Detailed Description
Holds information about the batch of frames to be inferred.
Definition at line 247 of file sources/gst-plugins/gst-nvdspreprocess/include/nvdspreprocess_interface.h.
Data Fields | |
| std::vector< NvDsPreProcessUnit > | units |
| Vector of units in the batch. More... | |
| std::vector< NvBufSurfTransformSyncObj_t > | sync_objects |
| Vector of sync objects for async transformation of the batch. More... | |
| GstBuffer * | inbuf = nullptr |
| Pointer to the input GstBuffer. More... | |
| gulong | inbuf_batch_num = 0 |
| Batch number of the input batch. More... | |
| gboolean | push_buffer = FALSE |
| Boolean indicating that the output thread should only push the buffer to downstream element. More... | |
| gboolean | event_marker = FALSE |
| Boolean marking this batch as an event marker. More... | |
| GstBuffer * | converted_buf = nullptr |
| Buffer containing the intermediate conversion output for the batch. More... | |
| NvDsPreProcessFormat | scaling_pool_format |
| scaling pool color format More... | |
| NvDsBatchMeta * | batch_meta |
| Deepstream batch meta. More... | |
| uint32_t | pitch |
| Holds the pitch of the buffer. More... | |
| nvtxRangeId_t | nvtx_complete_buf_range = 0 |
| nvtx buf range More... | |
Field Documentation
◆ batch_meta
| NvDsBatchMeta * NvDsPreProcessBatch::batch_meta |
Deepstream batch meta.
Definition at line 271 of file sources/gst-plugins/gst-nvdspreprocess/include/nvdspreprocess_interface.h.
◆ converted_buf
| GstBuffer * NvDsPreProcessBatch::converted_buf = nullptr |
Buffer containing the intermediate conversion output for the batch.
Definition at line 267 of file sources/gst-plugins/gst-nvdspreprocess/include/nvdspreprocess_interface.h.
◆ event_marker
| gboolean NvDsPreProcessBatch::event_marker = FALSE |
Boolean marking this batch as an event marker.
This is only used for synchronization. The output loop does not process on the batch.
Definition at line 265 of file sources/gst-plugins/gst-nvdspreprocess/include/nvdspreprocess_interface.h.
◆ inbuf
| GstBuffer * NvDsPreProcessBatch::inbuf = nullptr |
Pointer to the input GstBuffer.
Definition at line 254 of file sources/gst-plugins/gst-nvdspreprocess/include/nvdspreprocess_interface.h.
◆ inbuf_batch_num
| gulong NvDsPreProcessBatch::inbuf_batch_num = 0 |
Batch number of the input batch.
Definition at line 256 of file sources/gst-plugins/gst-nvdspreprocess/include/nvdspreprocess_interface.h.
◆ nvtx_complete_buf_range
| nvtxRangeId_t NvDsPreProcessBatch::nvtx_complete_buf_range = 0 |
nvtx buf range
Definition at line 275 of file sources/gst-plugins/gst-nvdspreprocess/include/nvdspreprocess_interface.h.
◆ pitch
| uint32_t NvDsPreProcessBatch::pitch |
Holds the pitch of the buffer.
Definition at line 273 of file sources/gst-plugins/gst-nvdspreprocess/include/nvdspreprocess_interface.h.
◆ push_buffer
| gboolean NvDsPreProcessBatch::push_buffer = FALSE |
Boolean indicating that the output thread should only push the buffer to downstream element.
If set to true, a corresponding batch has not been queued at the input of NvDsPreProcessContext and hence dequeuing of output is not required.
Definition at line 261 of file sources/gst-plugins/gst-nvdspreprocess/include/nvdspreprocess_interface.h.
◆ scaling_pool_format
| NvDsPreProcessFormat NvDsPreProcessBatch::scaling_pool_format |
scaling pool color format
Definition at line 269 of file sources/gst-plugins/gst-nvdspreprocess/include/nvdspreprocess_interface.h.
◆ sync_objects
| std::vector< NvBufSurfTransformSyncObj_t > NvDsPreProcessBatch::sync_objects |
Vector of sync objects for async transformation of the batch.
Definition at line 252 of file sources/gst-plugins/gst-nvdspreprocess/include/nvdspreprocess_interface.h.
◆ units
| std::vector< NvDsPreProcessUnit > NvDsPreProcessBatch::units |
Vector of units in the batch.
Can be for Frame/ROI/Crop
Definition at line 250 of file sources/gst-plugins/gst-nvdspreprocess/include/nvdspreprocess_interface.h.
The documentation for this struct was generated from the following file:
