PixelType.h File Reference

Defines types and functions to handle pixel types. More...

#include "DataLayout.h"
#include "detail/FormatUtils.h"

Include dependency graph for PixelType.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

#define	VPI_MAKE_PIXEL_TYPE_ABBREV(memLayout, dataType, packing)
	Creates a user-defined pixel type constant using abbreviated parameters. More...
#define	VPI_MAKE_PIXEL_TYPE(memLayout, dataType, packing)
	Creates a user-defined pixel type constant. More...
enum	VPIPixelType
	Pre-defined pixel types. More...
VPIPixelType	vpiMakePixelType (VPIMemLayout memLayout, VPIDataType dataType, VPIPacking packing)
	Creates a user-defined pixel type. More...
VPIPacking	vpiPixelTypeGetPacking (VPIPixelType type)
	Get the packing of a pixel type. More...
int	vpiPixelTypeGetBitsPerPixel (VPIPixelType type)
	Get the number of bits per pixel of a pixel type. More...
void	vpiPixelTypeGetBitsPerChannel (VPIPixelType type, int32_t *bits)
	Get the number of bits per channel of a pixel type. More...
VPIDataType	vpiPixelTypeGetDataType (VPIPixelType type)
	Get the data type of a pixel type. More...
VPIMemLayout	vpiPixelTypeGetMemLayout (VPIPixelType type)
	Get the memory layout of a pixel type. More...
int	vpiPixelTypeGetChannelCount (VPIPixelType type)
	Get the number of channels of a pixel type. More...
const char *	vpiPixelTypeGetName (VPIPixelType type)
	Returns a string representation of the pixel type. More...

Detailed Description

Defines types and functions to handle pixel types.

Definition in file PixelType.h.

Macro Definition Documentation

VPI_MAKE_PIXEL_TYPE

#define VPI_MAKE_PIXEL_TYPE	(		memLayout,
			dataType,
			packing
	)

Creates a user-defined pixel type constant.

Example to create a block-linear format two interleaved 32-bit floating point channels:

VPIPixelType type = VPI_MAKE_PIXEL_TYPE(VPI_MEM_LAYOUT_BL, VPI_DATA_TYPE_FLOAT, VPI_PACKING_X32_Y32);

Parameters

[in]	memLayout	VPIMemLayout to be used.
[in]	dataType	VPIDataType to be used.
[in]	packing	Format packing used, which also defines the number of channels.

Returns

The user-defined pixel type.

Definition at line 221 of file PixelType.h.

VPI_MAKE_PIXEL_TYPE_ABBREV

#define VPI_MAKE_PIXEL_TYPE_ABBREV	(		memLayout,
			dataType,
			packing
	)

Creates a user-defined pixel type constant using abbreviated parameters.

This macro allows passing abbreviated format parameters (without the parameter type prefix). Example to create a block-linear format two interleaved 32-bit floating point channels:

VPIPixelType type = VPI_MAKE_PIXEL_TYPE_ABBREV(BL, FLOAT, X32_Y32);

Parameters

[in]	memLayout	VPIMemLayout to be used, without the VPI_MEM_LAYOUT_ prefix.
[in]	dataType	VPIDataType to be used, without the VPI_DATA_TYPE_ prefix.
[in]	packing	Format packing used, which also defines the number of channels, without the VPI_PACKING_ prefix.

Returns

The user-defined pixel type.

Definition at line 203 of file PixelType.h.

Function Documentation

vpiMakePixelType()

VPIPixelType vpiMakePixelType	(	VPIMemLayout	memLayout,
		VPIDataType	dataType,
		VPIPacking	packing
	)

Creates a user-defined pixel type.

When the pre-defined pixel types aren't enough, user-defined formats can be created.

Parameters

[in]	memLayout	VPIMemLayout to be used.
[in]	dataType	VPIDataType to be used.
[in]	packing	Format packing used, which also defines the number of channels.

Returns

The user-defined pixel type.

vpiPixelTypeGetBitsPerChannel()

void vpiPixelTypeGetBitsPerChannel	(	VPIPixelType	type,
		int32_t *	bits
	)

Get the number of bits per channel of a pixel type.

Parameters

[in]	type	Pixel type to be queried.
[out]	bits	Pointer to an int32_t array with 4 elements where output will be stored. If it's NULL, the function is a no-op.

vpiPixelTypeGetBitsPerPixel()

int vpiPixelTypeGetBitsPerPixel

(

VPIPixelType

type

)

Get the number of bits per pixel of a pixel type.

Parameters

[in]

type

Pixel type to be queried.

Returns

The number of bits per pixel.

vpiPixelTypeGetChannelCount()

int vpiPixelTypeGetChannelCount

(

VPIPixelType

type

)

Get the number of channels of a pixel type.

Parameters

[in]

type

Pixel type to be queried.

Returns

The number of channels of the pixel type.

vpiPixelTypeGetDataType()

VPIDataType vpiPixelTypeGetDataType

(

VPIPixelType

type

)

Get the data type of a pixel type.

Parameters

[in]

type

Pixel type to be queried.

Returns

The data type of the pixel type.

vpiPixelTypeGetMemLayout()

VPIMemLayout vpiPixelTypeGetMemLayout

(

VPIPixelType

type

)

Get the memory layout of a pixel type.

Parameters

[in]

type

Pixel type to be queried.

Returns

The memory layout of the pixel type.

vpiPixelTypeGetName()

const char* vpiPixelTypeGetName

(

VPIPixelType

type

)

Returns a string representation of the pixel type.

Parameters

[in]

type

Pixel type to be returned.

Returns

The string representation of the pixel type. Returned string is valid until next call of this function from the same calling thread.

vpiPixelTypeGetPacking()

VPIPacking vpiPixelTypeGetPacking

(

VPIPixelType

type

)

Get the packing of a pixel type.

Parameters

[in]

type

Pixel type to be queried.

Returns

The format's packing.
