Quickstart Guide#

This page describes how to launch Alpamayo1.5 NIM and verify that the service is ready.

Note

Before following this guide, install and configure the components listed in Prerequisites.

Generate an API Key#

An NGC API key is required to access NGC resources. The key can be generated on the NGC setup page.

When creating an NGC API key, ensure that at least NGC Catalog is selected from the Services Included dropdown. If this key will be reused for other purposes, more services can be included.

Generate Personal Key

Export the API Key#

Pass the value of the API key to the docker run command in the next section as the NGC_API_KEY environment variable to download the appropriate models and resources when starting the NIM.

If you are not familiar with how to create the NGC_API_KEY environment variable, export it in your terminal:

export NGC_API_KEY=<value>

Run one of the following commands to make the key available at startup:

# If using bash
echo "export NGC_API_KEY=<value>" >> ~/.bashrc

# If using zsh
echo "export NGC_API_KEY=<value>" >> ~/.zshrc

Other, more secure options include saving the value in a file, which you can retrieve with cat $NGC_API_KEY_FILE, or using a password manager.

Docker Login to NGC#

To pull the NIM container image from NGC, first authenticate with the NVIDIA Container Registry using the following command:

echo "$NGC_API_KEY" | docker login nvcr.io --username '$oauthtoken' --password-stdin

Use $oauthtoken as the username and NGC_API_KEY as the password. The $oauthtoken username is a special name indicating that you authenticate with an API key, not a username/password.

Launch the NIM#

Use the following command to start Alpamayo1.5 NIM interactively. This form removes the container when you exit it and is convenient while evaluating the NIM:

export IMG_NAME=nvcr.io/nim/nvidia/alpamayo1.5:1.0.0
export LOCAL_NIM_CACHE=/tmp/alpamayo-nim-cache
mkdir -p "$LOCAL_NIM_CACHE"
chmod 777 "$LOCAL_NIM_CACHE"

docker run -it --rm --name alpamayo1.5 \
   --runtime=nvidia \
   --gpus all \
   --shm-size=16g \
   --ulimit memlock=-1 \
   --ulimit stack=67108864 \
   -e NGC_API_KEY=$NGC_API_KEY \
   -v "$LOCAL_NIM_CACHE:/opt/nim/.cache" \
   -p 8000:8000 \
   -p 50051:50051 \
   $IMG_NAME

For a detached service, use -d and omit --rm so that logs remain available after the process exits:

docker run -d --name alpamayo1.5 \
   --runtime=nvidia \
   --gpus all \
   --shm-size=16g \
   --ulimit memlock=-1 \
   --ulimit stack=67108864 \
   -e NGC_API_KEY=$NGC_API_KEY \
   -v "$LOCAL_NIM_CACHE:/opt/nim/.cache" \
   -p 8000:8000 \
   -p 50051:50051 \
   $IMG_NAME

Follow startup with docker logs -f alpamayo1.5. Stop and remove the detached container with docker stop alpamayo1.5 followed by docker rm alpamayo1.5.

--shm-size=16g is important for direct Docker usage because PyTriton and TensorRT-LLM exchange multimodal request payloads through shared memory. Host IPC can also work when allowed by your deployment environment, but the quickstart uses an explicit shared-memory segment.

Note

The container runs as user ID 1000, so the cache directory mounted at /opt/nim/.cache must be writable by UID 1000. The quickstart uses /tmp because home directories are commonly NFS-backed and reject writes from the container UID. For a persistent deployment, use a UID-1000-writable directory on local disk or a correctly initialized persistent volume. Refer to Configuring a NIM for cache permission options.

Docker Run Parameters#

Flag

Description

-it

Runs the container interactively with a terminal attached.

-d

Runs the container in the background. Use this instead of -it for the detached variant.

--rm

Deletes the container after it exits.

--name alpamayo1.5

Gives the container a stable name for local inspection.

--runtime=nvidia

Makes NVIDIA drivers available inside the container.

--gpus all

Exposes GPUs inside the container. Alpamayo1.5 uses one GPU per container.

--shm-size=16g

Provides enough shared memory for PyTriton and TensorRT-LLM multimodal request payloads.

--ulimit memlock=-1

Allows locked memory for GPU-serving runtime components.

--ulimit stack=67108864

Raises the process stack limit.

-e NGC_API_KEY=$NGC_API_KEY

Provide the container with the token necessary to download adequate models and resources from NGC. Refer to Export the API Key.

-v "$LOCAL_NIM_CACHE:/opt/nim/.cache"

Mounts a persistent model cache.

-p 8000:8000

Exposes the HTTP API.

-p 50051:50051

Exposes the gRPC trajectory API.

The NIM automatically selects a compatible profile for the visible GPU. To request a specific precision, add -e NIM_PRECISION=<precision> with one of bf16, fp8, or w4a16. Refer to Support Matrix for the supported GPU and precision combinations.

Check Startup#

Check readiness and the available model metadata:

curl http://localhost:8000/v1/health/ready
curl http://localhost:8000/v1/models

Readiness is reported after TensorRT-LLM initialization and the configured startup warmup requests complete. Startup warmup is enabled by default because the trajectory expert uses shape-specific CUDA graph replay. Warmup covers every K value in NIM_ALPAMAYO_TRAJ_SAMPLES. A first client request can still be slower than steady state because it may populate request-path caches that are not covered by startup warmup. Run one untimed request before benchmarking.

Set NIM_ALPAMAYO_STARTUP_WARMUP=0 to skip warmup inference during development. The backend still loads before readiness.

Run a Sample Request#

The NIM image includes an Alpamayo sample scene at /workspace/sample_data. In another terminal, copy it from the named running container before using the examples:

docker cp alpamayo1.5:/workspace/sample_data ./sample_data
docker cp alpamayo1.5:/opt/nim/build_http_payload.py ./build_http_payload.py

You can also extract the scene without starting the NIM:

sample_container=$(docker create "$IMG_NAME")
docker cp "$sample_container:/workspace/sample_data" ./sample_data
docker cp "$sample_container:/opt/nim/build_http_payload.py" ./build_http_payload.py
docker rm "$sample_container"

Payload Builder Options#

The bundled helper produces complete JSON request bodies for each HTTP endpoint. Its command-line interface is:

usage: build_http_payload.py --endpoint {infer,chat,vqa}
                             [--sample-dir SAMPLE_DIR]
                             [--nav-text NAV_TEXT]
                             [--question QUESTION]
                             [--layout {full,reduced}]

--endpoint {infer,chat,vqa}
    Required endpoint schema to generate.
--sample-dir SAMPLE_DIR
    Extracted sample directory (default: /workspace/sample_data).
--nav-text NAV_TEXT
    Route context for infer or chat (default: Drive forward.).
--question QUESTION
    VQA question (default: What is in front of the ego vehicle?).
--layout {full,reduced}
    Trajectory layout for infer or chat. full uses all 16 images and is the
    default; reduced uses front_wide_t0 for a quick single-image validation. VQA always
    uses front_wide_t0.

Run python3 build_http_payload.py --help to inspect the options shipped in your container version. The helper writes JSON to standard output, so redirect it to a file and send that file with curl --data-binary.

For HTTP trajectory examples, the bundled payload builder uses the complete 16-image scene by default:

python3 build_http_payload.py \
   --endpoint infer --sample-dir sample_data > /tmp/alpamayo-infer.json

Use --layout reduced only for a quick single-image validation request. The reduced request still includes the required 16-row ego-motion history.

The directory contains images/, egomotion.json, and an optional gt_trajectory.json. Image files use <camera-short-name>_t<timestep>.png or .jpg names. The ego-motion file must contain ego_history_xyz with shape [16, 3] and ego_history_rot with shape [16, 4] or [16, 3, 3]. All 16 history entries remain required for reduced or single-image trajectory layouts.

The following Python examples use the extracted local sample_data directory. Use JPEG images when possible. JPEG payloads are smaller than PNG and use the fastest image decode path in the NIM. The following examples send JPEG payloads; if the sample files are PNG, the client converts them to JPEG in memory.

Run a gRPC Trajectory Request#

For trajectory generation, use the gRPC API when your client can send compressed image bytes directly. HTTP is convenient for trying the NIM and debugging payloads, but latency-sensitive trajectory clients should use gRPC with JPEG image bytes.

Install all client dependencies before running the standalone gRPC example:

python3 -m pip install grpcio grpcio-tools pillow

import importlib
import subprocess
import sys
import tempfile
import textwrap
from io import BytesIO
from pathlib import Path

import grpc
from PIL import Image

PROTO = """
syntax = "proto3";
package nvidia.alpamayo.v1;

service Alpamayo {
  rpc Predict(PredictRequest) returns (PredictResponse);
}

message ImageFrame {
  string camera = 1;
  int32 timestep = 2;
  string mime_type = 3;
  bytes data = 4;
}

message CompressedImageInput {
  repeated ImageFrame frames = 1;
}

message LocalPathInput {
  string scene_dir = 1;
  repeated string image_paths = 2;
}

message PredictRequest {
  reserved 11, 12;

  string model = 1;
  int32 num_traj_samples = 2;
  optional float temperature = 3;
  optional float top_p = 4;
  int32 max_tokens = 5;
  string nav_text = 6;
  string egomotion_json = 7;
  optional int64 seed = 8;
  repeated string camera_order = 9;
  int32 num_frames_per_camera = 14;
  optional int32 top_k = 15;

  oneof input {
    CompressedImageInput compressed_images = 10;
    LocalPathInput local_paths = 13;
  }
}

message PredictResponse {
  string model = 1;
  string backend = 2;
  int32 num_samples = 3;
  int32 num_points = 4;
  float duration = 5;
  string reasoning_text = 6;
  float inference_time = 7;
  repeated float pred_trajectories = 8;
  repeated int64 pred_trajectories_shape = 9;
  string raw_json = 10;
  repeated float pred_rotations = 11;
  repeated int64 pred_rotations_shape = 12;
}
"""

def load_grpc_stubs():
    stub_dir = Path(tempfile.mkdtemp(prefix="alpamayo-grpc-"))
    proto_path = stub_dir / "alpamayo.proto"
    proto_path.write_text(textwrap.dedent(PROTO), encoding="utf-8")
    subprocess.run(
        [
            sys.executable,
            "-m",
            "grpc_tools.protoc",
            f"-I{stub_dir}",
            f"--python_out={stub_dir}",
            f"--grpc_python_out={stub_dir}",
            str(proto_path),
        ],
        check=True,
    )
    sys.path.insert(0, str(stub_dir))
    return (
        importlib.import_module("alpamayo_pb2"),
        importlib.import_module("alpamayo_pb2_grpc"),
    )

cameras = [
    ("camera_cross_left_120fov", "cross_left"),
    ("camera_front_wide_120fov", "front_wide"),
    ("camera_cross_right_120fov", "cross_right"),
    ("camera_front_tele_30fov", "front_tele"),
]

sample_dir = Path("sample_data")

def image_file(short_name: str, timestep: int) -> Path:
    stem = sample_dir / "images" / f"{short_name}_t{timestep}"
    for suffix in (".jpg", ".jpeg", ".png"):
        path = stem.with_suffix(suffix)
        if path.exists():
            return path
    raise FileNotFoundError(stem)

def jpeg_payload(path: Path) -> bytes:
    if path.suffix.lower() in {".jpg", ".jpeg"}:
        return path.read_bytes()
    buf = BytesIO()
    with Image.open(path) as image:
        image.convert("RGB").save(buf, format="JPEG", quality=95)
    return buf.getvalue()

alpamayo_pb2, alpamayo_pb2_grpc = load_grpc_stubs()

request = alpamayo_pb2.PredictRequest(
    model="nvidia/alpamayo1.5",
    num_traj_samples=1,
    temperature=0.6,
    top_p=1.0,
    max_tokens=256,
    nav_text="Drive forward.",
    egomotion_json=(sample_dir / "egomotion.json").read_text(),
    seed=42,
    top_k=1,
)

for camera, short_name in cameras:
    for timestep in range(4):
        path = image_file(short_name, timestep)
        frame = request.compressed_images.frames.add()
        frame.camera = camera
        frame.timestep = timestep
        frame.mime_type = "image/jpeg"
        frame.data = jpeg_payload(path)

options = [
    ("grpc.max_receive_message_length", 128 * 1024 * 1024),
    ("grpc.max_send_message_length", 128 * 1024 * 1024),
]
with grpc.insecure_channel("localhost:50051", options=options) as channel:
    stub = alpamayo_pb2_grpc.AlpamayoStub(channel)
    response = stub.Predict(request, timeout=300)

print(response.pred_trajectories_shape)
print(list(response.pred_trajectories[:6]))
print(response.pred_rotations_shape)
print(list(response.pred_rotations[:9]))

The preceding example sends the default 16-image layout: four cameras with four frames per camera. To send a reduced trajectory layout, set request.camera_order and request.num_frames_per_camera before adding frames. For example, to send one front-wide camera frame:

request.camera_order.append("camera_front_wide_120fov")
request.num_frames_per_camera = 1

frame = request.compressed_images.frames.add()
frame.camera = "camera_front_wide_120fov"
frame.timestep = 0
frame.mime_type = "image/jpeg"
frame.data = jpeg_payload(image_file("front_wide", 0))

For controlled deployments, local_paths can reference images already available inside the NIM container. These are container-local paths, not paths on a remote client host. Normal clients should send JPEG bytes through compressed_images as shown in the preceding gRPC example.

Run an HTTP Trajectory Request#

Use HTTP when you want a JSON-based interface for testing, debugging, or VQA. For production trajectory latency, prefer the gRPC path in the preceding section.

Install the client dependencies before running the standalone example:

python3 -m pip install pillow requests

import base64
import json
from io import BytesIO
from pathlib import Path

from PIL import Image
import requests

image_order = [
    "cross_left_t0", "cross_left_t1", "cross_left_t2", "cross_left_t3",
    "front_wide_t0", "front_wide_t1", "front_wide_t2", "front_wide_t3",
    "cross_right_t0", "cross_right_t1", "cross_right_t2", "cross_right_t3",
    "front_tele_t0", "front_tele_t1", "front_tele_t2", "front_tele_t3",
]

sample_dir = Path("sample_data")

def image_file(name: str) -> Path:
    stem = sample_dir / "images" / name
    for suffix in (".jpg", ".jpeg", ".png"):
        path = stem.with_suffix(suffix)
        if path.exists():
            return path
    raise FileNotFoundError(stem)

def jpeg_payload(path: Path) -> bytes:
    if path.suffix.lower() in {".jpg", ".jpeg"}:
        return path.read_bytes()
    buf = BytesIO()
    with Image.open(path) as image:
        image.convert("RGB").save(buf, format="JPEG", quality=95)
    return buf.getvalue()

def image_data_url(name: str) -> str:
    data = jpeg_payload(image_file(name))

payload = {
    "mode": "trajectory",
    "images": [image_data_url(name) for name in image_order],
    "egomotion": json.loads((sample_dir / "egomotion.json").read_text()),
    "num_traj_samples": 1,
    "nav_text": "Drive forward.",
    "seed": 42,
    "top_k": 1,
    "top_p": 1,
}

response = requests.post(
    "http://localhost:8000/v1/infer",
    json=payload,
    timeout=300,
)
response.raise_for_status()
print(response.json()["pred_trajectories"][0][:3])
print(response.json()["pred_rotations"][0][:1])

For reduced HTTP trajectory layouts, keep the same egomotion payload and add camera_order plus num_frames_per_camera. The images array must follow that camera-major layout:

payload = {
    "mode": "trajectory",
    "images": [image_data_url("front_wide_t0")],
    "egomotion": json.loads((sample_dir / "egomotion.json").read_text()),
    "camera_order": ["front_wide"],
    "num_frames_per_camera": 1,
    "num_traj_samples": 1,
    "seed": 42,
    "top_k": 1,
    "top_p": 1,
}

Next Steps#
