SN5400 and SN5600 Ethernet Switch Systems Quick Installation Guide

NVIDIA SN5400 AND SN5600 SWITCH SYSTEMS QUICK INSTALLATION GUIDE



Pay Attention!

  • At least two people are required to safely mount the system in the rack.

  • All servers and systems in the rack should be planned with the airflow direction. All FRU components must have the same air flow direction. A mismatch in the air flow will affect the heat dissipation.

  • The part of the system to which you choose to attach the rails will determine the system's adjustable side. The system's part to which the brackets are attached will be adjacent to the cabinet.

  • The FRU side is extractable. Mounting the rack brackets inverted to the FRU side will allow you to slide the FRUs, in and out.

  • Due to thermal considerations, the switch systems must be installed in a horizontal position. do not install the systems vertically.





Package Contents (System and Rail-Kit)

  • 1 x System

  • 1 x Rail kit

  • 2 x Power cables for each power supply unit – Type C20 to C19

  • 1 x Harness: HAR000028 – Harness RS232 2M cable – DB9 to RJ-45

  • 2 x Cable retainers for each power supply unit

  • 32 x OSFP thermal caps

Item

Quantity

Item

Rail kit for 23.6-31.5” (600-800mm) racks

X2 (of each part)

A


B


Power cables – Type C20-C19

X4


Harness: RS232 2M cable – DB9 to RJ-45

X1


Cable retainers

X2


OSFP thermal caps

X32


If anything is damaged or missing, contact your NVIDIA representative at Networking-support@nvidia.com.
