Detailed Description

Base Object class.

Definition at line 44 of file object.hpp.

Inheritance diagram for deepstream::Object:

[legend]

Data Structures
class	Value
	Value wrapper for various types. More...

Public Member Functions
	Object ()
	Constructor of a void object. More...

	Object (unsigned long type_id, const std::string &name)
	Create an object from a type id. More...

	Object (const Object &)
	Copy constructor. More...

	Object (Object &&)
	Move constructor. More...

Object &	operator= (const Object &)
	Copy assignment. More...

Object &	operator= (Object &&)
	Move assignment. More...

virtual	~Object ()
	Destructor. More...

const std::string	getName () const
	Return the name assigned during the construction. More...

	operator bool () const noexcept
	Check if the object is void. More...

bool	operator== (const Object &other) noexcept
	Check if the two objects are the same. More...

GstObject *	give ()
	Give up the ownership and return the opaque pointer. More...

GstObject *	getGObject ()
	Return the opaque object pointer. More...

Object &	take (GstObject *object)
	Takes the ownership of a object through the opaque pointer. More...

Object &	seize (GstObject *object)
	Seize a opaque object to prevent it from being destroyed somewhere. More...

Object &	set (const YAML::Node &params)
	Set the properties from key/value pairs in the yaml format. More...

Object &	set (const std::string &name, const Value &value)

template<typename T , typename... Args>
Object &	set (const std::string &name, const T &value, const Args &... args)

template<typename T , typename... Args>
Object &	getProperty (const std::string &name, T &value, Args &... args)
	Template for getting multiple properties. More...

std::vector< std::string >	listSignals (bool is_action)
	List all the supported signals from the object. More...

bool	connectSignal (const std::string &signal_name, SignalHandler &handler)
	Connect a signal handler to the object. More...

void	emitSignal (const std::string &signal_name, va_list args)
	Emit a signal. More...

Static Public Member Functions
static unsigned long	type ()
	Return the object's type id. More...

Protected Member Functions
virtual void	set_ (const std::string &name, const Value &value)

virtual void	set_ (const std::string &name, const YAML::Node &value)

virtual Value	get_ (const std::string &name)

Protected Attributes
GstObject *	object_

Friends
class	Pipeline

class	Element

Constructor & Destructor Documentation

◆ Object() [1/4]

deepstream::Object::Object ( )

Constructor of a void object.

◆ Object() [2/4]

deepstream::Object::Object	(	unsigned long	type_id,
		const std::string &	name
	)

Create an object from a type id.

Parameters

[in] name name to be assigned to the object instance

◆ Object() [3/4]

deepstream::Object::Object ( const Object & )

Copy constructor.

◆ Object() [4/4]

deepstream::Object::Object ( Object && )

Move constructor.

◆ ~Object()

virtual deepstream::Object::~Object ( )

virtual

Destructor.

Member Function Documentation

◆ connectSignal()

bool deepstream::Object::connectSignal	(	const std::string &	signal_name,
		SignalHandler &	handler
	)

Connect a signal handler to the object.

Parameters

[in]	signal_name	name of the signal to be connected
[in]	handler	handler for the signal

◆ emitSignal()

void deepstream::Object::emitSignal	(	const std::string &	signal_name,
		va_list	args
	)

Emit a signal.

◆ get_()

virtual Value deepstream::Object::get_ ( const std::string & name )

protectedvirtual

Reimplemented in deepstream::CustomObject.

Referenced by getProperty().

◆ getGObject()

GstObject* deepstream::Object::getGObject ( )

inline

Return the opaque object pointer.

Definition at line 140 of file object.hpp.

References object_.

◆ getName()

const std::string deepstream::Object::getName ( ) const

Return the name assigned during the construction.

◆ getProperty()

template<typename T , typename... Args>

Object& deepstream::Object::getProperty	(	const std::string &	name,
		T &	value,
		Args &...	args
	)

inline

Template for getting multiple properties.

Definition at line 171 of file object.hpp.

References get_().

Referenced by deepstream::CountMarker::handleData(), deepstream::TensorMetaParser::handleData(), deepstream::MsgMetaGenerator::handleData(), deepstream::NvDsKittiDump::handleData(), deepstream::LiDARDataSource::initialize(), deepstream::SmartRecordingAction::onAttached(), and deepstream::FileDataSource::read().

◆ give()

GstObject* deepstream::Object::give ( )

Give up the ownership and return the opaque pointer.

◆ listSignals()

std::vector<std::string> deepstream::Object::listSignals ( bool is_action )

List all the supported signals from the object.

◆ operator bool()

deepstream::Object::operator bool ( ) const

inlineexplicitnoexcept

Check if the object is void.

Definition at line 131 of file object.hpp.

References object_.

◆ operator=() [1/2]

Object& deepstream::Object::operator= ( const Object & )

Copy assignment.

◆ operator=() [2/2]

Object& deepstream::Object::operator= ( Object && )

Move assignment.

◆ operator==()

bool deepstream::Object::operator== ( const Object & other )

inlinenoexcept

Check if the two objects are the same.

Definition at line 134 of file object.hpp.

References object_.

◆ seize()

Object& deepstream::Object::seize ( GstObject * object )

Seize a opaque object to prevent it from being destroyed somewhere.

◆ set() [1/3]

template<typename T , typename... Args>

Object& deepstream::Object::set	(	const std::string &	name,
		const T &	value,
		const Args &...	args
	)

inline

Definition at line 161 of file object.hpp.

References set(), and set_().

◆ set() [2/3]

Object& deepstream::Object::set	(	const std::string &	name,
		const Value &	value
	)

inline

Definition at line 154 of file object.hpp.

References set_().

◆ set() [3/3]

Object& deepstream::Object::set ( const YAML::Node & params )

Set the properties from key/value pairs in the yaml format.

Referenced by deepstream::Pipeline::add(), and set().

◆ set_() [1/2]

virtual void deepstream::Object::set_	(	const std::string &	name,
		const Value &	value
	)

protectedvirtual

Reimplemented in deepstream::CustomObject.

Referenced by set().

◆ set_() [2/2]

virtual void deepstream::Object::set_	(	const std::string &	name,
		const YAML::Node &	value
	)

protectedvirtual

Reimplemented in deepstream::CustomObject.

◆ take()

Object& deepstream::Object::take ( GstObject * object )

Takes the ownership of a object through the opaque pointer.

◆ type()

static unsigned long deepstream::Object::type ( )

static

Return the object's type id.

Friends And Related Function Documentation

◆ Element

friend class Element

friend

Definition at line 205 of file object.hpp.

Referenced by deepstream::Pipeline::add().

◆ Pipeline

friend class Pipeline

friend

Definition at line 204 of file object.hpp.

Field Documentation

◆ object_

GstObject* deepstream::Object::object_

protected

Definition at line 198 of file object.hpp.

Referenced by getGObject(), operator bool(), and operator==().

The documentation for this class was generated from the following file:

object.hpp
