Gesture Recognition

GestureNet is an NVIDIA-developed gesture classification model that is included in the TAO Toolkit. GestureNet supports the following tasks:

• dataset_convert

• train

• evaluate

• inference

• export

These tasks can be invoked from the TAO Toolkit Launcher using the following convention on the command line:

Copy
Copied!

tao gesturenet <sub_task> <args_per_subtask>


where args_per_subtask are the command-line arguments required for a given subtask. Each subtask is explained in detail below.

Pre-processing the Dataset

The GestureNet App requires the data images and labels to be in a specific format. Once it is prepared, the TAO Toolkit includes dataset_convert to prepare the data for model training.

Dataset Extraction Config

The dataset_config spec specifies the parameters neededed to crop hand bounding box and prepare dataset.

Here’s a sample spec:

Copy
Copied!

{
"org_dataset": "data",
"mount_dir_path" :"/workspace/tao-experiments/gesturenet/",
"org_data_dir" : "original",
"post_data_dir" : "extracted",
"kpi_users": ["uid_1", "uid_2"],
"sampling_rate": 1,
"convert_bbox_square": true,
"bbox_enlarge_ratio": 1.1,
"annotation_config":{
"annotation_path": "annotation"
}
}


The following table describes the parameters:

 Field Description Data Type and Constraints Recommended/Typical Value org_dataset Name of dataset. String mount_dir_path Path to the root directory relative to which the data is stored. String org_data_dir Path to original images directory relative to mount_dir_path. String post_data_dir Path to directory relative to mount_dir_path where crops are to be extracted. String kpi_users List of user IDs set aside for Test set. List of String sampling_rate Rate at which to select frames for labeling. If data is not video please set to 1. Integer 1 if dataset is not from video convert_bbox_square Boolean variable to indicate if the labelled bounding box should be converted to a square. Boolean bbox_enlarge_ratio Scale factor used to enlarge bounding box. Float [1.0,1.2] annotation_config The nested annotation dictionary that contains path to folder with labels (relative to /). Dictionary

Dataset Experiment Config

The dataset_experiment_config spec specifies the parameters neededed to combine different datasets. It allows user to provide user IDs that are set aside for validation or test set. It also allows different sampling strategies based on meta data and class counts.

Here’s a sample spec:

Copy
Copied!

{
"mount_dir_path" :"/workspace/tao-experiments/gesturenet",
"org_data_dir" : "original",
"post_data_dir" : "extracted",
"set_list": {
"train_val": [
"data"
],
"kpi": [
"data"
]
},
"uid_list": {
"uid_name": "user_id",
"predefined_val_users": false,
"val_fraction": 0.25,
"validation": [
],
"kpi": [
"uid_1"
]
},
"image_feature_filter": {
"train_val":{
"*":[
{
"location":"outdoor"
}
]
},
"kpi":{
}
},
"sampling": {
"sampling_mode": "average",
"use_class_weights": false,
"class_weights": {
"thumbs_up": 0.5,
"v": 0.5
}
}
}


 Field Description Data Type and Constraints Recommended/Typical Value mount_dir_path Path to the root directory relative to which the data is stored. String org_data_dir Path to original images directory relative to mount_dir_path. String post_data_dir Path to directory relative to mount_dir_path where crops were extracted. String set_list This nested configuration for parameters related to datasets. Dictionary uid_list This nested configuration for parameters related to user ids. Dictionary image_feature_filter This nested configuration for parameters related to filtering images based on metadata. Dictionary sampling This nested configuration for parameters related to class weights and sampling startegy Dictionary

The following table describes the set_list parameters:

 Field Description Data Type and Constraints Recommended/Typical Value train_val List of datasets from which to select users for training and validation. List of String kpi List of datasets from which to select users for test set. List of String

The following table describes the uid_list parameters:

 Field Description Data Type and Constraints Recommended/Typical Value uid_name Name of field that represents unique identifier of each subject. String predefined_val_users Flag to indicate if train-validation split of is specifed by config. Boolean val_fraction Fraction of non-kpi users used for validation set. Only used if predefined_val_users=false. Float validation List of uid used in validation set. Only used if predefined_val_users=true List of String kpi List of uid assigned to test set. List of String

The following table describes the image_feature_filter parameters:

 Field Description Data Type and Constraints Recommended/Typical Value train_val Metadata fields that used to discard images in training and validation set. Dictionary kpi Metadata fields that used to discard images in test set. Dictionary

The following table describes the sampling parameters:

 Field Description Data Type and Constraints Recommended/Typical Value sampling_mode Sampling methodology when using class_weights under : undersampling over : oversampling average : some classes are oversampled and others are undersampled String “average” use_class_weights Boolean variable to indicate if sampling should be based on class weights. Boolean True / False class_weights Dictionary mapping gesture classes of interest and their class weight. Dictionary

Sample Usage of the Dataset Converter Tool

TAO has built in commands to run prepare datset for GestureNet model and is given below.

Copy
Copied!

tao gesturenet dataset_convert  --dataset_spec <dataset_spec_path>
--experiment_spec <experiment_spec_path>
--k_folds <num_folds>
--output_filename <output_filename>
--experiment_name <experiment_name>


Required Arguments

• --dataset_spec: The path to dataset spec.

• --experiment_spec: The path to dataset experiment spec.

• --k_folds: Number of folds.

• --output_filename: Output json that is ingested by GestureNet training pipeline.

• --experiment_name: Name of experiment.

Sample Usage

Here is an example using a GestureNet model.

Copy
Copied!

tao gesturenet dataset_convert --dataset_spec $SPECS_DIR/dataset_config.json \ --k_folds 0 \ --experiment_spec$SPECS_DIR/dataset_experiment_config.json \
-k $KEY  Evaluating the Model TAO Toolkit has built in commands to evaluate a GestureNet model and is given below. Copy Copied!  tao gesturenet evaluate -e <spec_file> -m <model_file> -k <key>  Required Arguments • -e, --experiment_spec_filename: Experiment spec file to set up the evaluation experiment. This should be the same as training spec file. • -m, --model: Path to the model file to use for evaluation. • -k, -–key: Provide the encryption key to decrypt the model. This is a required argument only with a .tlt model file. Sample Usage Here’s an example of using the evaluation command on a GestureNet model. Copy Copied!  tao gesturenet evaluate -e$USER_EXPERIMENT_DIR/model/train_spec.json \
-m $USER_EXPERIMENT_DIR/model/model.tlt \ -k$KEY


Running Inference on the Model

TAO Toolkit has built in commands to run inference on a GestureNet model and is given below.

Copy
Copied!

tao gesturenet inference -e <spec_file>
-m <model_full_path>
-k <key>
--image_root_path <root_path>
--data_json <json_path>
--data_type <data_type>
-results_dir <results_dir>


Required Arguments

• -e, --experiment_spec_filename: Experiment spec file to set up the evaluation experiment. The model parameters should be the same as training spec file.

• -m, --model: Path to the model file to use for evaluation.

• -k, -–key: Provide the encryption key to decrypt the model. This is a required argument. only with a .tlt model file.

• --image_root_path: The root directpry that dataset is mounted at.

• --data_json: The json spec with image path and hand bounding box.

• --data_type: The dataset type within data_json that inference is to be run on.

• --results_dir: Directory where the results are saved.

Sample Usage

Here is an example of running inference using a GestureNet model.

Copy
Copied!

tao gesturenet inference -e $USER_EXPERIMENT_DIR/model/train_spec.json \ -m$USER_EXPERIMENT_DIR/model/model.tlt \
-k $KEY \ --image_root_path /workspace/tao-experiments/gesturenet \ --data_json /workspace/tao-experiments/gesturenet/data.json \ --data_type kpi_set \ --results_dir$USER_EXPERIMENT_DIR/model


Exporting the Model

TAO Toolkit provides a utility for exporting a trained model to an encrypted onnx format or a TensorRT deployable engine format.

The export sub-task optionally generates the calibration cache for TensorRT INT8 engine calibration.

Exporting the model decouples the training process from deployment and allows for conversion to TensorRT engines outside the TAO environment. TensorRT engines are specific to each hardware configuration and should be generated for each unique inference environment. This may be interchangeably referred to as a .trt or .engine file. The same exported TAO model may be used universally across training and deployment hardware. This is referred to as the .etlt file, or encrypted TAO file. During model export, the TAO model is encrypted with a private key, which is required when you deploy this model for inference.

INT8 Mode Overview

TensorRT engines can be generated in INT8 mode to run with lower precision,thus improving performance. This process requires a cache file that contains scale factors for the tensors to help combat quantization errors, which may arise due to low-precision arithmetic. The calibration cache is generated using a calibration tensorfile when export is run with the --data_type flag set to int8. Pre-generating the calibration information and caching it removes the need for calibrating the model on the inference machine. Moving the calibration cache is usually much more convenient than moving the calibration tensorfile since it is a much smaller file and can be moved with the exported model. Using the calibration cache also speeds up engine creation, as building the cache can take several minutes to generate depending on the size of the Tensorfile and the model itself.

The export tool can generate an INT8 calibration cache by ingesting a sampled subset of training data. You need to create a sub-sampled directory of random images that best represent your test dataset. We recommend using at least 10-20% of the training data. The more data provided during calibration, the closer int8 inferences are to fp32 inferences. A helper script is provided with the sample notebook to select the subset data from the given training data.

Based on the evaluation results of the INT8 model, you might need to adjust the number of sampled images or the kind of selected to images to better represent test dataset. You can also use a portion of data from the test data for calibration to improve the results.

FP16/FP32 Model

The calibration.bin is only required if you need to run inference at INT8 precision. For FP16/FP32 based inference, the export step is much simpler. All that is required is to provide a model from the train step to export to convert it into an encrypted TAO model.

Sample Usage of the Export tool

Copy
Copied!

tao gesturenet export -m <Trained TAO Model Path> -k <Encode Key> -o <Output file .etlt>


• -m: The path to the trained model to be exported

• -k: The encryption key for model loading

• -o: The path to the output .etlt file (.etlt is appended to model path otherwise)

• -t: The target opset value for onnx conversion. The default value is 10

• --cal_data_file: The path to the calibration data file (.tensorfile)

• --cal_image_dir The path to a directory with calibration image samples

• --cal_cache_file The path to the calibration file (.bin)

• --data_type: The data type for the TensorRT export. The options are fp32 and int8.

• --batches: The number of images per batch. The default value is 1.

• --max_batch_size: The maximum batch size for the TensorRT engine builder. The default value is 1.

• --max_workspace_size: The maximum workspace size to be set for the TensorRT engine builder

• --batch_size: The number of batches to calibrate over. The default value is 1.

• --engine_file: The path to the exported TRT engine. Generates an engine file if specified.

• --input_dims: Input dims in channels first(CHW) or channels last (HWC) format as comma separated integer values. Default 3,160,160.

• --backend: The model type to export to.

INT8 Export Mode Required Arguments

• --cal_image_dir: The directory of images that is preprocessed and used for calibration.

• --cal_data_file: The tensorfile generated using images in cal_image_dir for calibrating the engine. If this already exists, it is directly used to calibrate the engine. The INT8 tensorfile is a binary file that contains the preprocessed training samples.

Note

The --cal_image_dir parameter applies the necessary preprocessing to generate a tensorfile at the path mentioned in the --cal_data_file parameter, which is in turn used for calibration. The number of generated batches in the tensorfile is obtained from the value set to the --batches parameter, and the batch_size is obtained from the value set to the --batch_size parameter. Ensure that the directory mentioned in --cal_image_dir has at least batch_size * batches number of images in it. The valid image extensions are .jpg, .jpeg, and .png.

INT8 Export Optional Arguments

• --cal_cache_file: The path to save the calibration cache file to. The default value is ./cal.bin. If this file already exists, the calibration step is skipped.

• --batches: The number of batches to use for calibration and inference testing. The default value is 10.

• --batch_size: The batch size to use for calibration. The default value is 1.

• --max_batch_size: The maximum batch size of the TensorRT engine. The default value is 1.

• --max_workspace_size: The maximum workspace size of the TensorRT engine. The default value is 2 * (1 << 30).

• --experiment_spec: The experiment_spec used for training. This argument is used to obtain the parameters to preprocess the data used for calibration.

• --engine_file: The path to the serialized TensorRT engine file. Note that this file is hardware specific and cannot be generalized across GPUs. Use this argument to quickly test your model accuracy using TensorRT on the host. As the TensorRT engine file is hardware specific, you cannot use this engine file for deployment unless the deployment GPU is identical to the training GPU.

Deploying to DeepStream 6.0

The pretrained model for GestureNet provided through NGC is available by default with DeepStream 6.0.

For more details, refer to DeepStream TAO Integration for GestureNet.
