Detailed Description
Definition at line 62 of file gstnvdsvideotemplate.h.
Data Fields | |
| GstBaseTransform | base_trans |
| DSCustomLibrary_Factory * | algo_factory |
| Custom Library Factory and Interface. More... | |
| IDSCustomLibrary * | algo_ctx |
| gchar * | custom_lib_name |
| Custom Library Name and output caps string. More... | |
| std::vector< Property > * | vecProp |
| gchar * | custom_prop_string |
| gboolean | stop |
| Boolean to signal output thread to stop. More... | |
| GstVideoInfo | in_video_info |
| Input and Output video info (resolution, color format, framerate, etc) More... | |
| GstVideoInfo | out_video_info |
| guint | gpu_id |
| GPU ID on which we expect to execute the task. More... | |
| gboolean | dummy_meta_insert |
| gboolean | fill_dummy_batch_meta |
| nvtxDomainHandle_t | nvtx_domain |
| NVTX Domain. More... | |
| GstCaps * | sinkcaps |
| GstCaps * | srccaps |
| guint | num_batch_buffers |
| NvBufSurfTransformConfigParams | config_params |
| gint | compute_hw |
| cudaStream_t | cu_nbstream |
| void * | inter_buf |
| void * | cvmat |
| gchar * | config_file_path |
| gint | in_width |
| gint | in_height |
| gint | out_width |
| gint | out_height |
Field Documentation
◆ algo_ctx
| IDSCustomLibrary* _GstNvDsVideoTemplate::algo_ctx |
Definition at line 68 of file gstnvdsvideotemplate.h.
◆ algo_factory
| DSCustomLibrary_Factory* _GstNvDsVideoTemplate::algo_factory |
Custom Library Factory and Interface.
Definition at line 67 of file gstnvdsvideotemplate.h.
◆ base_trans
| GstBaseTransform _GstNvDsVideoTemplate::base_trans |
Definition at line 64 of file gstnvdsvideotemplate.h.
◆ compute_hw
| gint _GstNvDsVideoTemplate::compute_hw |
Definition at line 98 of file gstnvdsvideotemplate.h.
◆ config_file_path
| gchar* _GstNvDsVideoTemplate::config_file_path |
Definition at line 108 of file gstnvdsvideotemplate.h.
◆ config_params
| NvBufSurfTransformConfigParams _GstNvDsVideoTemplate::config_params |
Definition at line 97 of file gstnvdsvideotemplate.h.
◆ cu_nbstream
| cudaStream_t _GstNvDsVideoTemplate::cu_nbstream |
Definition at line 99 of file gstnvdsvideotemplate.h.
◆ custom_lib_name
| gchar* _GstNvDsVideoTemplate::custom_lib_name |
Custom Library Name and output caps string.
Definition at line 71 of file gstnvdsvideotemplate.h.
◆ custom_prop_string
| gchar* _GstNvDsVideoTemplate::custom_prop_string |
Definition at line 75 of file gstnvdsvideotemplate.h.
◆ cvmat
| void* _GstNvDsVideoTemplate::cvmat |
Definition at line 105 of file gstnvdsvideotemplate.h.
◆ dummy_meta_insert
| gboolean _GstNvDsVideoTemplate::dummy_meta_insert |
Definition at line 87 of file gstnvdsvideotemplate.h.
◆ fill_dummy_batch_meta
| gboolean _GstNvDsVideoTemplate::fill_dummy_batch_meta |
Definition at line 89 of file gstnvdsvideotemplate.h.
◆ gpu_id
| guint _GstNvDsVideoTemplate::gpu_id |
GPU ID on which we expect to execute the task.
Definition at line 85 of file gstnvdsvideotemplate.h.
◆ in_height
| gint _GstNvDsVideoTemplate::in_height |
Definition at line 112 of file gstnvdsvideotemplate.h.
◆ in_video_info
| GstVideoInfo _GstNvDsVideoTemplate::in_video_info |
Input and Output video info (resolution, color format, framerate, etc)
Definition at line 81 of file gstnvdsvideotemplate.h.
◆ in_width
| gint _GstNvDsVideoTemplate::in_width |
Definition at line 111 of file gstnvdsvideotemplate.h.
◆ inter_buf
| void* _GstNvDsVideoTemplate::inter_buf |
Definition at line 102 of file gstnvdsvideotemplate.h.
◆ num_batch_buffers
| guint _GstNvDsVideoTemplate::num_batch_buffers |
Definition at line 96 of file gstnvdsvideotemplate.h.
◆ nvtx_domain
| nvtxDomainHandle_t _GstNvDsVideoTemplate::nvtx_domain |
NVTX Domain.
Definition at line 92 of file gstnvdsvideotemplate.h.
◆ out_height
| gint _GstNvDsVideoTemplate::out_height |
Definition at line 116 of file gstnvdsvideotemplate.h.
◆ out_video_info
| GstVideoInfo _GstNvDsVideoTemplate::out_video_info |
Definition at line 82 of file gstnvdsvideotemplate.h.
◆ out_width
| gint _GstNvDsVideoTemplate::out_width |
Definition at line 115 of file gstnvdsvideotemplate.h.
◆ sinkcaps
| GstCaps* _GstNvDsVideoTemplate::sinkcaps |
Definition at line 94 of file gstnvdsvideotemplate.h.
◆ srccaps
| GstCaps* _GstNvDsVideoTemplate::srccaps |
Definition at line 95 of file gstnvdsvideotemplate.h.
◆ stop
| gboolean _GstNvDsVideoTemplate::stop |
Boolean to signal output thread to stop.
Definition at line 78 of file gstnvdsvideotemplate.h.
◆ vecProp
| std::vector<Property>* _GstNvDsVideoTemplate::vecProp |
Definition at line 74 of file gstnvdsvideotemplate.h.
The documentation for this struct was generated from the following file:
