Video-Analytics-MCP Server

Overview

The Video Analytics MCP Server exposes video analytics capabilities through the Model Context Protocol (MCP). It enables AI agents to query and analyze video analytics data stored in Elasticsearch, including incident records, object detection metrics, and sensor metadata.

Key features include:

• Semantic place search using sentence-transformer embeddings
• VLM (Vision Language Model) verification for incidents
• Optional: Active sensor filtering using VST sensor list tool

The server is implemented as a NAT (NVIDIA Agent Toolkit) function group and uses the NAT library to serve its tools via the MCP protocol. For more information about NAT, see NVIDIA Agent Toolkit Documentation.

Prerequisites

System Requirements

• Python 3.13 or 3.14
• NVIDIA Agent Toolkit installed. See NAT Installation.

External Dependencies

• Elasticsearch 7.x or 8.x containing video analytics data
• Optional: VST (Video Sensor Tool) for active sensor filtering
• Optional: Sentence-transformers model for semantic place search

Required Elasticsearch Indices

Configuration

Configuration File

The VA-MCP Server is configured via a YAML file:

functions:
  vst_sensor_list:
    _type: vst.sensor_list
    vst_internal_url: "http://${HOST_IP}:30888"
function_groups:
  video_analytics:
    _type: video_analytics
    es_url: "http://${HOST_IP}:${VSS_ES_PORT}"
    index_prefix: "mdx-"
    vlm_verified: false
    vst_sensor_list_tool: vst_sensor_list
    embedding_model_name: "sentence-transformers/all-MiniLM-L6-v2"
    include:
      - get_incident
      - get_incidents
      - get_sensor_ids
      - get_places
      - get_fov_histogram
      - get_average_speeds
      - analyze
llms:
  nim_llm:
    _type: nim
    model_name: meta/llama-3.1-70b-instruct
    temperature: 0.0
    max_tokens: 1024
# Dummy workflow required to start MCP server
workflow:
  _type: react_agent
  tool_names: [video_analytics]
  llm_name: nim_llm
  verbose: true
  parse_agent_response_max_retries: 3

Environment Variables

The configuration file supports environment variable substitution using ${VAR_NAME} syntax.

Example:

export HOST_IP=10.63.144.174
export VSS_ES_PORT=9200

Quick Start

After setting up dependencies, configuration, and environment variables, start the server:

nat mcp serve --config_file <path/to/config_file>

The server starts on http://localhost:9901/mcp by default.

Custom Host and Port

nat mcp serve --config_file <path/to/config_file> \
  --host 0.0.0.0 \
  --port 9901 \
  --name "<server-name>"

Transport Type

nat mcp serve --config_file <path/to/config_file> --transport sse

For more NAT MCP commands, see NAT MCP Documentation.

Connecting a Client

The MCP server’s tools are accessible using an agent’s standard tool-calling interface.

Example NAT Agent Configuration

function_groups:
  video_analytics_mcp:
    _type: mcp_client
    server:
      transport: streamable-http
      url: "http://localhost:9901/mcp"
llms:
  nim_llm:
    _type: nim
    model_name: meta/llama-3.1-70b-instruct
    temperature: 0.0
    max_tokens: 1024
workflow:
  _type: react_agent
  tool_names: [video_analytics_mcp]
  llm_name: nim_llm
  verbose: true
  max_retries: 3

For more on NAT workflows, see NAT Workflow Documentation.

Available Tools

get_incident

Retrieve a specific incident by ID.

get_incidents

Query incidents with optional filtering.

get_sensor_ids

Get available sensor IDs.

Parameters: place (optional) - filter by place name

Returns: List of sensor IDs

get_places

Get hierarchical place map.

Returns:

{"CityName": ["Intersection1", "Intersection2"]}

get_fov_histogram

Get object counts over time in field of view.

Returns:

{
  "bucketSizeInSec": 180,
  "histogram": [
    {
      "start": "2025-01-12T11:20:10.000Z",
      "end": "2025-01-12T11:23:10.000Z",
      "objects": [
        {"type": "Person", "averageCount": 5}
      ]
    }
  ]
}

get_average_speeds

Get average speed per direction.

Parameters: source, source_type, start_time, end_time

Returns:

{"metrics": [{"direction": "North", "averageSpeed": "25 mph"}]}

analyze

Perform statistical analysis on video analytics data.

Analysis Types:

• max_min_incidents - Min/max overlapping incidents
• average_speed - Average speeds per direction
• avg_num_people - Average people count
• avg_num_vehicles - Average vehicle count

Source Type Options

Several tools accept source and source_type parameters to specify the data source.

Sensor (source_type: "sensor"): Queries by exact sensor ID match.

source: "Camera-001"
source_type: "sensor"

Place (source_type: "place"): Queries by place name using wildcard matching with optional semantic search.

# Match all incidents in a city
source: "Montague"
source_type: "place"

For a specific intersection:

# Match a specific intersection
source: "Lafayette_Agnew"
source_type: "place"

When wildcard matching returns no results, the server automatically falls back to semantic search (if enabled) to find places with similar names.

NAT CLI Commands

Inspect available tools using NAT CLI:

List Tools

nat mcp client tool list --url <mcp-url>

Tool Details

nat mcp client tool list --tool <tool_name> --url <mcp-url>

Call a Tool

nat mcp client tool call --tool <tool_name> --url <mcp-url> --json-args '<json args>'

Help

nat mcp --help

For more NAT MCP commands, see NAT MCP Client Documentation.
