Relying on the fact that the NIC hardware “knows” the network time, the ConnectX-6 Dx and later are able to signal the hardware to transmit a packet at a specific network time. The idea is that the software can place a fencing command inside any queue against a specific network time. This command will block all the following packets in the same queue from being transmitted.
![worddav389be2f12812df665c3c3fde9bb505ab.png](https://docscontent.nvidia.com/dims4/default/62fed9c/2147483647/strip/true/crop/900x548+0+0/resize/900x548!/quality/90/?url=https%3A%2F%2Fk3-prod-nvidia-docs.s3.us-west-2.amazonaws.com%2Fbrightspot%2Fconfluence%2F00000188-48d0-d97f-a9f9-d8f0111a0000%2Fimages%2Fnetworking%2Fdownload%2Fattachments%2F89130385%2Fworddav389be2f12812df665c3c3fde9bb505ab.png)
Accurate Scheduling Scheme
