.
Definition at line 284 of file nvdstracker.h.
◆ classId
| uint16_t _NvMOTTrackedObj::classId |
Holds the class ID of the object to be tracked.
Definition at line 280 of file nvdstracker.h.
◆ confidence
| float _NvMOTTrackedObj::confidence |
Holds the tracking confidence of the object.
Definition at line 286 of file nvdstracker.h.
◆ convexHull
| NvDsObjConvexHull _NvMOTTrackedObj::convexHull |
Convex hull information projected on frame.
Definition at line 300 of file nvdstracker.h.
◆ ptImgFeet
| float _NvMOTTrackedObj::ptImgFeet[2] |
Foot location in frame coordinates.
Definition at line 296 of file nvdstracker.h.
◆ ptWorldFeet
| float _NvMOTTrackedObj::ptWorldFeet[2] |
Foot location in 3D coordinates.
Definition at line 298 of file nvdstracker.h.
◆ reid
| NvDsObjReid _NvMOTTrackedObj::reid |
Each target’s reid vector information.
Definition at line 292 of file nvdstracker.h.
◆ reserved
| uint8_t _NvMOTTrackedObj::reserved[128] |
Reserved custom data field.
Definition at line 302 of file nvdstracker.h.
◆ trackingId
| uint64_t _NvMOTTrackedObj::trackingId |
Holds a unique ID for the object, assigned by the tracker.
Definition at line 282 of file nvdstracker.h.
◆ visibility
| float _NvMOTTrackedObj::visibility |
Object visibility.
Definition at line 294 of file nvdstracker.h.
The documentation for this struct was generated from the following file:
